- Page 1 FRONT LINKAGE MX R05N MX R08N User Manual Please read carefully before using MX front linkage EN 368483 AD -0919 Translation of the original manual...
- Page 3 The front linkage user manual before you is an important document, please retain it in order to be able to refer to it if required. Make it available to any other users and hand it over it to any new owner in the event of your MX front linkage being sold on.
-
Page 4: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS OPERATING REQUIREMENTS SAFETY STICKERS IDENTIFICATION PLATE DESCRIPTION SETTING FRONT LINKAGE TO OPERATING POSITION HITCHING A FRONT IMPLEMENT UNHITCHING A FRONT IMPLEMENT SETTING FRONT LINKAGE TO TRANSPORT POSITION 10. FRONT POWER TAKE-OFF WITH TRANSMISSION SHAFT* 11. HITCHING TRIANGLE* 12. - Page 5 The operator must read this manual before using the machine for the first time. Familiarise yourself with: — Safety rules and operating requirements. — Hitching and unhitching an implement. — Full use of the controls. Subject to modifications • 19, rue de Rennes • BP 83221 • F - 35690 ACIGNÉ...
-
Page 6: Safety Instructions
— The tractor – linkage combination must only be operated by trained and experienced personnel. — When the tractor is fitted with a front linkage and front-end loader, the user is required to unhitch the loader before using the MX front linkage (please refer to the loader user manual for the unhitching procedure). -
Page 7: Operating Requirements
Caution! Requirements for implement hitching and for working on the ground must be strictly complied with. Any deviation from the requirements risks causing serious damage for which MX cannot be held liable. Subject to modifications • 19, rue de Rennes • BP 83221 • F - 35690 ACIGNÉ... -
Page 8: Safety Stickers
3. SAFETY STICKERS A safety sticker is affixed to the front linkage. Keep it readable and clean; replace it if damaged. 4. IDENTIFICATION PLATE The identification plate is located on the right-hand side of the front linkage frame. The serial number and front linkage model shown on this plate must be quoted in any request for spare parts information or technical assistance. -
Page 9: Description
5. DESCRIPTION Right-hand arm Left-hand arm Linkage frame Towing clevis (use a 30 mm diameter pin) Frame 3rd link bar Safety clip Roll cage clip Arm locking Subject to modifications • 19, rue de Rennes • BP 83221 • F - 35690 ACIGNÉ... -
Page 10: Setting Front Linkage To Operating Position
6. SETTING FRONT LINKAGE TO OPERATING POSITION Caution This operation must be carried out by the driver who must leave his seat and ensure all controls are locked out while he is working on the front linkage. 6.1 Choose a level and solid surface. The tractor engine is to be turned off and the hand brake applied. 6.2 ... - Page 11 6.4 Swing the arms forwards up to the desired position. 6.5 Refit the pin and secure it with the locking pin. 6.6 Repeat operations 6.2 to 6.5 for the right-hand arm. 6.7 Open the stop valve. Closed Fermé Open Ouvert Subject to modifications •...
-
Page 12: Hitching A Front Implement
7. HITCHING A FRONT IMPLEMENT Caution This operation must be carried out by the driver who must leave his seat and ensure all controls are locked out while he is working on the front linkage. The linkage is in the operating position. 7.1 Open the locking catches on the hitching hooks and hitch up the implement. -
Page 13: Unhitching A Front Implement
7.4 Set the length of the 3rd link bar to obtain the desired geometry for the front implement. Lock the adjustment of the bar by means of the lever locknut. Checks to be carried out before starting work — Carry out a lift test checking that the tractor and front implement interact correctly. Pay particular attention to checking the gap between the upper link bar and the bonnet of the tractor. -
Page 14: Setting Front Linkage To Transport Position
8.3 Reposition the 3rd link bar on to the front linkage frame. 8.4 Unlock the hitching hooks and lower the linkage arms to release the implement. 9. SETTING FRONT LINKAGE TO TRANSPORT POSITION Caution This operation must be carried out by the driver who must leave his seat and ensure all controls are locked out while he is working on the front linkage. - Page 15 9.2 Shut the isolator valve. Closed Open Fermé Ouvert 9.3 Remove the locking pin while holding the left-hand arm. 9.4 Swing the left-hand arm rearwards and refit the pin and locking pin. 9.5 Repeat operations 9.3 to 9.4 for the right-hand arm. Subject to modifications •...
-
Page 16: Front Power Take-Off With Transmission Shaft
10. FRONT POWER TAKE-OFF WITH TRANSMISSION SHAFT* SAFETY RULES AND RECOMMENDATIONS IN RESPECT OF POWER TAKE-OFF — Never start the engine with the power take-off engaged. — Before hitching the implement, check that the direction of rotation for the implement is compatible with the front power take-off. -
Page 17: Hitching Triangle
12.1 Connect the hydraulic hoses of the implement to the 3/8" female couplings. Release the pressure from the hydraulic system to make the connection of the hoses easier. 12.2 Operate the hydraulic line using the tractor or the MX control valve. (Refer to the "Control" section). * Depending on configuration Subject to modifications •... -
Page 18: Control
Using the factory-fitted control valve on the tractor. Refer to the user manual for the tractor. 13.1 Using the MX loader control valve. 13.1.1 R aising and lowering the MX front linkage. Move the MX monolever handle forwards or backwards. 13.1.2 O perating the auxiliary hydraulic line (depending on configuration). -
Page 19: Maintenance
After the first 50 hours and every 500 tractor operating hours thereafter (or once a year): — Drain the oil and replace the filter with a new genuine MX one (see filter removal procedure below). — Next, refill the housing with oil up to the level shown opposite. Recommend oil type STOU (Supper Tractor Oil Universal) 10W30 or 10W40 or equivalent. -
Page 20: Technical Specifications
15. TECHNICAL CHARACTERISTICS R05N R08N Front linkage category Lifting capacity at the end of the linkage arms* 500 kg 800 kg Lifting capacity with the centre of gravity of the implement positioned 610 mm 300 kg 550 kg forward of the ball ends* Theoretical arm spacing 365 mm 365 mm... - Page 21 DECLARATION OF CONFORMITY The manufacturer: Mailleux SAS Registered office: 19, Rue de Rennes, 35690 Acigné (France). Registered with the RCS of Rennes under number 639 200 260. Hereby declares that the material : Front loader T406 or T406+ or T408 or T408+ or T410 or T410+ or T412 or T412+ or T414 or T417 or T418 or TX420 or TX425 or TX430 Front loader U403 or U404 or U405 or U406 or U406+ or U407 or U408 or U408+ or U409 or U410 or U410+ or U412 or U412+ or U414...
- Page 24 19, rue de Rennes BP 83221 F - 35690 ACIGNÉ Tel.: +33 (0)2 99 62 52 60 Fax: +33 (0)2 99 62 50 22 E-mail: contact@m-x.eu...
