Tone TOUCH 03 Original Instructions Manual

Hide thumbs Also See for TOUCH 03:
Table of Contents

Advertisement

Quick Links

T O U C H 0 3
03
ORIG INA L I NSTRUCT IONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOUCH 03 and is the answer not in the manual?

Questions and answers

Related Manuals for Tone TOUCH 03

Summary of Contents for Tone TOUCH 03

  • Page 1 T O U C H 0 3 ORIG INA L I NSTRUCT IONS...

  • Page 2: Table Of Contents

    08 | General terms for safe use / Initial Set-Up 09 | Machine overview 10 | Button functions 11 | Button functions 12 | Connecting the TONE Touch 03 13 | Connecting the TONE Touch 03 14 | Edit recipes 15 | Edit recipess...

  • Page 3: Dimensions

    Dimensions...

  • Page 4: General Instruction

    The user shall arrange electric, water and draining systems in a suitable position to allow correct machine installation. The installer of TONE devices is not responsible for making modifications to existing water and power connections in the customers facilities. If the electric supply cable is damaged, it must be replaced by another cable provided by the manufacturer or by its Technical Service.

  • Page 5: Installation Instruction

    Installation instruction CAUTION Power to brewer must be OFF before proceeding with plumbing installation. Ethernet connection cable Cold Water | Softener Powercord P | N | GR CAUTION Improper electrical installation will damage electronic components. Damage caused by incorrect electrical connections in not covered by warranty.

  • Page 6: Plumbing Connection

    The pressure of the water line must be within 1.5bar – 3bar. The installation of a water softening filter system is mandatory for the use of TONE equipment. Any violation of this regulation will lead to a complete loss of any warranty on the complete system.

  • Page 7: Electrical Connection

    Electrical connection WARNING: The brewer must be disconnected from the power source until specified in INITIAL SET-UP. CAUTION – Improper electrical installation will damage electronic components. Damage caused by incorrect electrical connections is not covered by warranty. An electrician must provide electrical service as specified in conformance with all local, state and federal electrical codes.

  • Page 8: General Terms For Safe Use / Initial Set-Up

    General terms for safe use / Initial Set-Up This machine is only intended for the use for which it was basically developed. Any other use shall be considered ill-suited and improper. The manufacturer shall not be considered responsible for any damages caused by improper use.

  • Page 9: Machine Overview

    Machine overview COMPONENTS TOUCH 03 1 | power switch (on back side) 2 | four programmable buttons for recipe selection 3 | spray head 4 | support for smaller brewing vessels 5 | drip tray...

  • Page 10: Button Functions

    Button functions Recipe selection: Button 1 – 4 (from left to right) Descaling: Push and hold Button 1 while switching the main switch ON Rinsing: Push and hold button 1 & 2 while switching the main switch ON. Stop the rinsing by switching the main switch OFF ->...
  • Page 11 Wait until the recipe is processed completely (button stops to blink). Remove the brewing vessel from the appliance and the TONE TOUCH 03 is ready for use again immediately. The program can be aborted by pushing the chosen button again during process.

  • Page 12: Connecting The Tone Touch 03

    TABLET computer (#650308) -> connect the TONE to the LAN-2-USB converter -> connect the TABLET to the LAN-2-USB converter -> only one TONE can be connected to the TABLET Option 2a WiFi-Router You need a WiFi router (#650310)
  • Page 13 -> connect the TABLET to the WiFi router. The password to unlock the tablet is “tone”. Configuring of the USB-C adapter (Gigabit Ethernet) for other device than TONE Tablet Connecting the adapter with your device Control panel -> Network and Internet -> Network and Sharing Center -> Change adapter settings ->...

  • Page 14: Edit Recipes

    Connect your TONETouch03 brewer with the TONE tablet computer as described in the previous section. Once the installation is complete, switch your TONE Touch 03 ON and it will appear in the list of available TONE equipment on the left side of the Touch03 tab. The factory pre-set name will be ToneTouch03_XXXXX (XXXXX=serial number).
  • Page 15 For the coffee recipes, the brewing temperature and the pulsation of the water flow is pre-defined, based on the experience of TONE coffee experts. You can simply adjust the amount of water (click or click and hold on the arrows) and choose between cone and flat filters. Make sure you have installed the correct spray head insert for...
  • Page 16 Edit recipes Click on the save button and your recipe will appear on the recipe list. The name of the recipe tells you the strength of the coffee, the amount of water and the applied filter type. The settings of the tea recipes are slightly different. Choose the water temperature considering the type of tea which shall be prepared.
  • Page 17 The name of a tea recipe will tell you the strength of the flavour, the amount of water and the brewing temperature. See below a list of sample recipes for each pre-set button. When a recipe is no longer needed, you can delete it in this window by clicking “delete recipe”.
  • Page 18 Edit recipes...
  • Page 19 Your set then appears on the set list on the right side of the window. This list will be displayed when you click on the set bar in the Touch 03 tab. Set which are not needed anymore can be deleted by clicking on “delete set”.

  • Page 20: Advanced Tab

    Advanced tab The Advanced tab provides you a very intuitive and comprehensive tool for the creation of new recipes. You can set the temperature of each extraction phase (bloom, turbulence, development) and define the characteristics of the water pulses (quantity, flow ratio, duration, interval). Just drag the blue points in the corner of the pulses into the desired position.
  • Page 21 Once you have completed your recipe, you can save it by clicking “save recipe”. It will then appear in the selec- tion lists in the Touch 03 and Sets tabs. The name of advanced recipes will be marked with ad at the beginning, followed by a description, the weight and the intended filter type.

  • Page 22: Service Tab

    Service tab The Service tab provides possibilities to customise the brewer identification and the calibration. And you can also check all important paramters. Clicking on the service tab will automatically open a login pop-up window. Entering the password “TONEservice” enables all available options. Select one of the brewers listed in the left column. Click on “update location info”, enter a meaningful description of your brewer and its location and confirm these entries by clicking “accept”.
  • Page 23 In case your brewer should extract more or less water than intended you can tweak the flow rate by setting a value below 1 in case you want to reduce the amount of water or a value above 1 if you want to increase to amount of water.

  • Page 24: Cleaning / Descaling

    DAILY CLEANING To guarantee proper functionality of TONE equipment it is necessary to clean the device on each day it was in use. To clean the surface of TONE equipment, it is recommended to use a damp cloth and mild customary detergent.

  • Page 25: Warranty

    OR REFUND. In no event shall TONE Kaffeemaschinen AG be liable for any other damage or loss, including, but not limited to, lost profits, lost sales, loss of use of equipment, claims of Buyer’s customers, cost of capital, cost of down time,...

  • Page 26: Touch 03 - Wiring

    TOUCH 03 - Wiring WIRING DIAGRAM Blackbox Deckelblech braun Durchlauferhitzer Heizung_HIGH 2400W braun schwarz gelb grün hellblau schwarz schwarz schwarz gelb Heizung_LOW grün 1000W braun hellblau schwarz gelb E-fast grün schwarz gelb grün VALVE_P schwarz schwarz gelb/grün braun VALVE_2 Option...

  • Page 27: Technical Data / Declaration / Contact

    TONE Kaffeemaschinen AG Rheinweg 4 8200 Schaffhausen Switzerland +41 52 620 06 06 hello@tone-swiss.com TONE technical service : (CET /UTC+1) service@tkm.coffee Manual version v1.0 | release 01.05.2020 This manual is based on TONE TOUCH 03 Beverage Manager Software v1.0 and brewerbuild v.1.0...
  • Page 28 TONE Kaffeemaschinen AG Rheinweg 4 8200 Schaffhausen Switzerland +41 52 620 06 06 hello@tone-swiss.com www.tone-swiss.com...
