Summary of Contents for Blue Rhino Endless Summer 150000 Series
- Page 1 ® Cleaning Instructions for Burner, Pilot Assembly, and Emitter Screen Series: 150000 – 200605 LP Gas...
-
Page 2: Tools Needed
1. Installation and repair should be done by a qualified service person. 2. Use only Blue Rhino Global Sourcing, LLC. factory authorized parts. The use of any part that is not factory authorized can be dangerous. This will also void your warranty. - Page 3 ® For assistance call 1.800.762.1142. Steps 1-4 1. Disconnect and remove propane cylinder from heater. 2. Disconnect the main gas line from engine 3. Remove dome. 4. Remove engine from post. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 4 ® For assistance call 1.800.762.1142. Step 5 Remove emitter from emitter bottom by removing the 4 Phillips head screws in the emitter bottom. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 5 ® For assistance call 1.800.762.1142. Step 6 Use a non-abrasive scouring pad with soap and water solution to clean the inside and outside of the emitter screen. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 6 ® For assistance call 1.800.762.1142. Step 7 Unscrew and remove the two Phillips head screws in the pilot shield housing to remove the pilot shield. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 7 ® For assistance call 1.800.762.1142. Step 8 Using an open-end wrench (Size: #10mm and #12mm), remove the pilot tube. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 8 ® For assistance call 1.800.762.1142. Step 9 With pilot tube disconnected, remove the pilot tube. Note: Use care to not kink tubing. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 9 ® For assistance call 1.800.762.1142. Step 10 Remove the pilot orifice by using the #10mm and #12mm open-end wrenches. Note: Place the #10mm wrench on the black hex tube and the #12mm wrench on the brass piece. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 10 ® For assistance call 1.800.762.1142. Step 11 Pilot orifice is removed. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 11 ® For assistance call 1.800.762.1142. Step 12 With pilot orifice removed, insert a pipe cleaner into the bottom of the pilot housing through the top of the pilot hood to clean the area. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 12 ® For assistance call 1.800.762.1142. Step 13 Clean both ports at the top of the pilot assembly and clean the opening at the thermal-couple. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 13 ® For assistance call 1.800.762.1142. Step 14 Use small brush to clean the pilot orifice. Lightly brush orifice. Use care not to enlarge the orifice hole. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 14 ® For assistance call 1.800.762.1142. Step 15 Remove the pilot heat shield to access the burner assembly. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 15 ® For assistance call 1.800.762.1142. Step 16 Using an 11/16” open end wrench, hold the burner supply tube nut in place to prevent it from moving. At the same time, use a 3/4” open end wrench to unscrew the burner nut from the burner. Cleaning burner, pilot assembly and emitter screen.
- Page 16 ® For assistance call 1.800.762.1142. Step 17 With the brass nut removed, remove burner. Be careful not to damage burner. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 17 ® For assistance call 1.800.762.1142. Step 18 Clean venturi tube by inserting a bottle brush into the bottom of burner. Push brush in completely and twist to remove any spider webs or soot build up. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 18 ® For assistance call 1.800.762.1142. Step 19 Use a pipe cleaner to clean out all burner ports. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 19 ® For assistance call 1.800.762.1142. Step 20 Using an air hose or a can of compressed air, blow out the venturi tube and the burner ports. This will ensure that no soot or debris is left in the burner. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
- Page 20 ® For assistance call 1.800.762.1142. Step 21 Inspect the thermal-couple wires for any wear in the insulation. Should you find exposed areas, cover with electrical tape. Cleaning burner, pilot assembly and emitter screen. Series 150000-200605 LP Gas 501020...
