Summary of Contents for Klementz NANOPRE
- Page 1 NANOPRE - USER MANUAL -...
-
Page 2: Table Of Contents
NANOPRE – User Manual WWW.KLEMENTZ.FR CONTENT SAFETY INSTRUCTIONS ..................................2 CHECK LIST .....................................2 MACHINE PRESENTATION ................................3 QUICK START ....................................4 OVERVIEWS ....................................5 FRONT PANEL OVERVIEW ................................5 BACK PANEL OVERVIEW ................................5 CONTROLS & USE ...................................6 FRONT PANEL & CONTROLS ............................6 FUNCTIONS BLOC 1 : PHONO / LINE PREAMPLIFIER ..........................7 BLOC 2 : MICROPHONE PREAMPLIFIER ..........................7... -
Page 3: Safety Instructions
8. Don’t use another Power Supply than the one that is provided with the purchase. 9. In case of lost or damage of the Power Supply, contact KLEMENTZ before using a new power supply. 10. Make sure that the Power Supply block is not getting trampled, neither on the transformer part, nor on the cable or connector part. -
Page 4: Machine Presentation
NANOPRE – User Manual WWW.KLEMENTZ.FR MACHINE PRESENTATION Le Nanopre est une machine Dub box complète. Originellement conçue pour tout amateur de Reggae, de Dub ou de vinyles, il peut être utilisé pour transformer et améliorer n'importe quel type de musique. -
Page 5: Quick Start
» section for a more detailed description of the possible wirings. 2. In you use the NANOPRE with a DJ mixer, a [MONO JACK 6.35mm] to [2 x RCA (Cinch)] is necessary. 3. Before powering the NANOPRE, ensure that the Volume potentiometer is at the minimum position. -
Page 6: Overviews
NANOPRE – User Manual WWW.KLEMENTZ.FR OVERVIEWS FRONT PANEL OVERVIEW BACK PANEL OVERVIEW Copyright Klementz All rights reserved © 2019... -
Page 7: Controls & Use
NANOPRE – User Manual WWW.KLEMENTZ.FR CONTROLS & USE FRONT PANEL FUNCTIONS & CONTROLS The Nanopreamp is a machine composed of multiple features block. Each block is represented on the front panel below. A detailed description of each block is given below in this document. -
Page 8: Bloc 1 : Phono / Line Preamplifier
NANOPRE – User Manual WWW.KLEMENTZ.FR BLOC 1 : PHONO / LINE PREAMPLIFIER FUNCTIONS USAGE Switch used to select the main signal / music source : In high position, the LINE input is selected (CD player, Laptop, or any LN /PH other line level source) ... -
Page 9: Bloc 4 : 4 Way Crossover
NANOPRE – User Manual WWW.KLEMENTZ.FR SHAPE Switch selecting the mode (modulation waveform) of the Dub Siren TRIG Push button triggering the sound output of the dub siren. BLOC 4 : 4 WAY CROSSOVER The Nanopreamp has an internal active filter composed of 4 ways: SUB / BASS / MID and TOP. -
Page 10: Bloc 6 : Equalizer
NANOPRE – User Manual WWW.KLEMENTZ.FR BLOC 6 : EQUALIZER FUNCTIONS USAGE Rotary potentiometer allowing setting the targeted frequency in the SUB/BASS frequency range : BASS FREQ If it is at the minimum, the targeted frequency range is in the SUB range. -
Page 11: Back Panel Functions & Connectors
The main wiring diagrams have a dedicated section later in this document. BLOC 1 : SEPARATED OUTPUTS & FULL RANGE OUPUT As the NANOPRE has an internal 4-way active filter, you can use the separated outputs of the Nanopreamp in case of a multi-amplification system. -
Page 12: Bloc 2 : Fx Send & Return
NANOPRE – User Manual WWW.KLEMENTZ.FR MID separated output. Only the signal of the MID output of the 4-way filter is present on this output. 6.35mm Unbalanced MONO JACK type Connector. TOP separated output. Only the signal of the TOP output of the 4-way filter is present on this output. -
Page 13: Bloc 4 : Phono & Line Inputs
The power supply bloc is specifically designed for the Nanopreamp. Please refer to the end of this document to see the exact specs. NOTE Do not connect another power supply block. 2. In case of doubt, please contact the KLEMENTZ team at the address give at the end of this document. Copyright Klementz All rights reserved ©... -
Page 14: Typical Wiring
NANOPRE – User Manual WWW.KLEMENTZ.FR TYPICAL WIRING Copyright Klementz All rights reserved © 2019... -
Page 15: Internal Schematic
NANOPRE – User Manual WWW.KLEMENTZ.FR INTERNAL SCHEMATIC Copyright Klementz All rights reserved © 2019... -
Page 16: Frequency Response
NANOPRE – User Manual WWW.KLEMENTZ.FR FREQUENCY RESPONSE Copyright Klementz All rights reserved © 2019... -
Page 17: Modifications / Customizations
NANOPRE – User Manual WWW.KLEMENTZ.FR MODIFICATIONS / CUSTOMIZATIONS The user is not allowed to proceed to any tweaks or mods to the machine without the explicit allowance or request from the builder, or it will void the warranty. It is possible to customize and change the cut-off frequencies on request while ordering, and later when the machine has been bought, please contact us. - Page 18 NANOPRE – User Manual WWW.KLEMENTZ.FR FULL RANGE SETUP OUTPUT You can use the Full range output in 2 configurations, to allow different types of interfacing with other equipment. The two available setups are listed below: SETUP Dual mono (Stereo jack Compatible)
-
Page 19: Ouput Setup
NANOPRE – User Manual WWW.KLEMENTZ.FR OUPUT SETUP To reduce the number of output ways of the active filter of the unit, It is possible to mix them together. CONFIG BASS 4 Way* SUB* BASS* MID* TOP* 3 Way (2) SUB + BASS... -
Page 20: Gain Eq Potentiometer Setup
NANOPRE – User Manual WWW.KLEMENTZ.FR GAIN EQ POTENTIOMETER SETUP The gain potentiometer of the Parametric Equalizer can be set to control the gain of the Sub/Bass Parametric or/and the gain of the Mid/Top Parametric: GAIN SUB/BASS GAIN MID/TOP FIXED FIXED... -
Page 21: Technical Specifications
NANOPRE – User Manual WWW.KLEMENTZ.FR TECHNICAL SPECIFICATIONS ACTIVE FILTER CUTOFF FREQUENCIES* – 78Hz – 338Hz – 4.34kHz – INPUT IMPEDANCE > 10k Ohms POWER SUPPLY 16 VAC, 2.1 x 5.5mm barrel type connector CURRENT DRAW Less than 600mA @ 16V AC... - Page 22 NANOPRE – User Manual WWW.KLEMENTZ.FR Designed and manufactured by 42 Rue de la Dutée 44800 Saint-Herblain France contact@klementz.fr Made in France Copyright Klementz All rights reserved © 2019...
