Installation, Operating and Maintenance Instructions
02/2021
blueMatic EAV
Automatic locking system with motorised opening function
(12 V DC)
winkhaus.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the blueMatic EAV and is the answer not in the manual?

Questions and answers

Related Manuals for Winkhaus blueMatic EAV

Summary of Contents for Winkhaus blueMatic EAV

  • Page 1 Installation, Operating and Maintenance Instructions 02/2021 blueMatic EAV Automatic locking system with motorised opening function (12 V DC) winkhaus.de...
  • Page 2 © Aug. Winkhaus GmbH & Co. KG, All rights reserved. Last revised: 02/2021 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen...

  • Page 3: Table Of Contents

    P. 32 External power supply P. 32 Frame power supply (optional) P. 33 Access control systems P. 34 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 4 P. 71 4.3.2 Programming P. 71 Wireless receiver for additional applications (e.g. garage door control units) P. 75 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 5 P. 88 VdS Acceptance (based on VdS 2344, 2201) P. 88 Certificat DIN 18251-3 P. 88 10 Disposal Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 6: Important Information En

    It is assumed that the lock will be used as intended. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 7 The proper functions of the access control systems and the accessories included in the scope of delivery of the Winkhaus company have been tested. If you use components made by other companies and if you have any doubts about the suitability of these components, you will have to contact the respective manu- facturer to ensure their fitness for use.

  • Page 8: Use Contrary To The Intended Purpose

    • the lock is locked / unlocked by using improper objects; • the size of the door opening deviates from the specifications prescribed. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 9: Explanation Of Symbols

    Notices on complying with regulations on environmental protection. Disposal! Environmental damage due to incorrect disposal of batteries and electronic components! Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 10: Important Safety Information

    • Arbitrary modifications, changes or makeshift repairs are not permitted due to concerns for safety. You must only use genuine Winkhaus parts for replacements. • The manufacturer shall only be held liable for security related properties of...

  • Page 11: Abbreviations / Explanations

    Auxiliary antenna / ground Ground wire Neutral wire Phase Alternating current Direct current Make contact Break contact NO-NC Changer contact Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 12: Product Description

    230 V AC Figure 2-1: blueMatic EAV with accessories and external power supply Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 13 230 V AC Figure 2-2: blueMatic EAV with accessories and frame power supply T-NETZTEIL RAHM. 12 V DC 1,5 A Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 14 Figure 2-2: T-KÜ-T1 RT KABEL 0,6M RNT with plug connection to the fra- me power supply 24 V DC (optional) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 15 Flush-type box Handle * remaining components recommended for use, or should be used alternatively ** not extend cable Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 16: Automatic Locking System Autolock Av3

    C) with closed position of ± 45°, in each case with smooth-running free-to-turn function or stationary cam position. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 17 T-AV3-F1662 L79/55 A9 92/8 M2 RS/LS MC 5014941 5014942 T-AV3-F1662 L79/80 A9 92/10 M2 RS/LS MC 5041994 5041995 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 18 T-AV3-F1677062 L79/40 A9 92/8 M2 RS/LS MC 5034173 5034179 T-AV3-F1677062 L79/45 A9 92/8 M2 RS/LS MC 5015464 5015463 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 19 T-AV3-F2062 L79/65 A9 92/10 M2 RS/LS MC 5014958 5014959 T-AV3-F20162 L79/45 A9 92/8 M2 RS/LS MC 5050161 5050162 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 20 T-AV3-F2460 L79/45 A9 92/8 M2 RS/LS MC 5007849 5007847 T-AV3-F2460 L79/45 A9 94/8 KABA M2 RS/LS MC 5011505 5011504 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 21 T-AV3-U2460 L79/45 A9 92/10 M2 RS/LS MC 5008069 5008067 T-LE AV3-U2460 L79/45 A9 S 92/9 M2 RS/LS MC 5030968 5030969 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 22 T-LA AV3-U2418469 L79/45 A9 92/8 M2 RS/LS MC 5051363 5051364 T-LA AV3-U2418469 L79/50 A9 92/8 M2 RS/LS MC 5051365 5051366 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 23 T-AV3-U2488 L79/45 A9 92/8 M2 RS/LS MC 5063290 5063291 T-AV3-U2498062 L79/50 A9 92/8 M2 RS/LS MC 5015508 5015507 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 24 T-AV3OR-U2462 L79/40 A9 92/8 M2 RS/LS MC 5075980 5075981 T-AV3OR-U2471 L79/35 A9 92/8 M2 RS/LS GR 5035978 5035980 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 25: Motor Housing

    • If the main dead bolt is unlocked manually, the door may not be actuated electrically. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 26: Keep Rail / Extension Keep Set / Single Keeps

    Example: profile INOUTIC System Prestige  T-Grt. SL U26-192 ... When ordering always indicate the DIN direction RS or LS. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 27: Center Keep Fra

    T-G1 MAGNETAUSLÖSER 9 MV 5014379 T-G1 MAGNETAUSLÖSER 13 MV 5009111 T-G1 MAGNETAUSLÖSER 9 UMV 5009109 T-G1 MAGNETAUSLÖSER 13 5009110 UMV AV3 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 28: Daytime Latch "Tafa

    T-TAGESFALLE-O 9/91 TAFA FA STARK 5042651 T-TAGESFALLE-O 10/9 TAFA FA STARK STRONG = design with strong spring for higher sealing pressure Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 29: Cable Transition

    PVCu / plastic or aluminum) conceals the routing for the required cable reserves to prevent possible cable damage. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 30 Frame part with 0.6 m cable and plug for frame power supply inclusive cover strip STV-KÜ-T1 RT R8 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 31: Cable Transition Frame Part For T-Kü-T1

    STV-KÜ-T1 RT R8, to cover the profile hole on the frame side T-KÜ-T1 RT KABEL 0,6M RNT 5040504 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 32: Power Supply

    • for further external loads (e.g. intercom, LED lighting, video systems etc.), separate or designed power supplies must be used. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 33: Frame Power Supply (Optional)

    Use cable grommet at 230 V cable (2 x included)! No external voltage on output for external signals. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 34: Access Control Systems

    • 2 progamming cards transponder (pro- gramming card = green; delete-all card = red) T-HT TRANSPONDERSET T02 2410265 EAV BL Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 35 AC / free-wheeling diode at DC. Reason: Protection of the relay from wear. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 36: Routing Details

    5044744 Maintenance Instructions 3 Installation 3.1 Routing details For installing the blueMatic EAV it is required to rout out for standard three- point locking system and additionally the motor housing, as shown in the following diagrams. D = Backset G = Handle position...
  • Page 37 Maintenance Instructions Description Installation situation Situation hook Situation magnetic trigger Situation latch with daytime latch TaFa Situation motor housing Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 38: Cable Transition T-Kü-T1

    (includet in delivery T-KÜ ... sash part) Figure 3.2-1: T-KÜ-T1 FT with cover plate and frame part 1 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 39 Ø 3 x 20 mm in Figure 3.2-2: Detail the fitting groove. frame part 2 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 40 Figure 3.2-4: Cable assignment when used with blueMatic EAV Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 41 F20 in Timber Figure 3.2-6: Routing dimensions T-KÜ-T1 FT + RT and cover plate F16 in plastic Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 42: Installations

    By impressing the working voltage (start of operation), the motor brings the locking points into the neutral position. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 43: General Connection Diagram

    (Opening signal at least 0.5 s) ** no necessary screened cable 230 V AC Figure 3.3.1-1: General connection diagram Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 44: Access Control System Transponder Set

    • Do not install the antenna directly on metal as its range could be decreased drastically. • Do not install any other antenna within a radius of 1 m! Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 45 C 8 green potential free contact NO Figure 3.4-1: Terminal assignment of the transponder reader Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 46 ** no necessary screened cable 230 V AC Figure 3.4-2: Installation of the transponder reader Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 47: Access Control System Wireless Remote Control

    Notice: For safety reasons, you are not permitted to install it in a flush-type box with a 230 V AC switch or socket outlet. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 48 "Make contact (NO)", connect to terminal 4 of the wireless receiver (+ 12 V DC) "12 V DC or 24 V DC", Power supply, e.g. from the Winkhaus power supply (connect with white wire from the cable transition + terminal 2 from the wireless receiver) "0 V DC", Power supply, e.g.
  • Page 49 ** no necessary screened cable 230 V AC Figure 3.5.1-2: Installing the wireless receiver Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 50 • The wireless receiver can be adjusted from 12 V to 24 V via the jumper. Notice: Check the proper position of the jumper before starting operation! Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 51: Wireless Receiver (Separate)

    Notice: Do follow the relevant installation instructions of the additional applications! • Put the cover back on the housing and lock and screw it down. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 52 • Relay remains active after being activated by remote control. • Deactivation by actuating the remote control once more. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 53: Non Winkhaus Access Control System (Acs)

    EAV with motor operated opening (e.g. transponder set, wireless remote control): • We recommend the Winkhaus power supply T-HT NETZTEIL 12 V DC / 2 A (Mat.-No. 2469777) or the frame power supply T-NETZTEIL RAHM. 12 V DC 1,5 A (2 A/2 S) (Mat.-No.
  • Page 54 Fingerprint ekey home micro Figure 3.6.2-1: Installation blueMatic EAV with „Micro-Control unit, installed in the profile“ (sash side) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 55 Figure 3.6.2-2: Installation blueMatic EAV with „Micro-Control unit, installed in the profile“ and frame power supply (sash side) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 56 Fingerprint ekey home micro Figure 3.6.2-3: Installation blueMatic EAV with plus „Control unit, milled on the hinge side“ (sash side) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 57 Figure 3.6.2-4: Installation blueMatic EAV with „Control unit, milled on the hinge side“ and frame power supply (sash side) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 58 AV3, standard Fingerprint ekey home Figure 3.6.2-5: Installation blueMatic EAV with integra with control unit (sash side) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 59 Fingerprint ekey home Figure 3.6.2-6: Installation blueMatic EAV with integra with control unit and frame power supply (sash side) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 60 BioKey INSIDE with App 692 815 Fingerprint IDENCOM BioKey Figure 3.6.2-7: Installation blueMatic EAV with INSIDE (sash side) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 61 692 815 Fingerprint IDENCOM BioKey Figure 3.6.2-8: Installation blueMatic EAV with INSIDE and frame power supply (sash side) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 62 40 m extendable (min. 0,8 mm2) Fingerprint SOMMER Figure 3.6.2-9: Installation blueMatic EAV with ENTRAsys+ FD (sash side) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 63 SOMMER ENTRA+ 6M, Length 6 m, 3-wires for motor (with 4-pole plug for radio receiver ENTRAsys+ RX) separate Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 64 (min. 0,8 mm2) Fingerprint SOMMER Figure 3.6.2-10: Installation blueMatic EAV with ENTRAsys+ FD and frame power supply (sash side) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 65 SOMMER ENTRA+ 6M, Length 6 m, 3-wires for motor (with 4-pole plug for radio receiver ENTRAsys+ RX) separate Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 66: Control Of Additional Functions

    B) Control of swing door opener (ekey home integra 1 resp. 2) • When using a blueMatic EAV with control of the swing door drive, an additional cable transition and frame part must be used. (T-KÜ-T1 FT 3,5M, Part-no. 5040505; T-KÜ-T1 RT KABEL 4 M, Part-no.

  • Page 67: Operation / Programming

    • the intercom (potential free button!) • the handle or key (even possible in case of power failure) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 68: Bluematic Eav With Transponder

    Action Acoustic Signal Result Door with transponder not authorized nnnnn chip "Open" short, long Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 69: Programming

    (no more transponder in succession over the chips can be authorised chips can be authorised antenna max. 250) max. 250) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 70 If you lose the cards, the reader unit will have to be exchanged in its entirety! Please contact customer service in such a case. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 71: Bluematic Eav With Wireless Remote Control

    Button A Button B Notice: Keep the buttons pressed until you hear the acoustic signal at the receiver! Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 72 Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 73 • Insert two Lithium CR 2016 batteries. Notice: Pay attention to the correct polarity! Eco-Watch: Properly dispose of the batteries! Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 74 • A wireless remote control that has not been programmed by this method will need a programming (analogue "Teaching-in of wireless remote controls directly via the remote control"). Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 75: Wireless Receiver For Additional Applications (E.g. Garage Door Control Units)

    4.4 Wireless receiver for additional applications (e.g. garage door control units) No. Name JP1 jumper P1 button K4 relay red LED green LED Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 76 Now it is not possible to save additional wireless remote controls. This condition is indicated in the teach-in mode by both LED displays flashing simultaneously three times. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 77: Maintenance And Care En

    • Clean electronic parts only in a dry state. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 78: Errors / Causes / Troubleshooting

    • system not wired • check entire sys- correctly tem agains wiring diagram Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 79 30 mtrs. (unostructed) • remote control not • check remote autthorized control program- Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 80 • when locking the door (contact latch / dead bolt center keep) there is a short circuit Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 81: Technical Specifications

    Frame part approx.24 x 260 x 33 mm (B x H x T) Screw connection: max. 4 x 20 mm screws (max. length due to cable routing!) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...

  • Page 82: Antenna / Reader

    Lithium, 2 x CR 2016.31 Service life of batteries: 18 - 24 months Power consumption: 13 mA Frequency: 433,92 MHz Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 83 • T-KÜ-T1 FT 3,5 M with 3.5 m cable + plug for motor housing • T-KÜ-T1 FT 4,5 M with 4.5 m cable + plug for motor housing Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 84 - 3rd Cable end with plug for sash side access control systems Max. voltage: 48 V DC Max. switching current: 2 A per connection line / wire Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 85 • T-KÜ-T1 RT KABEL 0,6 M RNT with 0.6 m cable and plug for frame power supply Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 86 (the second button at the remote control can be used for this purpose) Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 87 (5066122) plug-in extension between frame power supply RNT and frame part cable transition T-KÜ-T1 RT KABEL 0,6M RNT Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 88 Acceptance class B for autoLock AV3, Acceptance-No.: M113345 9.3 Certificat DIN 18251-3 The company Aug. Winkhaus GmbH & Co. KG is certified, that it has fulfilled the requirements of DIN 18251 "Safety-relevant characteristics according to Table 3, Class 4 according to DIN 18251-3: 2002-11".
  • Page 89 Dr. D. Warnow, Technical Director ppa. A. Dinkelborg, Director of Product Management Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen ∙ T +49  369  3950 - 0 ∙ tuerverriegelung@winkhaus.de ∙ www.winkhaus.de T SB February 2020 · EN · All rights reserved.
  • Page 90 Notice: The packaging must be recycled separately in accordance with the separation regulations for packaging. Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen T +49  369  3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes...
  • Page 92 Aug. Winkhaus GmbH & Co. KG Berkeser Straße 6 D-98617 Meiningen T +49 3693 950- 0 F +49 3693 950- 134 winkhaus.de tuerverriegelung@winkhaus.de T SB February 2021 Print-No. 5044744 · EN All rights and changes reserved.
