Register - Dahua VTA2302A Quick Start Manual

Parameter
Type
All Device Ports
Device Start Sever
Port
Device End Sever
Port
4.
Click Confirm.

3.5.3 Register

The Terminal registers to the proxy server designated by the user, and then the proxy server
provides the transfer function to facilitate the client software to access the Terminal, so as to
watch live view and monitor the scene.
Select Network > Register on the web interface.
Select the Enable check box, and then set parameters.
Parameter
IP Address
Port
Device Register ID
Click Save.
Table 3-6 Firewall parameters description
Description
Select IP Address, IP Segment, MAC Address or All IP Addresses.
IP Address: Select the IP version, and then enter the IP address
to be added.
IP Segment: Select the IP version, and then enter the Initial IPv4
Address, and End IPv4 Address.
MAC Address: Enter the MAC address to be added.
All IP Addresses: Set all IP addresses to the white list or black
list.
Set access ports. You can select all device ports, or set the port range.
All Device Ports: Set all ports of the Terminal to the black list or
white list. When all IP addresses are set to the black list, you are
not allowed to select all ports. Because in this case, all devices
cannot access all ports of the Terminal.
Device Start Sever Port/Device End Sever Port: Set the start
port and end port. The value ranges from 1 to 65535.
Click Save.
The system goes back to the Firewall interface.
Table 3-7 Register parameter description
Description
The IP address or domain name of the server that the Terminal is
registered to.
The sever port for registering.
Customize the register ID for the Terminal.
Register
20
