- Page 1 SYNARE RACK - USER MANUAL -...
-
Page 2: Table Of Contents
SYNARE RACK – User Manual WWW.KLEMENTZ.FR CONTENT SAFETY INSTRUCTIONS ..................................2 CHECK LIST .....................................2 QUICK START ....................................3 OVERVIEWS ....................................4 FRONT PANEL OVERVIEW ................................4 BACK PANEL OVERVIEW ................................4 CONTROLS & USE ...................................5 FRONT PANEL .....................................5 BACK PANEL ....................................7 TYPICAL WIRING ....................................8 DIRECT WIRING ..................................8 THRU FX PROCESSOR..................................9... -
Page 3: Safety Instructions
8. Don’t use another Power Supply than the one that is provided with the purchase. 9. In case of lost or damage of the Power Supply, contact KLEMENTZ before using a new power supply. 10. Make sure that the Power Supply block is not getting trampled, neither on the transformer part, nor on the cable or connector part. -
Page 4: Quick Start
SYNARE RACK – User Manual WWW.KLEMENTZ.FR QUICK START For a correct use of your SYNARE, please read the instructions below: This SYNARE must be plugged into a LINE input of your mixer or preamp. An effect processor can be plugged between your SYNARE and the LINE input of your mixer, only if the input of your effect processor is also a LINE type input. -
Page 5: Overviews
SYNARE RACK – User Manual WWW.KLEMENTZ.FR OVERVIEWS FRONT PANEL OVERVIEW BACK PANEL OVERVIEW Copyright Klementz All rights reserved © 2019... -
Page 6: Controls & Use
SYNARE RACK – User Manual WWW.KLEMENTZ.FR CONTROLS & USE FRONT PANEL DECAY TRIG UP/DOWN LFO LED MOD SW PITCH VOLUME SENS LFO AMP MOD SW TRI SHAPE SW TRIGGER TRIG AMP LFO SPEED The table below explains the features of the controls above. - Page 7 SYNARE RACK – User Manual WWW.KLEMENTZ.FR 2-positions switch selecting the base waveform of the LFO : MOD SW In the left position, the waveform will be square (« SQR ») In the right position, the waveform will be triangle (« TRI ») This 3-position switch is only active when the «...
-
Page 8: Back Panel
SYNARE RACK – User Manual WWW.KLEMENTZ.FR BACK PANEL EXT TRIGGER INPUT AUDIO OUTPUT DC JACK INTPUT The table below explains the functions of the connectors presented above. FUNCTIONS USAGE EXT TRIGGER INPUT Input Connector to plug an external trigger. 6.35mm MONO JACK type unbalanced output connector (check the « Typical AUDIO OUTPUT Wiring »... -
Page 9: Typical Wiring
SYNARE RACK – User Manual WWW.KLEMENTZ.FR TYPICAL WIRING DIRECT WIRING The simplest connection is the « Serial » one, meaning that the output of the SYNARE is directly inserted into a LINE input of the mixer or preamplifier. This configuration is the simplest. To apply an effect on the SYNARE, your mixer or preamplifier will need to have the effect send and return functionality. -
Page 10: Thru Fx Processor
SYNARE RACK – User Manual WWW.KLEMENTZ.FR THRU FX PROCESSOR The use of the dub siren (the SYNARE is one) is often coupled with an effect processor (for example Echo or Reverb). If your mixer or preamplifier does not have send/return functionality or if you prefer to keep this effect loop for another use, it is possible to plug the output of your SYNARE in the input of an effect processor (DUB DELAY for example). -
Page 11: Technical Specifications
SYNARE RACK – User Manual WWW.KLEMENTZ.FR TECHNICAL SPECIFICATIONS POWER SUPPLY 12 VDC, Center positive, 2.5 x 5.5mm barrel type connector CURRENT DRAW Less than 200mA AUDIO OUTPUT 1/4" unbalanced MONO Jack SIZE 483 x 198 x 47,3 mm Copyright Klementz All rights reserved ©... - Page 12 SYNARE RACK – User Manual WWW.KLEMENTZ.FR Designed and manufactured by 42 Rue de la Dutée 44800 Saint-Herblain France contact@klementz.fr Made in France Copyright Klementz All rights reserved © 2019...
