Elatec TWN3 Technical Manual

Transponder reader
Hide thumbs Also See for TWN3:
Table of Contents

Advertisement

Quick Links

Transponder Reader
TWN3
Technical Manual
Doc.-Rev. 1.07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TWN3 and is the answer not in the manual?

Questions and answers

Related Manuals for Elatec TWN3

Summary of Contents for Elatec TWN3

  • Page 1 Transponder Reader TWN3 Technical Manual Doc.-Rev. 1.07...

  • Page 2: Table Of Contents

    USB-Device (Keyboard Emulation) ..................8 USB-Device (Virtual Serial Port) ..................9 Configuration ........................ 11 Entering the Configuration Mode..................11 Writing a Configuration to a TWN3 Device ..............12 Resuming Normal Operation....................13 Selecting Mode of Operation ....................14 Setting Up the Keyboard Emulation................... 15 5.5.1...
  • Page 3 Elatec GmbH 7.1.5.3 System Functions ........................27 7.1.5.4 Function main ..........................28 7.1.6 Statements............................28 7.1.6.1 if Statement ..........................28 7.1.6.2 if else Statement .........................28 7.1.6.3 while Statement..........................28 7.1.6.4 do while Statement........................28 7.1.6.5 for Statement..........................29 7.1.6.6 switch Statement ........................29 7.1.6.7 break Statement..........................29 7.1.6.8 continue Statement........................29 7.1.6.9...

  • Page 4: Introduction

    This document is the reference guide for the transponder reader family TWN3. Note: In order to use the functionality, which is described in this document, your TWN3 reader needs a firmware version V4.00 or above. The latest version of the firmware is part of the developer pack.

  • Page 5: Modes Of Operation

    Mode Mode MultiISO 3. Modes of Operation The transponder reader TWN3 can be ordered in several hardware configurations: Support for the specific transponder family (Multi125, Mifare, HID Prox, HID iClass, Legic, • IndiTag, MultiISO) Physical type of connection (type of cable) to the host computer: USB or V24, DSUB25, •...

  • Page 6: Usb-Device

    Please be aware, that the communication between TWN3 device and host computer is unidirectional. This means, there is no possibility to send data from the host to the TWN3 device. In situations where this is required, we recommend the emulation of a serial port.

  • Page 7: Pin Assignment

    4.1 V24-Device Installing a TWN3 reader with a serial port requires an additional power supply, which is not standard for usual PCs. On the other hand, many devices do supply the 5V on a rarely used pin of the serial connector.

  • Page 8: Usb-Device (Keyboard Emulation)

    Elatec GmbH 4.2 USB-Device (Keyboard Emulation) Installing a TWN3 reader emulating a keyboard is rather simple due to the fact, that drivers do come with the operating system. Therefore, the device simply can be connected to the host computer and can be immediately used.

  • Page 9: Usb-Device (Virtual Serial Port)

    Elatec GmbH 4.3 USB-Device (Virtual Serial Port) In order to install a TWN3 reader, which emulates a virtual serial port under Windows XP, keep the drivers nearby and follow these steps: Plug in the TWN3 reader into your host computer. The following screen should appear (in your •...
  • Page 10 TWN3 transponder reader, you may take a look into the device manager: In this example, we find the TWN3 reader at COM7. Depending on the further configuration of the device, you may now test the TWN3 transponder reader with a normal terminal program.

  • Page 11: Configuration

    Configuration is possible both for V24 and USB devices. Note: Please do not connect more than one TWN3 device at a time to your computer during the usage of TWNConfig. This ensures the knowledge about the TWN3 device which is actually to be configured.

  • Page 12: Writing A Configuration To A Twn3 Device

    Elatec GmbH TWNConfig is searching and connecting to a TWN3 device. You are now ready to do the required configurations on the device. Note: If you are configuring a USB device the first time, you have to install the appropriate configuration drivers.

  • Page 13: Resuming Normal Operation

    Elatec GmbH 5.3 Resuming Normal Operation In order to leave the configuration mode of the TWN3 device and resume to normal operation click the “Restart” button. Note: Disconnecting the device from the host or a power cycle will keep the device in configuration...

  • Page 14: Selecting Mode Of Operation

    Elatec GmbH 5.4 Selecting Mode of Operation In the tab folder “Mode of Operation” you select the basic mode in which the TWN3 device operates. This setup is used both for USB and V24 devices: Mode USB Device V24 Device...

  • Page 15: Setting Up The Keyboard Emulation

    Elatec GmbH 5.5 Setting Up the Keyboard Emulation 5.5.1 Table of Scan Codes This tab folder enables you to change the scan codes of the keyboard emulation, which are sent to the host for a specific character. The default setup of the device already contains the mainly used characters ‘0’...
  • Page 16 Elatec GmbH In order to do this, you may double-click on an existing entry in the table or specify a new entry by pressing the “Add”-button. In the following dialog you now are able to select the appropriate keys. Please keep in mind, that the keyboard keys are to be specified in relation to a standard U.S. QUERTY keyboard, which is shown below: Source: www.wikipedia.org...

  • Page 17: Sending Alt Codes

    Elatec GmbH 5.5.2 Sending ALT Codes You may send ALT codes instead of key strokes on a keyboard. Example: The character ‘A’ (ASCII code 65) should be sent to the host. Following sequence is executed: - Press ALT key - Press key ‘6’ on the numeric keypad - Release key ‘6’...

  • Page 18: Installing Scripts

    Elatec GmbH 5.6 Installing Scripts In order to install a script on a TWN3 device, perform following actions: Select the tab folder “Scripting”. • Select a script file (extension “.twn.c”) by clicking the button “Select Script”. • Click the “Compile Script”. This will start the script compiler.

  • Page 19: Miscellaneous Settings

    The compiled script is now part of the configuration within TWNConfig. Some additional information is displayed on how much storage space is occupied by this script. Up to now, the script has not been saved to the TWN3 device. 5.7 Miscellaneous Settings Within the tab folder “Misc”, there is only one setting, which influences the behavior on how a carriage...

  • Page 20: Updating The Firmware

    After any successful connection to a TWN3 device, the current directory will be searched for firmware images, which are compatible to the connected device. In order to re-program the firmware of a TWN3 device, click the “Program”-button. After successful programming, the following screen should be...

  • Page 21: Preferences

    Activating the checkbox “Slow down start of boot loader on HID keyboard devices” will do a • somewhat slower activation of the boot loader of a TWN3 device. This may prevent from problems in activating the boot loader, which have been seen on specific PCs.

  • Page 22: Export And Import Of Configurations

    TWN3 devices in the same way: Note: It is not possible to read the secret area from a TWN3 device. To save a configuration • including their secrets, you have to compile the appropriate script, which defines these secrets.

  • Page 23: Installing Usb-Drivers For Configuration

    Elatec GmbH 5.11 Installing USB-Drivers for Configuration If the USB TWN3 reader is configured the first time, USB drivers for the configuration mode have to be installed. Here are the steps to do so: Once you have clicked the “Connect”-button within TWNConfig.exe the first time, the following •...

  • Page 24: Transparent Mode

    Elatec GmbH You are now ready to configure the TWN3 reader. Note: If the TWN3 reader is plugged into a different USB port of the host computer, this installation procedure has to be repeated. 6. Transparent Mode Once a TWN3 device has been turned into transparent mode, a direct link will be established between the serial interface (V24 or virtual USB), and the reading module.

  • Page 25: Hid Prox Transparent Protocol

    6.1 HID Prox Transparent Protocol Due to the fact, the TWN3 HID Prox performs read access only, there are no commands available, which can be sent to the reading module. The data received from the module is formatted as follows: If a transponder is read, a ASCII string is sent which is terminated by carriage return.

  • Page 26: Scripting

    7.1.1 Source Code The source for a TWN3 script is given as a text file. Due to closeness to the language C, the extension should be “.c”. Doing so will give the advantage of a working syntax highlighting in many programming editors.

  • Page 27: Include Directive

    Elatec GmbH 7.1.4.1 #include Directive Include another source file and treat it as a part of the compiled source. There are two possibilities: #include <sys.twn.h> Include the given file, which is located relative to the directory, where TWNConfig.exe resides. #include “mydefs.twn.h”...

  • Page 28: Function Main

    Elatec GmbH 7.1.5.4 Function main A TWN3 script always needs the function main to be implemented. The prototype for the function main void main(); After internal initialization, the TWN3 reader will start execution of the script by calling this function main.

  • Page 29: For Statement

    Elatec GmbH 7.1.6.5 for Statement A for statement has the form: for ([expression1]; [expression2]; [expression3] statement As first step, expression1 is evaluated. As long as expression2 is not equal to zero, statement is executed. After execution of statement, expression3 is evaluated. Therefore, a for statement can be rewritten as while statement with exactly the same behavior: expression1;...

  • Page 30: Return Statement

    // Waste some time and do ten times nothing 7.1.7 Storage Types In the TWN3 scripting language, there is only one type of storage defined, which is the byte. A byte is an unsigned integer with a size of 8 bits.

  • Page 31: Storage Classes

    The secret data space is a read-only segment. The content of this segment is written once during programming the script into the TWN3 transponder reader. Furthermore, this segment can not be read directly by the script itself. Therefore, there is no way to simply read the content of this memory and send it to the host.

  • Page 32: Operators

    Elatec GmbH 7.1.9 Operators Following operators are available: Operator Meaning Example A = B * (C + D) Parenthesis A = B[C] Brackets Logical Not A = !B A = ~B Bitwise Complement A = -B Unary Minus A = +B...

  • Page 33: Runtime Environment

    7.2 Runtime Environment 7.2.1 Include File The file sys.twn.h declares all constants and system function prototypes, which are necessary for accessing the TWN3 transponder reader functionality. It is strongly recommended to include this file in any TWN3 script: #include <sys.twn.h>...

  • Page 34: System Function Calls

    Elatec GmbH 7.2.5 System Function Calls 7.2.5.1 Transponder Operations Following constants are defined for the various types of transponders which can be read by the family of TWN3 transponder readers: TWN3 Type Transponder Types TAGTYPE_EM4102 Multi125 TAGTYPE_HITAG1S TAGTYPE_HITAG2 TAGTYPE_EM4150 TAGTYPE_ISOFDX...

  • Page 35: Generally Available Transponder Operations

    Elatec GmbH 7.2.5.1.1 Generally Available Transponder Operations byte TagSearch(byte &IDData, byte &IDBitCnt, byte &TagType) Search a transponder. This function behaves similar on different types of transponder readers, but not identical. Parameter: Reference to a bit field (in fact an array of bytes), which receives the ID byte &IDData...

  • Page 36: Multi125-Specific Transponder Operations

    Elatec GmbH byte TagWrite(byte Address, byte ByteCnt, byte &Data) Write data to a selected transponder. Parameters: The address within the address space of the transponder. byte Address Number of bytes to write. byte ByteCnt Reference to an array of bytes to be written.

  • Page 37: Mifare- And Multiiso-Specific Transponder Operations

    Elatec GmbH 7.2.5.1.3 Mifare- and MultiISO-Specific Transponder Operations For TWN3 Mifare and TWN3 MultiISO, there are identical functions available, which directly communicate with the built-in module: byte MifareLogin(byte &Secret, byte KeyType, byte Sector) In order to do any operations on a sector of a Mifare transponder, a login has to be performed.

  • Page 38: Legic Specific Operations

    If the operation was successful, the return value is TRUE, otherwise it is FALSE. Please note, that TXData and RXData do contain a telegram without length byte and LRC or CRC. This information is calculated by the firmware of the TWN3 reader. Page 38 of 50...

  • Page 39: Hid Iclass Specific Operations

    7.2.5.1.5 HID iClass Specific Operations byte IClassGeneric(byte &TXData, byte TXCount, byte &RXData, byte RXCount, byte Timeout) Send a specific command to the built in module of a TWN3 HID iClass. Parameters: Reference to an array of bytes which contains the command to be sent byte &TXData...

  • Page 40: Functions For Host Communication

    Elatec GmbH 7.2.5.2 Functions for Host Communication void HostSendVersion() Send version information of the firmware to the host. This information is sent without a carriage return. Therefore, it is possible to append some more information, i.e. the version of the script, which is currently executed.
  • Page 41 Elatec GmbH HostSendHex(ID,8,5); // Result is 00012 HostSendHex(ID,13,5); // Result is 00246 void HostSendDec(byte &Data, byte BitCnt, byte Width) Convert a number, which is given as a bit field into decimal ASCII format, and send it to the host. Parameters: A reference to an array of bytes, which contains the bit field byte &Data...

  • Page 42: Accessing Leds

    Elatec GmbH 7.2.5.3 Accessing LEDs void LEDSet(byte LEDs, byte Status) Set the state of the red and/or the green LED. Parameters: Binary or of the LEDs to be switched. The green LED is represented by byte LEDs the constant GREEN, the red LED is represented by the constant RED.

  • Page 43: Accessing The Beeper

    Elatec GmbH 7.2.5.4 Accessing the Beeper void SetVolume(byte Volume) Set the volume of the beeper. Parameter: A value between 0 (beeper turned off) and 4 (maximum volume). byte Volume Return: None. void Beep(byte Type) Sound some type of beep. Parameter:...
  • Page 44 Elatec GmbH void CopyBits(byte &DestBits, byte StartDestBit, byte &SourceBits, byte StartSourceBit, byte BitCount) Copy bits from a source to a destination. Source and destination may be identical and the source section may overlap the destination. Depending on that, the correct method for copying will be chosen.

  • Page 45: Byte Operations

    Elatec GmbH 7.2.5.6 Byte Operations byte CompBytes(byte &Data1,byte &Data2,byte ByteCount) Compare two byte arrays. Parameters: Reference to an array of bytes. byte &Data1 Reference to an array of bytes. byte &Data2 Number of bytes (beginning from index 0) to be compared.

  • Page 46: Timer Operations

    Elatec GmbH byte ScanHex(byte &Data, byte ByteCnt) Convert an array of bytes containing ASCII characters which represent hexadecimal numbers into their binary representation. The conversion is done in place. This means that after successful conversion, number of valid is half of the given count of ASCII characters (two hex digits represent one binary byte).

  • Page 47: Retrieving System Information

    The TWN3 reader is connected via a USB cable to USB: the host byte GetUSBMode() Retrieve the information if the TWN3 reader is emulating a keyboard or if it is emulating a virtual COM port. Parameter: None. Return: Either one of the defined constants: The TWN3 reader is emulating a virtual COM port.

  • Page 48: Firmware History

    8. Firmware History Version Changes V4.02 Initial release • V4.07 Send ALT codes • Support for TWN3 IndiTag • Support for TWN3 MultiISO • New functions regarding Mifare (identical to • MultiISO): ModuleSendChar, ModuleSendHexByte and ModuleReceiveLine New functions regarding HID iClass: •...

  • Page 49: Regulatory Information

    Elatec GmbH 10. Regulatory Information 10.1 CE Declaration of Conformity This product conforms to the following standards: ETSI EN 300330-1 V1.3.1 / ETSI EN 300330-2: V1.3.1 • ETSI EN 301489-1: V1.6.1 / ETSI EN 301489-3: V1.4.1 • DIN EN 55022: 2007-04 class B / DIN EN 55024: 2003-10 •...

  • Page 50: Ci (Canada Industry) Statement

    Elatec GmbH 10.3 CI (Canada Industry) Statement This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB- 003 du Canada. Operation is subject to the following two conditions:...
