Summary of Contents for Billion BiPAC 7300M
- Page 1 BiPAC 7300M 802.11g MIMO ADSL2+ Router Quick Start Guide...
-
Page 3: Package Contents
Avoid using this product and all accessories outdoors. Place the router on a stable surface. Only use the power adapter that comes with the package. Using a different voltage rating power adaptor may damage the router. Attention Billion BiPAC 7300M 802.11g MIMO ADSL2+ Router... -
Page 4: The Front Leds
Quick Start Guide The Front LEDs BiPAC 7300M PPP : ADSL: LAN Port: WLAN : SYS : PWR : Meaning Lit steady when there is a PPPoA / PPPoE connection. Lit when successfully connected to an ADSL DSLAM (“linesync”). Lit when connected to an Ethernet device. -
Page 5: The Rear Ports
Recovery) (RJ-45 connector) ADSL Billion BiPAC 7300M 802.11g MIMO ADSL2+ Router Connect the supplied power adapter to this jack. 1.After the device is powered on, press it to perform Failure recover for a dead routers: Simply hold the Emergency/Failure Recovery Button” when power on the routers and download the Application if necessary. - Page 6 Quick Start Guide Connecting BiPAC 7300M 1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network. 2. Power on the device. 3. Make sure the PWR, SYS, and WLAN LEDs are lit steadily and that the relevant LAN LED is...
-
Page 7: Configuring Pc In Windows Xp
Properties. 4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. Billion BiPAC 7300M 802.11g MIMO ADSL2+ Router... -
Page 8: Configuring Pc In Windows 2000
Quick Start Guide Configuring PC in Windows 2000 Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4. -
Page 9: Configuring Pc In Windows 98/Me
Network Interface Card (NIC) in your PC. 3. Select the Obtain an IP address automatically radio button. 4. Then select the DNS Configuration tab. 5. Select the Disable DNS radio button and click OK to finish the configuration. Billion BiPAC 7300M 802.11g MIMO ADSL2+ Router... - Page 10 Quick Start Guide Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.
- Page 11 1. Please wait when the connection is trying. 3. If login failed, Please input the correct username and password again. Billion BiPAC 7300M 802.11g MIMO ADSL2+ Router Easy Sign On (EZSO) 2.Enter the username and password provide by your ISP.
- Page 12 Quick Start Guide DHCP 1. Please wait when the connection is trying. Web Configuration: Open the web browser and type http://192.168.1.254 address box. This number is the default IP address for this router. Press Enter. 2. A username and password window will appear.
-
Page 13: Verifying Your Local Network Connection With The Device
Contact Billion AUSTRALIA http://www.billion.com.au ©2006 Billion Electric Co, PC Range P/L. All Rights Reserved. WORLDWIDE http://www.billion.com Mac OS is a registered Trademark of Apple Computer, Inc. Windows 98, Windows NT, Windows 2000, Windows Me and Windows XP are registered Trademarks of Microsoft Corporation.
