- Page 1 ® Replace Pilot Series: 150000 – 450000 LP Gas...
-
Page 2: Tools Required
1. Installation and repair should be done by a qualified service person. 2. Use only Blue Rhino Global Sourcing, LLC. factory authorized parts. The use of any part that is not factory authorized can be dangerous. This will also void your warranty. - Page 3 ® For assistance call 1.800.762.1142. Steps 1-5 1. Turn your LP gas tank off, unscrew regulator and remove LP gas tank. 2. Remove the dome 3. Remove control knob and remove access panel 4. Disconnect gas line 5. Remove engine from post Replace Pilot - 150000 –...
- Page 4 ® For assistance call 1.800.762.1142. Step 6 Disconnect the pilot tube using the #10 mm open end wrench and the #12mm open end wrench. Replace Pilot - 150000 – 450000 LP Gas 501020...
- Page 5 ® For assistance call 1.800.762.1142. Step 7 Remove the two screws that hold the pilot to the pilot bracket Note: On the 153000 and 163000 series, there are 2 nuts that you will need to hold with the pliers to remove the pilot from the pilot bracket.
- Page 6 ® For assistance call 1.800.762.1142. Step 8 Remove the screw holding the tip switch bracket Replace Pilot - 150000 – 450000 LP Gas 501020...
- Page 7 ® For assistance call 1.800.762.1142. Step 9 1. Using a Phillips screw driver remove the access panel on the back of the valve housing. 2. Remove the thermal-couple wire on the back of the control valve using a #8 mm open end wrench. 3.
- Page 8 ® For assistance call 1.800.762.1142. Step 10 1. Remove the tip switch from the tip switch bracket using a Phillips screw driver and pliers 2. Install the new tip switch to the bracket. Replace Pilot - 150000 – 450000 LP Gas 501020...
- Page 9 ® For assistance call 1.800.762.1142. Step 11 1. Connect the thermal-couple wire to the back of the control valve. Finger tight plus a 1/4 turn with the #8mm open end wrench. 2. Attach the small access panel. Replace Pilot - 150000 – 450000 LP Gas 501020...
- Page 10 ® For assistance call 1.800.762.1142. Step 12 Attach the tip switch bracket to the valve support. Replace Pilot - 150000 – 450000 LP Gas 501020...
- Page 11 ® For assistance call 1.800.762.1142. Step 13 1. Slide pilot up into the pilot housing. 2. Attach the pilot supply tube. Do not fully tighten. 3. Secure pilot assembly to the pilot bracket with 2 screws 4. Tighten pilot supply nut. Replace Pilot - 150000 –...
- Page 12 ® For assistance call 1.800.762.1142. Steps 14-17 14. Attach the engine to the post 15. Burner Connections 1. Make sure the regulator valve and hose connections are securely fastened to the burner and the tank. 2. If your unit was assembled for you, visually check the connection between the burner pipe and orifice.
- Page 13 ® For assistance call 1.800.762.1142. Step 18 - IMPORTANT Perform leak check. WARNING FOR YOUR SAFETY If you smell gas - 1. Shut off gas to appliance. 2. Extinguish any open flame. 3. If odor continues, immediately call your gas supplier or your fire department. 1.
- Page 14 ® For assistance call 1.800.762.1142. Tank/Gas Line Connection 1. Make 2-3 oz. of leak solution by mixing one part liquid dishwashing soap with three parts water. 2. Make sure control knobs are off. 3. Turn LP gas tank ON at valve. 4.
- Page 15 1.800.762.1142, www.bluerhino.com © 2004 Blue Rhino Global Sourcing, LLC All Rights Reserved. ® Endless Summer is a registered trademark of Blue Rhino Global Sourcing, LLC All Rights Reserved. ® Blue Rhino is a registered trademark of Ferrellgas, L.P. All Rights Reserved.
