"C" CASE PARTS LIST
Item No Part No.
.
1 405548
2 Table 8-3
3 Table 8-3
4 194376
5 Table 8-3
6 Table 8-4
7 400092
8 400096
9 400097
10 194827-1
11 406593
12 194447
13 Table 8-5
14 Table 8-5
15 194373
16 404033
17 TRY174-3
18 Table 8-6
19 392456
20 191192
21 191193
22 406518
23 W10080-5
24 378234-13
25 Table 8-2
26 Table 8-4
27 Table 8-5
28 194335
29 191892
30 406434
31 404099
32 Table 8-5
33 Table 8-1
34 Table 8-3
35 Table 8-2
36 Table 8-2
37 194374
38 193114
39 392458
40 Call Factory
41 194372
42 194371
43 405026
44 192266-1
45 196096
46 194377
47 196038
48 Call Factory
49 193101-1
50 Table 8-7
51 194378
52 404079
53 194530
Description
Label, Frame Ground
Block, Fuse, Input
Fuse, Input
Panel, Top
Contactor, Line
Transformer, Control
Label, L1
Label, L2
Label, L3
Grommet, Mounting
Label, Supply Connections
Panel, Interior
Panel, Side, Right
Switch, Disconnect
Panel, Rear (See Note 1)
Insulator, Heat Sink
Bracket, Mtg., Capacitor
Capacitor, Transformer
Heat Sink, Flat
Heat Sink, Fin, 45
Heat Sink, Fin, 90
Label, Warning, Heat Sink
Connector, Strain Relief
Cover, Neoprene
Cable, Output Charging
Label, AC Input
Latch, Door, Disconnect
Label, Danger, Input Volt. & Fuse
Label, Warning, Rain Exposure
Label, Warning, Sparks
Label, Danger
Label, Disconnect Switch
Diode, Silicon
Block, Terminal, Transformer
Fuse, Output
Shunt, Current
Panel, Side, Left (See Note 2)
Insulator, Shunt / Fuse
Bus Bar
Transformer
Base, Charger
Support, Transformer
Label, Fuse, DC Output
Suppressor, Harness
Harness, Interior Panel
Hinge, Door
Label, Prestolite Power
Control, Charger
Rivet, Snap
Label, Charger
Door, Hinged
Label, UL and CUL
Latch, Door
193111-055
PARTS LIST
8-6
