Rocky's Eazy Roller Senior Commercial Instructions

This box contains
RE-
ITEM QTY DESCRIPTION
ORDER
# #
1 16 Self-tapping Screw 501
5 2 5/16"x1" Bolt 505
3/8" x 1" Bolt
7 4 507
9 4 3/8" x 1.5" Bolt 509
13 2 3/8"x8" Anchor Bolt 513
Concrete Anchor
15 2 515
19 2 5/16" Washer 505
21 18 3/8" Washer 21
Spring
25 2 517
29 6 Acorn Nut 523
31 4 3/8" Nut 525
#4 A-Frame
57 2 57
59 2 SR Bottom Base 59
61 1 White Knob 533
3rd Leg Frame
63 2 535
4" Commercial Hub
67 2 541
73 1 Large Handle 547
101 12 Male Grommet 549
Female Grommet
103 12 549
105 2 Plastic Bushing 555
107 2 Plastic Washer 555
Spring Guard
109 2 109
203 1 36' Strapping 589
211 6 4" Wheels 585
Tools Required:
Reversible Drill
1/2" Concrete (masonary) Drill Bit
Hammer & Center Punch (or large nail)
5/16" Hex Head Socket Bit
1/2" Wrench
5/8" Wrench
9/16" Wrench
R O C K Y ' S E A Z Y R O L L E R S I N S T R U C T I O N S - S E N I O R C O M M E R C I A L
1
For use with Rocky's 4" twelve
sided commercial tubing.
NOTE: Tube length should be about 1' wider than
pool.
Insert 4" hub (item #67) into one end of tube.
67
With 2 self-drill/tapping screws
SELF-DRILLING
(item #1), attach hub to tube
1
using electric drill. Apply
pressure to ensure screw
cuts into aluminum tube
then cuts it's own thread.
(No predrilling required)
Repeat with other side.
4
3
For regular shaped pools, align
the outside edge of the tube
MARK
parallel with the end of the pool.
#1
Using one of the two holes in the A-frame as a guide,
make mark #1 on deck. With a 1/2" concrete drill bit,
For irregular shaped pools, the
drill a 1 1/2" deep hole at mark #1. Complete steps 5
outside edge of the tube
and 6 before continuing with step 4.
should be 3'
On the other side of the roller unit, make mark #2 by
i n s i d e
using one of the two holes in the A-frame as of guide.
from the With a 1/2" concrete drill bit, drill a 1 1/2" deep hole at
end of mark #2.
the pool. NOTE:
Set one bolt at front of frame on one end and one
at the rear of the frame on the other end.
®
2
107
APPLY PETROLEUM BASED
GREASE
57
2 105
9
67 21
59
21
29
21
7 31
63
211
5
To set the concrete anchor, then tap
the slug into the hole with a hammer,
then using a center punch or large
nail drive the slug down into the
MARK
anchor forcing legs out into concrete.
#2
Slug
1/16"
Bolt the castors (item #211) to the SR bottom base
5
(item #59) and to the 3rd leg frame (item #63), as
19
shown in the diagram. Next, bolt the 3rd leg frames
(item #63) to the SR bottom base (item #59). Bolt
the #4 A-frame (item #57) to the SR bottom base
(item #59).
Assemble one end unit to the tube, using the large
handle (item #73), as shown in the diagram.
Assemble the other end unit to the tube, using the
white knob (item #61).
73
For smoother operation, apply petroleum based
29
grease between the hub (item #67) and the black
plastic bushing (item #105). This should be done
61
once a year.
Position the assembled roller unit at the widest end
21
of the pool.
V E R Y I M P O R T A N T
PREVENT DROWNING
Attach Warning Label to one end of tube.
6
Drive the concrete anchor into
the hole with a hammer. Leave
the anchor raised 1/16".
(item #13) through the spring
(item #25) and through the hole
of the SR base.
13
Hit center slug
25
with hammer &
center punch,or
large nail.
109
15
Tighten the anchor bolt.
NOTE: Do not over tighten
T960521SR
Insert the anchor bolt
