INTRODUCTION
Read this manual carefully as it offers practical advice to help you get the most from your
washing machine.
1.- CONTROL PANEL
2.- LID
3.- DRUM
4.- DETERGENT COMPARTMENT
5.- FILTER DOOR
6.- FILTER
When contacting a CANDY or one of its Technical Assistance Cen-
tre always refer to the model (see control panel) and the registration
and series numbers which are indicated at the bottom of the machine
under the lower panel or on the warranty certificate. That is to say,
everything that appears in the box.
Providing this information will ensure a faster and more efficient service.
This Instruction Manual
contains everything you need
to know about the everyday
running of your machine.
Keep it for future reference.
An
Maintenance Manual is also
provided which you should
consult during the installation
and routine maintenance of
your washing machine. The
manual
information about possible
working problems, advice
about the wash load, an
explanation of label symbols
and hints about how to remove
stubborn stains.
39
EN
Installation
and
also
contains

Advertisement

loading
Need help?

Need help?

Do you have a question about the CTE 104 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Candy CTE 104

  • Page 1 5.- FILTER DOOR 6.- FILTER When contacting a CANDY or one of its Technical Assistance Cen- tre always refer to the model (see control panel) and the registration and series numbers which are indicated at the bottom of the machine under the lower panel or on the warranty certificate.
  • Page 2: Table Of Contents

    INDEX page GUARANTEE ................41 TECHNICAL DATA ............... 42 OPENING THE LID – LOADING ..........43 DETERGENT DISPENSER ............44 AUTOMATIC VARIABLE CAPACITY - FUZZY LOGIC ELECTRONICS ................45 PROGRAMME SELECTION ............45 CONTROL DESCRIPTION ............46 TABLE OF PROGRAMMES ............50 Place the attached «program label»...
  • Page 3: Guarantee

    GUARANTEE The appliance comes with a guarantee certificate. Complete part A and keep it in a safe place. It should be presented to the Technical Assistance Centre in the event of a repair being necessary along with the legal receipt issued by the dealer on purchase.
  • Page 4: Technical Data

    TECHNICAL DATA CTE 104 Load capacity ................ kg. Voltage ..................V. Wash motor power rating ............W. Spin motor power rating ............W. Electropump power rating ............W. Heating element power rating ..........W. 1.950 Max. power input ..............W.
  • Page 5: Opening The Lid - Loading

    OPENING THE DRUM Lift the lid ( A ) and open it completely. Next, open the drum door following these instructions: Place your hand on the rear door ( D ). Hold the catch ( B ) down. Press the front door ( C ) to unlock the two doors ( C and D ).
  • Page 6: Detergent Dispenser

    DETERGENT DISPENSER The detergent dispenser is divided into 4 compartments: • Compartment I, is for prewash powder detergent. The recommended quantity is 60 gm of detergent (for 5 kg of laundry). • Compartment II, is for wash powder detergent. The recommended quantity is 120 gm of detergent (for 5 kg of laundry).
  • Page 7: Automatic Variable Capacity - Fuzzy Logic Electronics

    AUTOMATIC VARIABLE CAPACITY – FUZZY LOGIC ELECTRONICS This machine has electronics that automatically process all stages of the wash to ensure exceptional results and at the same time save you time and money. Once a programme has been selected, the machine optimises the following elements depending on the wash load and type of fabric: - quantity of water and power consumption - wash time...
  • Page 8: Control Description

    CONTROL DESCRIPTION CTE 104 Programme selector knob ............Temperature selector knob ............Spin selector ................Easy-iron button ................. Super rinse button ..............ON/OFF pilot light ............... ON/OFF button ................Reference indicator ..............
  • Page 9 USE OF THE SELECTION CONTROLS . PROGRAMME SELECTOR KNOB This control allows you to select the washing programmes. Turn the selector so that the number or symbol of the desired programme is opposite the reference indicator (p). ALWAYS ROTATE the control in a clockwise direction, never in an anticlockwise direction.
  • Page 10 USE OF THE SELECTION CONTROLS . EASY IRON BUTTON This function helps reduce creasing, depending on the programme selected and the type of fabric washed. MIXED FABRICS: - the water is cooled gradually to prevent heat shock - the drum is not moved mechanically during emptying - a mild spin is used to ensure that fibres are smoothed out as much as possible.
  • Page 11: Table Of Programmes

    TABLE OF PROGRAMMES CTE 104 DETERGENT BUTTON LOAD SEL. TYPE OF PROGRAMME FOR FABRIC ºC From cold • 32´ Rapid 32 minute super cycle RAPID PROGRAMME to…50º From cold • • • • • INTENSIVE WITH PREWASH to…90º From cold •...
  • Page 12 NOTE: 1. If the wash load is very dirty it is best to reduce the load weight to 3 kg. 2. Programmes 1-2- have an automatic bleaching option. Simply place the bleaching agent in the compartment. 3. The washing machine is designed to incorporate fabric softener automatically in the last rinse of each washing cycle.
