- Page 1 TOUCH DIGITAL MANUAL Please download software here JANUARY 2024 Get in touch with your dealer for VERSION 1.0 any information about installation. OP ERATIN G MANUAL...
- Page 3 TONE product, or damage to other objects in the vicinity. This document and all other collateral documents are subject to change at the sole discretion of TONE.
-
Page 5: Table Of Contents
TABLE OF CONTENS 1. PROPER USE For your safety Explanation of safety warnings 2. DESCRIPTION OF THE PRODUCT Purpose of the Product Contents Appliance overview Dimensions 3. INITIAL USE Place of use Plumbing Connection Electrical Connection Initial set-up 4. PROCESS/WORKFLOW Brewing Startup modes Connection... -
Page 6: Proper Use
PROPER USE 1. PROPER USE INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN This machine is only intended for the use ACCORDANCE WITH EC for which it was basically developed. Any DIRECTIVE 2012/19/EU other use shall be considered ill-suited and improper. - Page 7 contact a local Technical Service that has ▪ Do not put the appliance under a jet of been authorized by the manufacturer. water, nor plunge it into water to clean it. ▪ Do not leave the appliance turned-on and WARNING DUE TO unattended for long periods (e.g.
-
Page 8: Description Of The Product
DISCRIPTION OF THE PRODUCT DO NOT USE WATER JET DEVICES IN THE AREA WHERE TOUCH 04 IS INSTALLED! DO NOT TILT TOUCH 04 DURING OPERATION! MAX. TILT ANGLE < 5°. ONLY TO BE OPERATED BY TRAINED PERSONNEL! 2. DESCRIPTION OF THE PRODUCT 2.1 Purpose of the Product... -
Page 9: Dimensions
DIMENSIONS CAUTION Improper electrical installation will damage electronic components. Damage caused by incorrect electrical connections is not covered by warranty. CAUTION Power to brewer must be OFF before proceeding with plumbing installation. 2.4 DIMENSIONS Ethernet connection cable Cold Water | Softener Powercord P1/P2 | N | GR... -
Page 10: Initial Use
INITIAL SET-UP 3. INITIAL USE ▪ The installation of a water softening filter system is mandatory for the use of TONE equipment. Any violation of this regulation 3.1 PLACE OF USE will lead to a complete loss of any warranty on the complete system. -
Page 11: Initial Set-Up
▪ Remove the cover from the housing. ▪ Connect the blue water hose with the 4. PROCESS/WORKFLOW Touch 04 and your water supply. (Note: The TONE Touch 04 needs to be run with 4.1 BREWING filtered water, check water specification on page 26 ). -
Page 12: Startup Modes
BREWING appliance and the TONE Touch 04 is ready 1. Button 1 pressed: Water flushes through for use again immediately. The program can bypass and only through flowmeter 2. Button 2 pressed : Water flushes through be aborted by pushing the chosen button again during process. - Page 13 When (direct or via LAN-2-USB converter) button 1 lights up blue, it signals that the ▪ you can connect one or more TONE to the movable locking element has reached the tablet / pc lower sensor.
-
Page 14: Edit Recipes
TONE simply enter how much ground coffees you Touch 04 ON and it will appear in the list of are using (ratio), the total amount of water available TONE equipment as soon you select that hits the coffee, select a dilution in % or the tab Touch 04. -
Page 15: Create Set
EDIT RECIPES trash bin and selecting the recipe(s) you no longer need. Then click on the green hook to delete. Enter the desired recipe name and click the save button. Your recipe will appear on the recipe list. 4.4.2 CREATING SETS It can be decided in advance whether the set is to be made for brewing profiles or for water profiles. -
Page 16: Advanced
ADVANCE Press “select set” and select the desired set When you have finished your recipe, you can in the corresponding category. If you press save it by giving the recipe the desired name “edit set” you can change one specific set or and select whether it is a tea or coffee recipe. -
Page 17: Water
SERVICE 4.4.4 FREESTYLE The freestyle chapter provides a way to Import create a recipe entirely without restrictions or frameworks. Select the button if you want to import a As a first step, you can define the number of new recipe (sent to you from somewhere pulses (maximum 20) using the + and - keys. -
Page 18: Error Codes
▪ Cables on top of the heater are achieve good brewing results. disconnected. Please also remark that the boiling point of water drops with increasing altitude (≈ Save the current recipes on the machine -1°C/300m). via the TONE Beverage Manager. - Page 19 CONNECTING Buttons 2 & 4 light up blue. Do a reboot by pushing 1/3/4 and switch ON the main switch (this will delete the current ▪ Proportional valve is leaking. recipes on the machine). Turn the machine off and on again. 1.
-
Page 20: Maintenance
5.2 DAILY CLEANING ▪ Do not use water jet device to clean the TONE equipment. ▪ Do not use abrasive means to clean the TONE equipment. Blue chasing light (Button 1-4) after switching the brewer ON and after finish- ▪... - Page 21 TECHNICAL DATA STEP 1 STEP 9 Remove the cover from the The TONE Touch 04 is then ready again for brewing excellent coffee. TONE Touch 04. STEP 2 Before the descaling process is started, a vessel with a minimum volume of one liter must be placed underneath the shower.
-
Page 22: Fault Rectification
3. Please, contact your 1/3/4 and main switch machine). dealer if there is No recipes visible on together. and issue. the keys (TONE-App) 3. Update the machine with the actual firmware. 4. In case of any other issues, please contact your dealer. - Page 23 -> Proportional 1. Check the valve is leaking 2. Please, contact your regulations of your dealer. firewall for the TONE app. 2. Select the automatic mode 1. Switch the brewer in the ethernet Buttons 2 & 3 & 4 OFF and let it cool properties.
-
Page 24: Technical Data
EEC CONFORMITY DECLARATION ACT The electrical ratings can be found on 2006/42/EC the type plate which you will find on the The undersigned: TONE Kaffeemaschinen device. AG with premises at: Kasernenstraße 5, 3600 Thun, Switzerland Declares that: The coffee machine has been... - Page 25 TONE chlorine and non periodic cleaning and Kaffeemaschinen AG Authorized Service descaling. Warranty is null and void if Representative;...
-
Page 26: Wiring Diagram
LRP AG File Document \\abon\D ... Aufbau_TONE04_060224 - Kopie.dsn 250111 Revision Date Sheets 05.02.2024 2/22 11. TONE WATER SPECIFICATION Recommended water parameters for TONE TOUCH 04 above this values a VALUE UNITS MINIMUM MAXIMUM decarbonation is necessary Conductivity/T.D.S µS Total Hardness °dH... - Page 27 Required water pressure : 3-4 bar / 0.3-0.4 MPa (40-60 psi / 300-400 kPa) IRON: Iron is regulated via the drinking water ordinance with 0.2 mg/L. CHLORINE: Even small amounts of chlorine can lead to a change in taste. CARBONATE HARDNESS: Depending on the coffee; recommendation: individual tasting during set-up and subsequent fine-tuning of the filter blend, as the KH has the greatest influence.
- Page 28 TONE Kaffeemaschinen AG Kasernenstrasse 5 3600 Thun Switzerland contact@tone-swiss.com www.tone-swiss.com Download all TOUCH 04 brewer documents here for a quick and easy start: A printed version can be ordered at service@tone-swiss.com.
