AGFEO A 30 Addendum To Manual

Upgrade for the system phone st 30
Hide thumbs Also See for A 30:
Table of Contents

Advertisement

Quick Links

Download this manual
Firmware 7.x
Addendum to
Main Manual
Answering Machine
Upgrade
for the
System Phone ST 30

Advertisement

Table of Contents
loading

Related Manuals for AGFEO A 30

Summary of Contents for AGFEO A 30

  • Page 1 Firmware 7.x Addendum to Main Manual Answering Machine Upgrade for the System Phone ST 30...

  • Page 2: Table Of Contents

    7.x Firmware Revision Table of Contents Table of Contents ........................2 Answering Machine Operation ....................3 Record an Announcement ......................4 Outgoing Message Activation (on / off) ..................4 Set to Answer or Answer Only Mode ..................4 Allocate Announcement to Line ....................5 Outgoing Message Activation (on / off) ..................

  • Page 3: Answering Machine Operation

    7.x Firmware Revision Answering Machine Operation The operation of the answering machine for the ST 30 System Telephone has changed: As the secondary extension number is no longer available the outgoing messages of the answering machine have now been increase to six individual selectable announcements. The answering machine can be set to „Greet and Record“...

  • Page 4: Record An Announcement

    7.x Firmware Revision Record an Announcement To record an outgoing announcement, please follow the steps below: Enter programming mode and select !611 announcement with the arrow keys, confirm by pressing Select 1 for „Record Greeting“. Pick up handset and press .

  • Page 5: Allocate Announcement To Line

    7.x Firmware Revision Allocate Announcement to Line Follow the instructions below to select which announcement should be played to which line. Enter programming mode !611 Select required announcement with the arrow keys and confirm by pressing Select the section „Announcement for“. Select if the Announcement should be for: „1“= Outside Call „2“= Extension Call...

  • Page 6: Outgoing Message Activation (On / Off)

    7.x Firmware Revision Outgoing Message Activation (on / off) With this comand you may enable / disable !612 individual - or all outgoing messages. Enter programming mode Individual !611 Select announcement required and confirm selection by pressing the button. Select: „1“= to set the outgoing message to off „2“= to set the outgoing message to on.

  • Page 7: Setting Functions

    7.x Firmware Revision Setting Functions !613 Display SubMenu: 1=Answers in set number of rings 2=Call screening 3=Toll Saver. Save Call Charges on interrogation Number of Rings The number of rings after which the TAM should answer an incoming call can be set in the menu „Number of Rings“.

  • Page 8: Toll Saver

    7.x Firmware Revision Toll Saver This feature will save on call charges if you call your answering machine to retrieve messages remotely. The answering machine will answer within 2 rings if new messages have been received and 5 rings if no new messages have been left. In order to avoid being charged for the call, replace the handset before your answering machine answers, ie.

  • Page 9: Set Info To Systels

    7.x Firmware Revision Set Info to Systels Enter programming mode !6141 Select the extension number of a system phone or hunt group. Either enter the extension number or browse using the arrow keys. If playback is required from more than one system phone then the hunt group number of the system phones has to be entered here.

  • Page 10: Answering Machine Maintenance

    7.x Firmware Revision Answering Machine Maintenance Select the Menu "TAM Maintenance": !615 „1“= Number of Messages / free minutes „2“= Reset to default. „3“= Clear Memory Display Answering Machine Status Select the Menu "Status" and confirm by !6151 pressing The following information will be displayed: - Version xx (current firmware of phone) - xx number of recorded messages - approx.

  • Page 11: Remote Interrogation

    7.x Firmware Revision Remote Interrogation The answering machine can be remotely interrogated from any telephone in the world or any extension phone connected to the system. Condition: You must use a DTMF telephone (Tone dialling phone). A DTMF tone pad may also be used.

  • Page 12: Index Numbers For Remote Interrogation

    7.x Firmware Revision Index Numbers for Remote Interrogation Once the connection to the answering machine is established select the required funtion by entering an index number from the menu below. Voice prompts will assist in the selection of the different menus. To repeat a menu press the button.
  • Page 13 7.x Firmware Revision Index Numbers for Remote Interrogation Record Announcements ................Check current announcement ......Record new announcement ........ Stop recording ............. Return to main menu .......... Repeat this menu ..........After playback or recording of an anouncement you may return to the main menu by pressing 0. Example of a Remote Interrogation You are in the main menu after you have entered your access code.

  • Page 14: Programming Tree

    7.x Firmware Revision Programming Tree Select Answering Machine Menu by pressing: !61 1 Record Greeting Select with Arrow Buttons ....1 Select Announcement ....2 Activate ........... 3 Answering Mode ........... 4 Announcement for ........... Select with arrow buttons 2 Activate ........1 Number of Rings ......
  • Page 15 7.x Firmware Revision...
  • Page 16 Identnr. 1101533 Subject to change without notice. AGFEO GmbH & Co. KG No liability can be accepted for Gaswerkstr. 8 errors contained in this document.
