  • Page 2 Version 1.0 Published September 2020 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 AUSTRALIA ONLY Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage caused by our goods. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Motherboard Layout Front Panel Rear Panel Chapter 2 Installation Installing Memory Modules (SO-DIMM) Onboard Headers and Connectors Smart Switch M.2 WiFi/BT Module Installation Guide M.2_SSD (NGFF) Module Installation Guide (M2_1) Chapter 3 Software and Utilities Operation Installing Drivers Chapter 4 UEFI SETUP UTILITY Introduction...
  • Page 5 4.4.1 CPU Configuration 4.4.2 Onboard Devices Configuration 4.4.3 Storage Configuration 4.4.4 ACPI Configuration 4.4.5 Trusted Computing Tools Hardware Health Event Monitoring Screen Security Screen Boot Screen Exit Screen...

  • Page 6: Chapter 1 Introduction

    FP6D4-P1 Chapter 1 Introduction Thank you for purchasing FP6D4-P1 motherboard. In this documentation, Chapter 1 and 2 contains the introduction of the motherboard and step-by-step installation guides. Chapter 3 contains the operation guide of the software and utilities. Chapter 4 contains the configuration guide of the BIOS setup.

  • Page 7: Specifications

    1.2 Specifications Platform • 7.0-in x 5.7-in, 17.8 cm x 14.5 cm • Supports AMD FP6 Renoir • 3 Power Phase design • SOC Chipset • Dual Channel DDR4 Memory Technology Memory • 2 x DDR4 SO-DIMM Slots • Supports DDR4 3200/2933/2800/2666/2400/2133 non-ECC, un-buffered memory • Max.
  • Page 8 FP6D4-P1 Audio • Realtek ALC233 Audio Codec • 1 x Headphone/Headset Jack • 1 x MIC-In • PCIE x1 Gigabit LAN 10/100/1000 Mb/s • Realtek RTL8111H • Supports Wake-On-LAN • Supports Lightning/ESD Protection • Supports Energy Efficient Ethernet 802.3az • Supports PXE Front • 1 x Power Button...
  • Page 9 Hardware • CPU Temperature Sensing Monitor • CPU Fan Tachometer • CPU Quiet Fan (Auto adjust chassis fan speed by CPU temperature) • CPU Fan Multi-Speed Control • Voltage monitoring: CPU Vcore, VCCM, +5V, +3.3V • Microsoft® Windows® 10 64-bit Certifica- • FCC, CE tions...

  • Page 10: Motherboard Layout

    FP6D4-P1 1.3 Motherboard Layout Power Button USB 3.2 Gen1 T: USB_2 USB2.0 B: USB_1 USB 3.2 Gen1 T: USB_4 USB2.0 B: USB_3 USB 3.2 Gen1 B: USB3_TC_1 CPU_FAN1 USB 3.2 Gen1 T: USB_6 B: USB_5 SD Card RJ-45 BIOS FP6D4-P1...
  • Page 11 Back Side View...

  • Page 12: Front Panel

    FP6D4-P1 1.4 Front Panel No. Description No. Description SD Card Socket USB 2.0 Port (USB_3)* USB 3.2 Gen1 Type-C Port *Quick Charger Support (USB3_TC_1) USB 3.2 Gen1 Type-A Port (USB_2) USB 3.2 Gen1 Type-A Port USB 2.0 Port (USB_1) (USB_4)

  • Page 13: Rear Panel

    1.5 Rear Panel No. Description No. Description D-Sub Port LAN RJ-45 Port* HDMI Port DC Jack USB 3.2 Gen1 Type-A Port Headphone Jack (USB_5_6) Microphone Input * There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port...

  • Page 14: Chapter 2 Installation

    FP6D4-P1 Chapter 2 Installation This is a Proprietary form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 15: Installing Memory Modules (So-Dimm)

    2.1 Installing Memory Modules (SO-DIMM) This motherboard provides two 260-pin DDR4 (Double Data Rate 4) SO-DIMM slots. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4 slot; otherwise, this motherboard and SO-DIMM may be damaged. The SO-DIMM only fits in one correct orientation.

  • Page 16: Onboard Headers And Connectors

    FP6D4-P1 2.2 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. Serial ATA3 Connector...

  • Page 17: Smart Switch

    2.3 Smart Switch The motherboard has one smart switch: Power Button. Power Button Power Button allows users (SW1) to quickly turn on/off the (see p.7, No. 7) system.

  • Page 18: Wifi/Bt Module Installation Guide

    FP6D4-P1 2.4 M.2 WiFi/BT Module Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (Key E) supports type 2230 WiFi/BT module.
  • Page 19 Step 4 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module.
  • Page 20 FP6D4-P1 2.5 M.2_SSD (NGFF) Module Installation Guide (M2_1) The Ultra M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Ultra M.2 Socket (M2_1) supports type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s).
  • Page 21 M.2_SSD (NGFF) Module Support List Vendor Interface ADATA PCIe ADATA ASX7000NPC-512GT-C (XPG SX7000) (NVMe) ADATA PCIe ADATA ASX8000NPC-512GM-C (XPG ASX8000) (NVMe) Apacer PCIe Apacer Z280 AP240GZ280-240G (NVMe) Intel PCIe Intel Optane Memory 32GB (MEMPEK1W032GA)(NVMe) Intel PCIe Intel Optane Memory 16GB (MEMPEK1W016GA)(NVMe) INTEL PCIe INTEL 600P-SSDPEKKW256G7-256GB (NVMe)

  • Page 22: Chapter 3 Software And Utilities Operation

    FP6D4-P1 Chapter 3 Software and Utilities Operation 3.1 Installing Drivers The Support CD that comes with the motherboard contains necessary drivers and useful utilities that enhance the motherboard’s features. Running The Support CD To begin using the support CD, insert the CD into your CD-ROM drive. The CD automatically displays the Main Menu if “AUTORUN”...

  • Page 23: Chapter 4 Uefi Setup Utility

    Chapter 4 UEFI SETUP UTILITY 4.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. You may run the UEFI SETUP UTILITY by pressing <F2> or <Del> right after you power on the computer, otherwise, the Power-On-Self-Test (POST) will continue with its test routines.

  • Page 24: Navigation Keys

    FP6D4-P1 4.1.2 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter>...

  • Page 25: Main Screen

    4.2 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview.

  • Page 26: Oc Tweaker Screen

    FP6D4-P1 4.3 OC Tweaker Screen In the OC Tweaker screen, you can set up overclocking features. Because the UEFI software is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.
  • Page 27 DRAM Timing Configuration Voltage Configuration DRAM Voltage Configure the voltage for the DRAM Voltage. Save User Default Type a profile name and press enter to save your settings as user default. Load User Default Load previously saved user defaults. Save User UEFI Setup Profile to Disk It helps you to save current UEFI settings as an user profile to disk.

  • Page 28: Advanced Screen

    FP6D4-P1 4.4 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Onboard Devices Configuration, Storage Configuration, ACPI Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction.

  • Page 29: Cpu Configuration

    4.4.1 CPU Configuration PSS Support Use this to enable or disable the generation of ACPI_PPC, _PSS, and _PCT objects. NX Mode Use this to enable or disable NX mode. SVM Mode When this is set to [Enabled], a VMM (Virtual Machine Architecture)can utilize the additional hardware capabilities provided by AMD-V.

  • Page 30: Onboard Devices Configuration

    FP6D4-P1 4.4.2 Onboard Devices Configuration SR-IOV Support Enable/disable the SR-IOV (Single Root IO Virtualization Support) if the system has SR-IOV capable PCIe devices. UMA Frame buffer Size (Only for processor with integrated graphics) This item allows you to set the size of the UMA frame buffer.
  • Page 31 Bluetooth Enable/disable the bluetooth's connectivity Onboard LAN Enable or disable the onboard network interface controller.

  • Page 32: Storage Configuration

    FP6D4-P1 4.4.3 Storage Configuration SATA Controller(s) Enable/disable the SATA controllers.

  • Page 33: Acpi Configuration

    4.4.4 ACPI Configuration Suspend to RAM It is recommended to select auto for ACPI S3 power saving. Deep Sleep Configure deep sleep mode for power saving when the computer is shut down. Wake From Onboard LAN Allow the system to be waked up by onboard LAN. Ring-In Power On Allow the system to be waked up by onboard COM port modem Ring-In signals.

  • Page 34: Trusted Computing

    FP6D4-P1 4.4.5 Trusted Computing Security Device Support Enable or disable BIOS support for security device.

  • Page 35: Tools

    4.5 Tools SSD Secure Erase Tool Use this tool to securely erase SSD. Instant Flash Save UEFI files in your USB storage device and run Instant Flash to update your UEFI.

  • Page 36: Hardware Health Event Monitoring Screen

    FP6D4-P1 4.6 Hardware Health Event Monitoring Screen This section allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, fan speed and voltage. CPU FAN1 Setting Select a fan mode for CPU Fan 1, or choose Customize to set 5 CPU temperatures...

  • Page 37: Security Screen

    4.7 Security Screen In this section you may set or change the supervisor/user password for the system. You may also clear the user password. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 38: Boot Screen

    FP6D4-P1 4.8 Boot Screen This section displays the available devices on your system for you to configure the boot settings and the boot priority. Fast Boot Fast Boot minimizes your computer's boot time. In fast mode you may not boot from an USB storage device.
  • Page 39 CSM (Compatibility Support Module) Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. Other PCI Device ROM Priority For PCI devices other than Network. Mass storage or Video defines which OpROM- to launch.

  • Page 40: Exit Screen

    FP6D4-P1 4.9 Exit Screen Save Changes and Exit When you select this option the following message, “Save configuration changes and exit setup?” will pop out. Select [OK] to save changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option the following message, “Discard changes and exit...
  • Page 41 DECLARATION OF CONFORMITY Per FCC Part 2 Section 2.1077(a) Responsible Party Name: ASRock Incorporation Address: 13848 Magnolia Ave, Chino, CA91710 Phone/Fax No: +1-909-590-8308/+1-909-590-1026 hereby declares that the product Product Name : Motherboard FP6D4-P1 Model Number : Conforms to the following speci cations:...
  • Page 42 EU Declaration of Conformity For the following equipment: Motherboard (Product Name) FP6D4-P1 (Model Designation / Trade Name) EMC —Directive 2014/30/EU (from April 20th, 2016) EN 55022:2010/AC:2011 Class B EN 55024:2010/A1:2015 EN 55032:2012+AC:2013 Class B EN 61000-3-3:2013 EN 61000-3-2:2014 LVD —Directive 2014/35/EU (from April 20th, 2016)
