Summary of Contents for Klementz DIGISIREN
- Page 1 DIGISIREN - USER MANUAL -...
-
Page 2: Table Of Contents
DIGISIREN – User Manual WWW.KLEMENTZ.FR CONTENT SAFETY INSTRUCTIONS ..................................2 CHECK LIST .....................................2 QUICK START ....................................3 OVERVIEWS ....................................4 FRONT PANEL OVERVIEW ................................4 BACK PANEL OVERVIEW ................................4 CONTROLS & USE ...................................5 FRONT PANEL .....................................5 BACK PANEL ....................................6 TYPICAL WIRING ....................................7 DIRECT WIRING ..................................7 THRU FX PROCESSOR..................................8... -
Page 3: Safety Instructions
8. Don’t use another Power Supply than the one that is provided with the purchase. 9. In case of lost or damage of the Power Supply, contact KLEMENTZ before using a new power supply. 10. Make sure that the Power Supply block is not getting trampled, neither on the transformer part, nor on the cable or connector part. -
Page 4: Quick Start
Microphone input or it may damage it. Please see the « » section for a more detailed description of the possible wirings. 2. In you use the DIGISIREN with a DJ mixer, a [MONO JACK 6.35mm] to [2 x RCA (Cinch)] is necessary. NOTE On the cable described above, the 6.35mm JACK must be MONO. -
Page 5: Overviews
DIGISIREN – User Manual WWW.KLEMENTZ.FR OVERVIEWS FRONT PANEL OVERVIEW BACK PANEL OVERVIEW Copyright Klementz All rights reserved © 2019... -
Page 6: Controls & Use
If it is at the maximum, the oscillation speed will be fast and the modulation will be fast as well. Rotary potentiometer allowing to set the pitch of the sound of the DIGISIREN PITCH If it is at the minimum (fully anticlockwise), the pitch of the sound is low. -
Page 7: Back Panel
DIGISIREN – User Manual WWW.KLEMENTZ.FR BACK PANEL AUDIO OUTPUT DC JACK INTPUT The table below explains the functions of the connectors presented below. FUNCTIONS 6.35mm MONO JACK type unbalanced output connector (check the « Typical AUDIO OUTPUT Wiring » section below). -
Page 8: Typical Wiring
TYPICAL WIRING DIRECT WIRING The simplest connection is the « Serial », meaning that the output of the DIGISIREN is directly inserted into a LINE input of the mixer or preamplifier. This configuration is the simplest. To apply an effect on the DIGISIREN, your mixer or preamplifier will need to have the effect send and return functionality. -
Page 9: Thru Fx Processor
Echo or Reverb). If your mixer or preamplifier does not have send/return functionality or if you prefer to keep this effect loop for another use, it is possible to plug the output of your DIGISIREN in the input of an effect processor (DUB DELAY for example). The output of the effect processor will be plugged into a LINE input of your mixer or preamplifier. -
Page 10: Technical Specifications
DIGISIREN – User Manual WWW.KLEMENTZ.FR TECHNICAL SPECIFICATIONS POWER SUPPLY 12 VDC, Center positive, 2.5 x 5.5mm barrel type connector CURRENT DRAW Less than 200mA AUDIO OUTPUT 1/4" unbalanced MONO Jack SIZE 483 x 198 x 47,3 mm Copyright Klementz All rights reserved ©... - Page 11 DIGISIREN – User Manual WWW.KLEMENTZ.FR Designed and manufactured by 42 Rue de la Dutée 44800 Saint-Herblain France contact@klementz.fr Made in France Copyright Klementz All rights reserved © 2019...
