- Page 1 POWERSIREN RACK - USER MANUAL -...
-
Page 2: Table Of Contents
POWERSIREN RACK – User Manual WWW.KLEMENTZ.FR CONTENT SAFETY INSTRUCTIONS ..................................2 CHECK LIST .....................................2 QUICK START ....................................3 OVERVIEWS ....................................4 FRONT PANEL OVERVIEW ................................4 BACK PANEL OVERVIEW ................................4 CONTROLS & USE ...................................5 FRONT PANEL .....................................5 BACK PANEL ....................................7 TYPICAL WIRING ....................................8 DIRECT WIRING ..................................8 THRU FX PROCESSOR..................................9... -
Page 3: Safety Instructions
8. Don’t use another Power Supply than the one that is provided with the purchase. 9. In case of lost or damage of the Power Supply, contact KLEMENTZ before using a new power supply. 10. Make sure that the Power Supply block is not getting trampled, neither on the transformer part, nor on the cable or connector part. -
Page 4: Quick Start
POWERSIREN in a Microphone input or it may damage it. Please see the « » section for a more detailed description of the possible wirings. 2. In you use the POWERSIREN with a DJ mixer, a [MONO JACK 6.35mm] to [2 x RCA (Cinch)] is necessary. NOTE On the cable described above, the 6.35mm JACK must be MONO. -
Page 5: Overviews
POWERSIREN RACK – User Manual WWW.KLEMENTZ.FR OVERVIEWS FRONT PANEL OVERVIEW BACK PANEL OVERVIEW Copyright Klementz All rights reserved © 2019... -
Page 6: Controls & Use
If it is at the maximum, the pitch of the signal is high. LFO LED Light indicating the oscillation speed of the LFO SHAPE SW 2-position switch allowing setting the base waveform of the POWERSIREN. 2-positions switch selecting the base waveform of the LFO : MODULATION SW In the left position, the waveform will be square («... - Page 7 In high position, rising sawtooth waveform In low position, falling sawtooth waveform VOLUME Rotary potentiometer allowing to set the output volume of the POWERSIREN TRIGGERS Push button that triggers the sound output of the POWERSIREN. PWR LED Power Light indicator. It will light when the machine is powered...
-
Page 8: Back Panel
POWERSIREN RACK – User Manual WWW.KLEMENTZ.FR BACK PANEL AUDIO OUTPUT DC JACK INTPUT The table below explains the functions of the connectors presented above. FUNCTIONS USAGE 6.35mm MONO JACK type unbalanced output connector (check the « Typical AUDIO OUTPUT Wiring » section below). -
Page 9: Typical Wiring
TYPICAL WIRING DIRECT WIRING The simplest connection is the « Serial » one, meaning that the output of the POWERSIREN is directly inserted into a LINE input of the mixer or preamplifier. This configuration is the simplest. To apply an effect on the POWERSIREN, your mixer or preamplifier will need to have the effect send and return functionality. -
Page 10: Thru Fx Processor
Echo or Reverb). If your mixer or preamplifier does not have send/return functionality or if you prefer to keep this effect loop for another use, it is possible to plug the output of your POWERSIREN in the input of an effect processor (DUB DELAY for example). The output of the effect processor will be plugged into a LINE input of your mixer or preamplifier. -
Page 11: Technical Specifications
POWERSIREN RACK – User Manual WWW.KLEMENTZ.FR TECHNICAL SPECIFICATIONS POWER SUPPLY 12 VDC, Center positive, 2.5 x 5.5mm barrel type connector CURRENT DRAW Less than 200mA AUDIO OUTPUT 1/4" unbalanced MONO Jack SIZE 483 x 198 x 47,3 mm Copyright Klementz All rights reserved ©... - Page 12 POWERSIREN RACK – User Manual WWW.KLEMENTZ.FR Designed and manufactured by 42 Rue de la Dutée 44800 Saint-Herblain France contact@klementz.fr Made in France Copyright Klementz All rights reserved © 2019...
