Page 1 0120-436-01-00003-010 Revision A Installation, Operation and Maintenance Manuals Fire Detection System Fisheries Survey Vessel (FSV) FSV-6 Marinette Marine Corporation Fincantieri Marine Group 1600 Ely Street Marinette, WI 54143 1 May 2013...
Page 3 RECORD OF CHANGES REVISION DATE DESCRIPTION OF CHANGE NITIAL SSUE 7-31-12 NOAA NCORPORATED CHANGES REQUESTED FROM 5, 2012 ESPONSE ETTER DATED 5-1-13...
Page 5 FOREWORD HIS MANUAL IS INTENDED TO CLEARLY AND ACCURATELY REFLECT THE ACTUAL CONFIGURATION OF THE INSTALLED EQUIPMENT AND PROVIDE THE USER WITH THE NECESSARY INSTRUCTIONS TO SUCCESSFULLY OPERATE MAINTAIN AND TROUBLESHOOT ASSOCIATED EQUIPMENTS HE MANUAL IS CONSTRUCTED AS FOLLOWS  C CS4000 F ONSILIUM LARM...
Page 6 ONFIGURATION HE FOLLOWING PIECES OF EQUIPMENT ARE THE MAJOR PARTS OF THIS SYSTEM CS4000 F ALWICO LARM YSTEM...
Page 7 Fire Alarm System CS4000 Installation Manual çConsilium...
Page 8 The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. Consilium Marine assumes no legal responsibility for any error or damage resulting from the usage of this document. Consilium Marine AB P.O.
Page 9 About this manual Installation Manual Salwico CS4000 Contents ABOUT THIS MANUAL ......................1 CHAPTER 1: GENERAL DESCRIPTION ................2 CS4000 B ......................2 LOCK DIAGRAM CHAPTER 2: INSTALLATION ....................3 ....................... 3 ECHANICAL INSTALLATION Central unit ..........................3 Loop units..........................3 ......................
Page 11 Chapter 4: Commissioning requirements describe which steps are to be taken by the installation organisation before a commissioning engineer can be sent from Consilium. Chapter 5: Guidelines for fire alarm installations gives some general recommendations to be considered when installing a fire alarm system.
Page 12 Chapter 1: General description Installation Manual Salwico CS4000 Chapter 1: General description The CS4000 is a state of the art analogue addressable fire detection system designed to meet all major marine and industrial requirements. Special care has been taken to ergonomics, user friendliness with its logical self-instructing operator panel guiding the user to the various functions available.
Page 13 Chapter 2: Installation Installation Manual Salwico CS4000 Chapter 2: Installation The different parts of the CS4000 fire alarm system, the central unit, the control units, repeaters and the loop units, should first be mechanically installed. The different loop units are thereafter electrically installed and set up according to the definition of the loops.
Page 14 Min. 2 x 0.3 mm Loop: Min. 2 x 0.3 mm Sub-loop: However, Consilium recommends using standard unshielded cable min 2 x 0.75 mm Loop lengths The length of a loop or a sub-loop depends on the following three parameters, type of cable, shielded or unshielded cable and power consumtion.
Page 15 Chapter 2: Installation Installation Manual Salwico CS4000 Type 3: Reduced capacity level 2 • All address units with a constant voltage output on the sub-loop • AE-2 and AE-2K, configured as smoke detector (ID 111 and 124), flame detector, IR, (ID 123) and heat detector with constant output on the sub-loop (ID 118).
Page 16 Chapter 2: Installation Installation Manual Salwico CS4000 Important notice: Set the address switch on each loop unit before connecting them to • the loop. If an address unit is used, set its ID switch too. See Setting the address of the loop units later in this chapter and also Appendix A and B.
Page 17 Chapter 2: Installation Installation Manual Salwico CS4000 Connection to LB3 loop board ANALOG ADDRESSABLE ANALOG ADDRESSABLE ADDRESSABLE MANUAL ADDRESSABLE SMOKE DETECTOR HEAT DETECTOR CALL POINT FLAME DETECTOR (ION OR OPTICAL) IN FIRE CENTRAL SHORT CIRCUIT ISOLATOR ADDRESSABLE ADDRESS UNIT ISOLATOR FOR...
Page 18 Chapter 2: Installation Installation Manual Salwico CS4000 Connection to ZB, zone board Example of a detector zone with conventional non-addressable loop units...
Page 19 Chapter 2: Installation Installation Manual Salwico CS4000 Test the cable The cable should be tested for proper function after all the loop units are connected and before the cable is connected to the central unit. The cable can only be tested if all short circuit isolators are bypassed.
Page 20 Chapter 2: Installation Installation Manual Salwico CS4000 Test 2: Test for short circuits. Measure the resistance between the + pole and the - pole. Connect an ohm meter between the two poles. The measured value should be more than 100kΩ for a cable with a maximum length of 2 km.
Page 21 Chapter 2: Installation Installation Manual Salwico CS4000 Setting the address on loop units. All addressable loop units such as detectors, manual call points etc connected to the loop board LB must be given an address between 1-254 to be operational. The loop units located on the same physical loop must all have unique addresses.
Page 22 Chapter 2: Installation Installation Manual Salwico CS4000 Addressable Timers The addressable timers are located on the detector loop in the same way as any loop unit. For UR-2/UR-2K type timers, three address DIP switches should be set: 1. The loop address for the timer itself.
Page 23 Chapter 2: Installation Installation Manual Salwico CS4000 Electrical installation, Central equipment Terminal layout Since most systems are customer designed there exists no standard for how the different boards are to be connected in the system. However in the figure below you will find one board of each type that can be connected to the CS4000 system.
Page 24 Chapter 2: Installation Installation Manual Salwico CS4000 An example of a central unit terminal layout...
Page 25 Chapter 3: Verification Installation Manual Salwico CS4000 Chapter 3: Verification The definition of the loops must be performed by a person with a good knowledge of the CS4000 fire system. The operator must have the authority to work in access level 4. The system is delivered either with a complete system definition or a test definition.
Page 26 Chapter 3: Verification Installation Manual Salwico CS4000 8. We recommend you to use a top to bottom procedure if you have any problem with the verification of the loop function. Start by solving the problems that affect the whole loop and thereafter continue with the problems with each address.
Page 27 Chapter 3: Verification Installation Manual Salwico CS4000 Trouble shooting Polarity fault One or more loop units are not correctly installed if the measured voltage is much less then 30 VDC. Proceed as follows to locate the loop units with polarity fault: 1.
Page 28 Chapter 3: Verification Installation Manual Salwico CS4000 Cable break No loop units are answering. - The cable is broken before the first loop unit if no answer is received on a single fed loop. - The cable is broken before the first loop unit and after the last loop unit if the loop is a double fed loop.
Page 29 Chapter 3: Verification Installation Manual Salwico CS4000 Mute faults Mute all the faults simultaneously by pressing the Mute button. • The fault indication stops flashing and turns over to steady yellow. The fault is put in a fault list under menu/ 1 Fault Alarms/ 1 Fault List.
Page 30 Loop Requirements The following specification is a checklist of requirements on the loops for Salwico CS4000 fire alarm. The specification shall be used by the installation organisation of loop units and cabling. Start with part A, continue with part B and then part C. Part B must be used once for every loop.
Page 31 10.Fax each signed protocol in one copy to Consilium authorised representative and one copy to Consilium Marine, Gothenburg, Sweden. 11.When all loops are tested and all protocols are signed, a Consilium service engineer can be asked to come for the final control and adjustment of the system.
Page 32 Summary The following document must be filled in and faxed to Consilium +46 - 31 710 78 00 and your local Consilium representative in your country before commissioning of the system starts. ”Address list/test report”, appendix A, one for each loop.
Page 33 • Mark each loop unit with zone and address number. Suitable marking location for a detector is on its base. Special adhesive labels for marking are available from Consilium. • Please refer to the data sheet of each unit for detailed information about connection and installation etc.
Page 34 Chapter 5: Guidelines for fire alarm installations Installation Manual Salwico CS4000 • Avoid placing the detector near heat-generating devices, such as ovens, saunas etc., which may cause unwanted alarms. • Covering area max 37m • Maximum distance from wall or bulkhead is 4.5 m and between two detectors it is 9 m.
Page 35 Chapter 5: Guidelines for fire alarm installations Installation Manual Salwico CS4000 detection zone with SCI and therefore it is important to have it close to where the cable changes to a new fire detection zone. • Installation shall preferably be hidden from the public but easily accessible for service.
Page 36 Appendix A: Address list / Test report Installation Manual Salwico CS4000 Appendix A: Address list / Test report...
Page 37 Appendix A: Address list / Test report Installation Manual Salwico CS4000...
Page 38 Appendix A: Address list / Test report Installation Manual Salwico CS4000...
Page 39 Appendix B: ID list Installation Manual Salwico CS4000 Appendix B: ID list The ID switch must be set on the address units type AE and NS-AIN. The ID defines the function of the unit and type of unit connected to the address unit.
Page 40 Appendix B: ID list Installation Manual Salwico CS4000 ID for AE type address units ID no. Type of connected device Switches to set Heat detector Sprinkler, water Sprinkler, CO Smoke detector, ion Flame detector, IR Sprinkler, foam Flame detector, UV...
Page 41 Appendix C: Fault codes & Fuses Installation Manual Salwico CS4000 Appendix C: Fault codes & Fuses Fault list Listed below are all fault codes, their causes and how an operator with some knowledge of the system can solve the problem.
Page 43 Appendix C: Fault codes & Fuses Installation Manual Salwico CS4000 A cable break on the Locate the cable break and mend it. CABLE BREAK negative conductor has NEGATIVE been detected. Two units have the Check the loop unit addresses COMMUNICATION same address.
Page 45 Appendix C: Fault codes & Fuses Installation Manual Salwico CS4000 Something has restarted. If it happens repeatedly, contact our service RESTARTED More info is given on department. the control panel. Exceeded the maximal If it happens repeatedly, contact our service TOO LONG BOOT allowed boot time.
Page 46 Appendix C: Fault codes & Fuses Installation Manual Salwico CS4000 Fuses If a fuse is defective in the system a fault will be displayed at the control units. Locate and replace the fuse with the information below. Fuse list Location...
Page 47 Appendix D: Connections for loop units Installation Manual Salwico CS4000 Appendix D: Connections for loop units...
Page 48 Appendix D: Connections for loop units Installation Manual Salwico CS4000 Connections for loop units...
Page 49 Appendix D: Connections for loop units Installation Manual Salwico CS4000 Connections for loop units, NS-type...
Page 51 Fire Alarm System CS4000 User Guide çConsilium...
Page 52 The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. Consilium Marine assumes no legal responsibility for any error or damage resulting from the usage of this document. Consilium Marine AB P.O.
Page 53 User Guide Contents Salwico CS4000 Contents About this manual ........................3 Chapter 1: General description ....................4 Control panel CS4000 ......................4 Description of keys and indicators ..................4 Repeater panel MN4000......................8 Description of keys and indicators ..................8 Guide to the menu system ....................
Page 54: Table Of Contents
User Guide Contents Salwico CS4000 Reconnection of disconnected items ..................29 Chapter 3: Installation......................30 Electrical connection ......................30 Description of CS4000 PCB’s..................30 Connection ........................31 Testing ..........................32 Test a fire-detecting zone ....................32 Reset test mode......................... 32 Test the control unit display .....................
Page 55 User Guide About this manual Salwico CS4000 About this manual This manual gives general information about the CS4000 fire alarm system and its control panel in chapter 1 General description. In chapter 2 Operation it is described how to operate the CS4000 fire alarm system.
Page 56 User Guide Chapter 1: General description Salwico CS4000 Chapter 1: General description The CS4000 is a state of the art analogue addressable fire detection system designed to meet all major marine and industrial requirements. Special care has been taken to ergonomics, user friendliness with its logical self-instructing operator panel guiding the user to the various functions available.
Page 57 User Guide Chapter 1: General description Salwico CS4000 1. Fire alarm indicator The fire alarm indication is flashing with red light to indicate that there is an un-muted fire alarm in the system. It turns into steady light when all fire alarms are muted.
Page 58 User Guide Chapter 1: General description Salwico CS4000 11. Warning indicator Warnings, for example a dirty detector, are indicated with yellow steady light. 12. Pre-alarm indicator The pre-alarm indication flashes with red light to indicate that there is an un-muted pre-alarm in the system. It turns into steady light when all pre-alarms are muted.
Page 59 User Guide Chapter 1: General description Salwico CS4000 24. Arrow keys The arrow keys are used to navigate in the menus and select different menu alternatives. Shows the previous item in the list. If the first item is displayed it will go to the last item.
Page 60 User Guide Chapter 1: General description Salwico CS4000 Repeater panel MN4000 The repeater panel is used to monitor functions of the CS4000 fire alarm system. It is possible to view and list fire alarm, faults and disconnections. Description of keys and indicators...
Page 61 User Guide Chapter 1: General description Salwico CS4000 4. Disconnection indicator This is a general indicator showing that there is at least one disconnected function in the system, for example a zone, detector, external control or alarm device. 5. Test button Test of all indications and each segment in the alphanumerical display on the repeater panel.
Page 62 User Guide Chapter 1: General description Salwico CS4000 Guide to the menu system The CS4000 is a menu-operated system. All functions in the system can be reached from the different menus. Choosing menu alternatives Press Menu to enter the menu system. Navigate in the menu alternatives with the up and down arrows.
Page 63 User Guide Chapter 1: General description Salwico CS4000 Menu tree CS4000 Home 1 Fault Alarms 1 Fault List 2 Warning List 3 Reset All Faults 2 Fire Alarms 1 Fire List 2 Pre-Alarm List 3 Resound (restart bells) 4 Reset All Fire Alarms...
Page 64 User Guide Chapter 1: General description Salwico CS4000 Explanation of the different menu alternatives Home Top-level start display showing “CS4000 FIRE ALARM SYSTEM” and the name of the installation (if defined). 1 Fault Alarms The menu from which fault- and warning messages are listed and handled.
Page 65 User Guide Chapter 1: General description Salwico CS4000 3.1.2 Detectors & Manual Call Points Possibility to disconnect individual detectors or manual call points for a specified time period or permanent. 3.1.3 External Controls Possibility to de-activate all External Controls or Alarm Transfer.
Page 66 User Guide Chapter 1: General description Salwico CS4000 3.5 Remove all disconnections Removes all active disconnections shown in the disconnection list (3.2). Does not remove periodic disconnections (3.3) permanently, just the active period of the periodic disconnection. 4 Login From this menu it is possible to log in to the system by entering the access code, create new users or delete users.
Page 67 User Guide Chapter 1: General description Salwico CS4000 6 Service menu (access level 4) Use this menu to list and view information about the system and its components. It is also possible to make disconnections of the listed units. 6.1 System Details This menu gives information about the installed system such as name and reference number (if defined).
Page 68 User Guide Chapter 1: General description Salwico CS4000 Definition of terms External controls An output to activate external actions, for example release fire doors or stop ventilation. Alarm device Alarm devices are outputs activated in case of fire, for example audible or optical alarms such as bells, sirens and flashlights.
Page 69 User Guide Chapter 1: General description Salwico CS4000 CS4000 System data Supply voltage (other supply voltage is optional) 230 VAC Internal system voltage 24 VDC Max 512 (max according Number of detectors on one central to EN54 regulations) Number of detectors in one addressable detector loop Max 254 No.
Page 70 User Guide Chapter 1: General description Salwico CS4000 CS4000 System : EN54 functions Optional functions with requirements The following optional functions with requirements are available in the CS4000 system: Paragraph Function description Output to alarm devices (Item C) Output to fire alarm routing equipment (Item E) 7.10...
Page 71 User Guide Chapter 2: Operations Salwico CS4000 Chapter 2: Operations Access levels To prevent un-authorized operation of the system there are access levels to protect the different functions of the CS4000. The user has to login to the system or unlock the lock (mainly industrial applications) before any vital operations can be performed.
Page 72 User Guide Chapter 2: Operations Salwico CS4000 Description of the access levels Access level 1 Only viewing of fire or fault alarms. Fire alarms have priority over fault alarms. Possibility to mute local buzzer. Access level 2 As level 1 + access to the menu system. List status. Reset and muting of alarms.
Page 73 User Guide Chapter 2: Operations Salwico CS4000 Pre-alarm The CS4000 is equipped with the function Pre-alarm that will give an early alarm to a slow raise of the fire condition, for example a smouldering fire. The Pre-alarm level is lower than the ordinary fire alarm level.
Page 74 User Guide Chapter 2: Operations Salwico CS4000 Fire alarm When “Fire” is flashing FIRE FAULT DISC. Menu Home Disc. Power Test FIRE ALARM 1(2) 15.53 Alarm Transfer 1 FIRE ZONE 2 MCP 23 Alarm Device Alarm Delay Galley deck 4...
Page 75 User Guide Chapter 2: Operations Salwico CS4000 Pressing MUTE causes the internal buzzer and all external alarms to silence and mutes the fire alarm indication. When the alarm is muted the fire indication stops flashing and turn over to steady light.
Page 76 User Guide Chapter 2: Operations Salwico CS4000 Fault indications When “Fault” is flashing FIRE FAULT DISC. Menu Home Disc. Power Test FAULT ALARM 1(1) 18.53 _______________________________________________ Alarm Transfer 1 LOOP ANALOGUE 3 CABLE BREAK POSITIVE Alarm Device Loop 3 Alarm Delay...
Page 77 User Guide Chapter 2: Operations Salwico CS4000 Reset All faults in the system are shown in the fault list. Reset a fault: 1. Go to the fault list under: Menu/ 1 Fault Alarms/ 1 Fault List 2. Choose the fault in the fault list and then press RESET to reset the fault alarm.
Page 78 User Guide Chapter 2: Operations Salwico CS4000 Disconnections It is possible to disconnect different parts of the system, such as: zones, detectors, manual call points, section units, alarm devices, external control devices and loops. All disconnections are placed in a disconnection list.
Page 79 User Guide Chapter 2: Operations Salwico CS4000 Disconnecting zones (access level 2B or higher) Disconnections are made under: Menu/ 3 Disconnections/ 1 New disconnection To disconnect a conventional zone, follow the basic system below: Step 1 Step 2 Step 3...
Page 80 User Guide Chapter 2: Operations Salwico CS4000 Disconnecting addressable detectors (access level 2B or higher) Disconnecting individual detectors is only possible on addressable loops. Disconnections of detectors are made under: Menu/ 3 Disconnections/ 1 New disconnection/ 2 Detectors & Manual...
Page 81: Reconnection Of Disconnected Items
User Guide Chapter 2: Operations Salwico CS4000 Disconnecting external outputs (for example fans, fire doors etc) (Access level 2B or higher) 1. Select: Menu/ 3 Disconnections/ 1 New disconn./ 3 External Control 2. Choose all outputs or select an individual output category to be disconnected.
Page 82: Chapter 3: Installation
User Guide Chapter 3: Installation Salwico CS4000 Chapter 3: Installation Electrical connection This chapter will give some brief information about installation. For full information, please refer to the separate “CS4000 installation manual”. Description of CS4000 PCB’s The CS4000 system is based on the following standard PCB’s: Panel Board, PB This is the control panel with alphanumerical display.
Page 83: Connection
User Guide Chapter 3: Installation Salwico CS4000 Connection Since all CS4000 systems are customer designed no standard exists for how the different PCB’s are to be connected in the system. However, in the figure below you will find an example with one board of each...
Page 84: Testing
User Guide Chapter 3: Installation Salwico CS4000 Testing After installation of the fire alarm system the different parts of the system shall be tested to assure correct function. The CS4000 has a special test mode, which makes the testing easier. When a zone is in test mode it will not activate any external alarm devices or controls in case of a fire.
Page 85: Index
User Guide Index Salwico CS4000 Index Disconnection of alarm delay · 26 Disconnection of alarm transfer output · 27 Disconnections · 24 Disconnections shortcut button · 6 Access levels · 17 Acknowledgement of a new disconnection · 24 Add new user · 18 Alarm delay ·...
Page 86 User Guide Index Salwico CS4000 Loop board, LB3 · 14 Rectifier Board, RB · 28 Loop Board, LB3 · 28 Relay board, RB · 14 loop cable requirements · 15 Relay Board, RB · 28 Loop unit · 14 Reset · 21 Reset button ·...
Page 88 The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. Consilium assumes no legal responsibility for any error or damage resulting from the usage of this document. Edition 6, 10 1 E, Oct 2010.
Page 89 Service & Maintenance manual Chapter 1: CS4000 block diagram Salwico CS4000 Contents Chapter 1: CS4000 block diagram ..................2 Chapter 2: Testing........................3 ....................3 EST A FIRE DETECTING ZONE Heat detectors ........................3 Smoke detectors........................4 Flame detectors ........................4 ......................
Page 90 Service & Maintenance manual Chapter 1: CS4000 block diagram Salwico CS4000 ........................25 ISPLAY NITS ..........................26 ONES ..........................28 OOPS ....................32 ELOAD ONFIGURATION ................. 33 OAD CONFIG FROM EMORY TICK .................. 34 PLOAD CONFIG TO EMORY TICK ................... 35...
Page 91: Chapter 1: Cs4000 Block Diagram
Service & Maintenance manual Chapter 1: CS4000 block diagram Salwico CS4000 Chapter 1: CS4000 block diagram...
Page 92: Chapter 2: Testing
Chapter 1: CS4000 block diagram Salwico CS4000 Chapter 2: Testing Consilium recommends that the fire alarm system is tested at least once a year to assure correct function. The CS4000 has a special test mode, which makes the testing easier.
Page 93: Smoke Detectors
Smoke detectors Smoke detectors are preferably tested with test gas equipment Solo 330, available from Consilium.  Spray test gas on to the detector during 0.5 second. Wait 10 seconds until new gas is sprayed during 1 second. Repeat this procedure until the detector indicates alarm with a red indication.
Page 94: Battery Fault
Service & Maintenance manual Chapter 1: CS4000 block diagram Salwico CS4000 Battery fault 1. Remove a battery fuse. 2. Verify that the fault is indicated on the control unit (this may take up to 1 minute). 3. Reinsert the fuse.
Page 95: Reset Test Mode
Service & Maintenance manual Chapter 1: CS4000 block diagram Salwico CS4000 Reset test mode After testing it is important to return the tested zone into normal condition again. Make sure that there are no detectors or manual call points still in alarm before leaving test mode.
Page 96: Chapter 3: Cleaning Of Fire Detectors
Service & Maintenance manual Chapter 3: Cleaning of fire detectors Salwico CS4000 Chapter 3: Cleaning of fire detectors The CS4000 fire alarm system continuously monitors the detectors and will give early warnings if they are polluted or malfunctioning in other ways. The methods for cleaning detectors depends of the type of detector, see below.
Page 97: Chapter 4: Replacing/Adding/Deleting Fire Detectors
Service & Maintenance manual Chapter 4: Replacing/Adding/Deleting fire detectors Salwico CS4000 Chapter 4: Replacing/Adding/Deleting fire detectors Replacing fire detectors Instruction 1. Disconnect the faulty detector and remove it from the base plate. Note: Some bases have a lock mechanism on the side.
Page 98: Hot Plug&Play (Adding/Deleting Loop Units)
Service & Maintenance manual Chapter 4: Replacing/Adding/Deleting fire detectors Salwico CS4000 Hot Plug&Play (adding/deleting loop units) The CS4000 system is equipped with a Hot Plug&Play function enabling the user to add or delete detectors during normal operation without the need to change the configuration file with a PC and restarting the system.
Page 99 Service & Maintenance manual Chapter 4: Replacing/Adding/Deleting fire detectors Salwico CS4000 4. Enter the data required for the new loop unit in dialog box Add loop unit. Central, Board, Loop and Zone must exist in the Systems Configuration to be valid.
Page 100: Change Configuration File From The Service Menu
Service & Maintenance manual Chapter 4: Replacing/Adding/Deleting fire detectors Salwico CS4000 Change configuration file from the service menu Adding a loop unit from the service menu 1. Open the service menu: Menu/ 6 Service menu/ 5 Loops 2. Select an analogue loop from the loop list (loop no. 2 is selected in the below example).
Page 101 Service & Maintenance manual Chapter 4: Replacing/Adding/Deleting fire detectors Salwico CS4000 Deleting a loop unit from the service menu 1. Open the service menu: Menu/ 6 Service menu/ 5 Loops. 2. Select an analogue loop from the loop list (loop no. 2 is selected in the below example).
Page 102: Chapter 5: Replacing Battery
Service & Maintenance manual Chapter 5: Replacing battery Salwico CS4000 Chapter 5: Replacing battery When replacing the batteries, make sure to use batteries with the same specification as the original. System is tested and approved according to EN 54-2 and EN 54-4 with two Yuasa 2.3 Ah type NP-12 batteries connected in series.
Page 103: Chapter 6: Software
Service & Maintenance manual Chapter 6: Software Salwico CS4000 Chapter 6: Software Configuration program The CS4000 central is delivered pre-programmed with a standard configuration file. See the separate manual CS4000 Configuration program manual for information on how to create and update a configuration file.
Page 104: To Download A Configuration File To Cs4000
Service & Maintenance manual Chapter 6: Software Salwico CS4000 To download a configuration file to CS4000 When the configuration file is finished it is time to download it to the CS4000 system. The configuration file must have the file extension “.c4d”.
Page 105: Download Configuration File From The Salwico Memory Stick Tm
Service & Maintenance manual Chapter 6: Software Salwico CS4000 Download configuration file from the Salwico Memory Stick 1. Connect the Salwico Memory Stick to one of the USB ports on the USB expansion board (piggyback board located on the Base Board).
Page 106: Update The Base Board Software
Service & Maintenance manual Chapter 6: Software Salwico CS4000 Update the base board software There are two flash memories in the base board:  flash1 containing bootloader and the software for the base board (flash1.img).  flash2 containing the definition file (current.c4d)
Page 107: Possible Errors During Update Of Base Board
Service & Maintenance manual Chapter 6: Software Salwico CS4000 Possible errors during update of base board Error LED1 do not flash after reboot when the DIP switch on the base board is set to 0. Cause The base board is defect.
Page 108: Chapter 7: Service Menu In Cs4000 (Access Level 4)
Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 Chapter 7: Service menu in CS4000 (access level 4) Service menu is used for configuration of the system in the commissioning phase, as well as for troubleshooting and small updates when the system is in operation.
Page 109: System Details
Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 1 System Details The System Details screen gives basic information about the system. SYSTEM DETAILS 12 36 CS4000 Consilium Salwico M/S Holiday CONFIGURATION Created : 2006-08-29 14:34:41...
Page 110: System Boards
Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 2 System Boards The System Boards screen lists the boards in the system. BOARD 1(2) 12 36 1 CENTRAL 1 BOARD BB 1 (BOARD OK)XX...
Page 111 Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 Details about system board (press OK at System Boards screen) BOARD 1(2) 12 36 1 CENTRAL 1 BOARD BB 1 HW: BASE BOARD VER. 1.0 SW: BBP ver.
Page 112 Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 Inputs of system board (press 2 at System Boards screen) INPUT 1(6) 12 36 1 BOARD 1 INPUT 1 CLEAR XXXXXXXXXXXXXXXXXXXXXXXXXXXX 2 BOARD 1 INPUT 2 SET...
Page 113 Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 Outputs of system board (press 3 at System Boards screen) OUTPUT 1(6) 12 36 1 BOARD 1 OUTPUT GRP 1 CLEAR XXXXXXXXXXXXXXXXXXXXXXXX XXXk 2 BOARD 1 OUTPUT GRP 2 CLEAR...
Page 114: Display Units
Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 3 Display Units The Display Units screen lists the panel boards. DISPLAY UNIT 1(6) 12 36 1 CENTRAL 1 BOARD PB 3 xxxx xxxxxxxxxx XXXXXXXXXXXXXXXXXXXXXXllkXXXXXl...
Page 115: Zones
Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 4 Zones The Zones screen lists the zones in the system. ZONE 1(40) 12 36 1 ZONE 1 xxxx xxxxxxxxx 1XXXXXXX XXXXHHXXXXXXml Deck 1XXXXXXX XXXXHHXXXXXXml...
Page 116 Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 Loop units of Zones (press 2 at Zones screen) LOOP UNITS 1(10) 12.36 ________________________________________ 1 LOOP 2 SMOKE 1 2 LOOP 2 SMOKE 3 3 LOOP 2 SCI 4...
Page 117: Loops
Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 5 Loops The Loops screen lists the loops in the system. LOOP 1(35) 12 36 1 LOOP ANALOGUE 1 f xxxxxxxx XXDeck 3XXXXXXXXXXXXXXXXXXXXXXl Starboard side...
Page 118 Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 Details about loops (press OK at Loops screen) LOOP 1(35) 12 36 LOOP ANALOGUE 2 System Address (crd.subCrd): 11.1 Loop Units (found/expected): 17/17 Communication errors: 625/1000...
Page 119 Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 Loop units (press 2 at Loops screen) LOOP UNITS 1(17) ________________________________________ 1 LOOP 1 SMOKE HEAT 1 (A/B) 2 LOOP 1 SMOKE HEAT 2 (A/B)
Page 120 Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 Add loop units (press 3 at Loops screen) ADD LOOP UNIT ________________________________________ Physical Central addr.: 1 (valid) Physical Board address: 6 (valid) Physical Loop address : 1 (valid)
Page 121: Reload Configuration
Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 6 Reload Configuration The screen is used when a new updated configuration file or supplementary text file has been downloaded to the CS4000 system. RELOAD CONFIGURATION...
Page 122: Load Config From Memory Stick
Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 7 Load config from Memory Stick The screen is used to download a new configuration file from the Salwico Memory Stick. LOAD FROM MEMORY STICK 1(8) 12 36 SG12345_Rev1.C4DMMMMMMMMMMMM...
Page 123: Upload Config To Memory Stick
Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 8 Upload config to Memory Stick The screen is used copy the existing CS4000 configuration file to the Salwico Memory Stick. UPLOAD TO MEMORY STICK 12 36 SG12345_Rev1.c4lMMMMMMMMMMMM...
Page 124: Save Changes To Configuration
Service & Maintenance manual Chapter 7: Service menu in CS4000 (access level 4) Salwico CS4000 9 Save changes to configuration The screen is used to save all changes made to the system configuration from the control panel. Note that the changes are not permanently saved in the configuration file until this command is performed.
Page 125: Upload Syslog To Memory Stick
10 Upload syslog to Memory Stick The screen is used to upload a system log with service information to the Salwico Memory Stick. This service log can then be sent to Consilium for further technical assistance. UPLOAD SYSLOG TO MEMORY STICK 12 36...
Page 126: Appendix A: Fault Codes & Fuses
Service & Maintenance manual Appendix C: System modules Salwico CS4000 Appendix C: System modules The system modules are building blocks in the fire alarm system. The system can be designed according to customers needs. All functions in the modules, including the control unit, are performed by circuit boards.
Page 127 Nominal voltage 27 VDC The printed circuit board Panel Board, PB, is a system Working voltage 19-30 VDC module in the Salwico CS4000 fire alarm system. Working current 65-85 mA The Panel Board together with the alphanumerical (excl. buzzer output)
Page 128 Specifications may be subject to change for improvement without prior notice Data sheet no: 462002 PB panel board 06 2 E Page 2 of 3 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 129 Specifications may be subject to change for improvement without prior notice Data sheet no: 462002 PB panel board 06 2 E Page 3 of 3 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 131: Appendix B: Connections For Loop Units
Nominal voltage 27 VDC The printed circuit board BB, Base Board is a system Working voltage 19-30 VDC module in the Salwico CS4000 fire alarm system. Working current 110 mA The Base Board is the motherboard in the system, Cable terminals 2.5 mm...
Page 132 Specifications may be subject to change for improvement without prior notice Data sheet no: 462001 base board 10 1 E Page 2 of 4 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 133 Specifications may be subject to change for improvement without prior notice Data sheet no: 462001 base board 10 1 E Page 3 of 4 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 134: Appendix C: System Modules
Specifications may be subject to change for improvement without prior notice Data sheet no: 462001 base board 10 1 E Page 4 of 4 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 135 Description RB Data Input voltage 100, 115 or 230 VAC The printed circuit board RB, Rectifier Board, is a +10%/-15% system module in the Salwico CS4000 fire alarm Output voltage 28 VDC system. Working current 70 mA The Rectifier Board, together with the transformer,...
Page 136 Specifications may be subject to change for improvement without prior notice Data sheet no: 462005e1 RB rectifier board 10 4 E Page 2 of 3 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 137 Specifications may be subject to change for improvement without prior notice Data sheet no: 462005e1 RB rectifier board 10 4 E Page 3 of 3 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 139 Battery discharge protector Salwico BDP-1 kit Part no. 5100425-00A System: Salwico CS4000 fire alarm Description Data The BDP-1 KIT is an add-on circuit board required when Operating voltage 10-30 VDC the CS4000 shall fulfil the requirements of the Marine Current consumption: Equipment Directive (MED).
Page 140 Pict. 1 BDP-1 mounted on RB Rectifier Board Specifications may be subject to change for improvement without prior notice Data sheet no: 5100425-00A.BDP-1 kit.10.1.ME ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800 www.consilium.se...
Page 141 27 VDC The printed circuit board LB3, Loop Board is a system Working voltage 19-30 VDC module in the Salwico CS4000 fire alarm system. Working current 340 mA The Loop Board is a connection board for 3 analogue Cable terminals 2.5 mm...
Page 142 Specifications may be subject to change for improvement without prior notice Data sheet no: 462003 LB3 loop board 06 2 E Page 2 of 2 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 143 Nominal voltage 27 VDC The printed circuit board ZB, Zone Board, is a system Working voltage 19-30 VDC module in the Salwico CS4000 fire alarm system. Working current 140 mA The Zone Board is a connection board for Max current/zone 100 mA 16 conventional detector zones or 16 digital inputs*.
Page 144 Specifications may be subject to change for improvement without prior notice Data sheet no: 462006 ZB zone board 06 4 E Page 2 of 3 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 145 Specifications may be subject to change for improvement without prior notice Data sheet no: 462006 ZB zone board 06 4 E Page 3 of 3 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 147 Nominal voltage 27 VDC The printed circuit board OB, Output Board, is a system Working voltage 19-30 VDC module in the Salwico CS4000 fire alarm system. Working current 70 mA The Output Board is an optional board providing Max current...
Page 148 Specifications may be subject to change for improvement without prior notice Data sheet no: 462004 output board 06 2 E Page 2 of 4 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 149 Specifications may be subject to change for improvement without prior notice Data sheet no: 462004 output board 06 2 E Page 3 of 4 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 150 Specifications may be subject to change for improvement without prior notice Data sheet no: 462004 output board 06 2 E Page 4 of 4 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 151 Nominal voltage 3.3 VDC The printed circuit board SETH1 is a system module in Working current ~10 mA the Salwico CS4000 fire alarm system. Temperature range 0°C to +55°C SETH1 adds an Ethernet port to the CS4000 system. This Weight...
Page 153 CS4000 system boards USB expansion board SPX Part no. 462008 System: Salwico CS4000 fire alarm Description Data Nominal voltage 3.3 VDC The SPX board is developed to add extra communication Working current ~10 mA channels to a CS4000 system: Temperature range -10°C to +70°C...
Page 155 Data Nominal voltage 27 VDC The printed circuit board MB, MUX Board, is a Working voltage 19-30 VDC system module in the Salwico CS4000 fire alarm Working current 140 mA system. Max current/output 100 mA The MUX Board is a multiplexer with 254 outputs.
Page 156 Specifications may be subject to change for improvement without prior notice Data sheet no: 462012 MB MUX board 06 2 E Page 2 of 3 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 157 Specifications may be subject to change for improvement without prior notice Data sheet no: 462012 MB MUX board 06 2 E Page 3 of 3 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 159 Fire Alarm System Salwico CS4000 Appendix D – Loose Parts List çConsilium Consilium Reference No. Your Reference No. SG23749 436-01-00003...
Page 160 Loose Parts List Consilium Reference No: Your Reference No: CAGE Code: SG23749 436-01-00003 3egto Item number Name Loose part number 5801512-00A CS4000 FIRE ALARM CENTRAL 436-01-00003-800 461005 MX4000 CONTROL PANEL UNIT 436-01-00003-801 N18103 ADDRESS LABEL SHEET(96PC) 436-01-00003-802 465000 CS4000 PRODUCT BINDER...
Page 161 Fire Alarm System Salwico CS4000 Appendix A - General Technical Specifications çConsilium Consilium Reference No. Your Reference No. SG23749 436-01-00003...
Page 163 Fire alarm central Salwico CS4000 Part no. CS4000/A1200 Description Data Nominal voltage 115 or 230*VAC Salwico CS4000 is an addressable analogue fire alarm Power consumption ~30W in normal condition, system. Max 100W The central is delivered complete with: Heat emission...
Page 164 Fire alarm central Salwico CS4000 Block diagram Specifications may be subject to change for improvement without prior notice Data sheet no: CS4000/A1200 08 1 E Page 2 of 3 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 165 Fire alarm central Salwico CS4000 Connection Base Board, part no. 462001 Rectifier Board, part no. 462005e1 RECTIFIER BOARD, RB4 230VAC CONNECTION* 115VAC CONNECTION COLOUR TABLE RELAYS POWER SUPP LY RS485 115 or 230 VAC 24 V PRIMARY PRIM PRIM B: BROWN...
Page 167 Control panel Salwico MX4000 Part no. 461005 System: Salwico CS4000 fire alarm Description Data Nominal voltage 27 VDC MX4000 is the control unit of the CS4000 fire alarm Working voltage 19-30 VDC system. Working current 65-100 mA MX4000 is equipped with:...
Page 168 Specifications may be subject to change for improvement without prior notice Data sheet no: 461005 MX4000 05 1 E Page 2 of 2 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800...
Page 169 3(-) 3 mA remote output Specifications may be subject to change for improvement without prior notice Data sheet no: 40000.EV-H 54C.09.1.E Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800 www.consilium.se...
Page 170 3(-) 3 mA remote output Specifications may be subject to change for improvement without prior notice Data sheet no: 40005.EV-H 84C.09.1.E Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800 www.consilium.se...
Page 171 6(-) 3(-) 3 mA remote output Specifications may be subject to change for improvement without prior notice Data sheet no: 40020.EV-P.08.1.E Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800 www.consilium.se...
Page 173 UV flame detector Salwico NS-AUV Part no. N11121 System: Salwico CS4000, CS3000* NSAC-1 fire detection system Description Data Sensor type UV Tron The NS-AUV is an analogue addressable flame detector Wave length detection 185 – 260 nm for Salwico addressable fire alarm systems. It is sensitive Supervising angle 100°...
Page 174 2 mA remote output Specifications may be subject to change for improvement without prior notice Data sheet no: N11121.NS-AUV.07.1.E Page 2 of 2 Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800 www.consilium.se...
Page 175 Max internal capacitance (C ) 1 nF * SPK-2 for NOSE based detectors. Max internal inductance (Li) Negligible Responsible manufacturer Consilium Fire & Gas, www.consilium.se Only clean outside of detector by using a damp cloth. Dimensions (mm) Connection Safe area...
Page 176 Loop in Loop out 2mA remote output Specifications may be subject to change for improvement without prior notice Data sheet no: 46916.SPB-ADAPT.06.1.E Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800 www.consilium.se...
Page 177 2(-) Specifications may be subject to change for improvement without prior notice Data sheet no: N1430.ADAPTER AOHS-IS.05.1.E Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg, Sweden Phone +46 31 710 77 00 Fax +46 31 710 78 00...
Page 178 Dimensions (mm) Specifications may be subject to change for improvement without prior notice Data sheet no: 46950.03.1.E Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg, Sweden Phone +46 31 710 77 00 Fax +46 31 710 78 00...
Page 179 Nominal voltage 24 VDC The NS-ACP is a manual call point for the addressable Working voltage 15-35 VDC fire alarm system Salwico CS4000, NSAC-1 and CS3000 Working current with SPK2000. - supervising 0.2 mA Pressing the glass causing it to crack activates the fire - alarm 2.5 mA...
Page 180 Nominal voltage 24 VDC The NS-ACP-IP55 is a manual call point for the Working voltage 15-35 VDC addressable fire alarm system Salwico CS4000, NSAC-1 Working current and CS3000 with SPK2000. The ingress protection IP55 - supervising 0.2 mA makes this call point suitable for harsh environments.
Page 181 2(-) 24(-) Ω Specifications may be subject to change for improvement without prior notice Data sheet no: N1790.10.2.E Page 1 of 2 Consilium Marine AB P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800 www.consilium.se...
Page 182 Cable to IS units Ω IS-ISOLATOR Specifications may be subject to change for improvement without prior notice Data sheet no: N1790.10.2.E Page 2 of 2 Consilium Marine AB P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800 www.consilium.se...
Page 183 Timer Loop in Loop out ELR-4.7 Specifications may be subject to change for improvement without prior notice Data sheet no: N11751-58.NS-TIMAC1.07.1.E Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800 www.consilium.se...
Page 184 Short circuit isolator Salwico NS-SCI Part no. N11891 System: Salwico CS4000 and NSAC-1 fire alarms Description Data The NS-SCI is an analogue addressable short circuit System voltage 24 V DC isolator for the NSAC-1and CS4000 fire alarm system. Operating voltage...
Page 185 Pole 3.0 - 12 m 9149 N1738 9153 N1744 Specifications may be subject to change for improvement without prior notice Data sheet no: N1738.Solo330.09.1.E Consilium Marine AB ÇConsilium P.O. Box 8763, SE-402 76 Göteborg Phone +46 31 7107700 Fax +46 31 7107800 www.consilium.se...
Page 186 The EV-AD2 will switch to “Standby mode” humidity or temperature. to prevent damage. Low battery warning. Changes shortly to “Low battery trouble”. Insert new batteries. The specifications described herein are subject to change without notice. Data sheet no: 5200123-00A EV-AD2.09 1.E www.consilium.se...
Page 187 Press any key to start from “Standby mode”. 10. Finish by turning the power switch “OFF”. The specifications described herein are subject to change without notice. Data sheet no: 5200123-00A EV-AD2.09 1.E www.consilium.se...
Page 189 Fire Alarm System Salwico CS4000 Appendix E – Certificates çConsilium Consilium Reference No. Your Reference No. SG23749 436-01-00003...
Page 207 Fire Alarm System Salwico CS4000 Appendix G – Terms & Conditions çConsilium Consilium Reference No. Your Reference No. SG23749 436-01-00003...
Page 208 Validity The following conditions apply unless deviations are confirmed in a written agreement between Consilium Marine AB, hereinafter called the vendor, and the purchaser. In addition to what is stated in the following terms of sale, NL 92, including assembly NLM 84 in the Nordic countries and ECE 188 including Addend.
Page 209 User Guide Appendix B: Quick guide* Salwico CS4000 Appendix B: Quick guide* FIRE FAULT DISC. Menu Home Disc. Power Test Alarm Transfer Alarm Device Alarm Delay Zone/Unit PQRS WXYZ System Fault Warning Pre-Alarm Mute Next Reset Fire alarm Accept a fire alarm & silence buzzer:...
Page 210 User Guide Appendix C: Display analogue values of a loop unit Salwico CS4000 Appendix C: Display analogue values of a loop unit The analogue value of a loop unit can be displayed on the panel board. This information can be useful to see the condition of a loop unit.
Page 211 User Guide Appendix C: Display analogue values of a loop unit Salwico CS4000 NS-ACP, Callp. 36 5% NS-ACWP at 25C 127  5% LK-2/-2K Callp. at 25C OA-120 Smoke 20-100 Sub.L >15 OA-130 Smoke 20-100 90  5% Heat at 25C Sub.L...
Page 212 User Guide Appendix C: Display analogue values of a loop unit Salwico CS4000 Address units type AE Address units make conventional digital detectors and other digital signals addressable and compatible with the CS4000 system. The type of connected device is set with the ID switch, see table below.
Page 213 User Guide Appendix C: Display analogue values of a loop unit Salwico CS4000 Analogue values for other loop units Loop Unit Channel Analogue values Name Function Normal Activated KS-2/-2K Short circuit UR-2K Timer UR-2KN Timer...
Page 215 Special Tools Consilium Reference No: Your Reference No: CAGE Code: SG23749 436-01-00003 3egto Item number Name Loose part number 5200123-00A EV-AD 2 ADDRESSING TOOL 436-01-00003-813 Rev A 3 February 2011...
Page 216 Special Test Equipment Consilium Reference No: Your Reference No: CAGE Code: SG23749 436-01-00003 3egto Item number Name Loose part number N1738 SOLO 330 SMOKE DET TESTER 436-01-00003-819 N1744 ADAPTER FOR N1738 436-01-00003-820 009151 EXTENSION HANDLE 4 METER 436-01-00003-821 009153 TEST GAS FOR SMOKE DET. *DGR*...
Page 217 Consumables Consilium Reference No: Your Reference No: CAGE Code: SG23749 436-01-00003 3egto Item number Name Loose part number 009153 TEST GAS FOR SMOKE DET. *DGR* 436-01-00003-822 Rev A 3 February 2011...
Page 218 Spare Parts Consilium Reference No: Your Reference No: CAGE Code: SG23749 436-01-00003 3egto Item number Name Loose part number Quantity N11250 NS-AOHS-IS OPT S/H DETECTOR IS 436-01-00003-810 N11121 NS-AUV UV FLAME DET HEAD 436-01-00003-814 N11301 NS-ACP MANUAL CALL POINT IP22...
Page 219 Consilium part no. 9153 As division of Home Safeguard Industries Material Safety Data Sheet Smoke Detector Tester Model No. 25 S, 2.5 oz. Revision: 01/01/04 Manufactured for Home Safeguard Shield Packaging of California, Inc. 5165 'G' Street Industries, LLC at :...
Page 220 Section 3 - Physical Data Appearance: Clear, colorless liquid Odor: Sweet Petroleum Boiling Range (Aerosol): -25.1 to +32º F Evaporation Rate (Aerosol): Immediate @ T above -25.1º F Vapor Density (Aerosol): Heavier than air % Volatile by Weight (Aerosol): < 100% Weight per Gallon (Aerosol): 4.5 # / Gal Section 4 - Fire and Explosion Hazard Data ________________________________________________________________________...
Page 221 Skin: Flush with plenty of water for 15 minutes. If any irritation persists, get medical attention if there is evidence of tissue damage. Inhalation: Harmful by Inhalation (R20). Remove victim to fresh air and provide oxygen if breathing is difficult. Give artificial respiration if victim is not breathing. Keep person warm and quiet.
Page 222 Handling and Storage: Product should be kept at temperatures below 120º F in a dry, cool area. Product is extremely flammable. Keep away from heat, sparks, and flame. Use only with adequate ventilation. Avoid breathing of vapor or mist. Wear OSHA standard goggles or face shield.
Page 223 DRAWING LIST SALWICO CS4000 FIRE DETECTION SYSTEM Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 225 Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 227 Flange entry cable diametres. 1 x Ø17-32 2 x Ø12-18 16x Ø10-14 14x Ø7-12 2 x Ø6-10 Mounting brackets and one FL21 multi flange is included. Colour: RAL 7032 Weight: Complete central ~22 kg Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 229 Console mounting Cut-out size Knock-outs diametres. 1 x Ø37 from behind 2 x Ø32 5 x Ø20 Colour: RAL 7032 Weight: Complete unit ~2 kg Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 231 Intrinsically Safe Smoke/Heat Detector, IP55 Detector EV-P Detector EV-P Detector NS-AOHS-IS Base UB-6 Adapter SPB-ADAPT Adapter AOHS-IS-ADAPTER Base 2IP55 Base 2IP55 436-01-00003-808 436-01-00003-810 436-01-00003-805 436-01-00003-811 436-01-00003-808 436-01-00003-809 436-01-00003-806 436-01-00003-806 Weight: ≈185g Weight: ≈330g Weight: ≈340g Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 233 Detector EV-H/A1R Detector EV-H/CS Detector NS-AUV Adapter SPB-ADAPT Adapter SPB-ADAPT Adapter SPB-ADAPT Base 2IP55 Base 2IP55 Base 2IP55 436-01-00003-804 436-01-00003-807 436-01-00003-814 436-01-00003-805 436-01-00003-805 436-01-00003-805 436-01-00003-806 436-01-00003-806 436-01-00003-806 Weight: ≈330g Weight: ≈330g Weight: ≈315g Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 235 CUT-OUT Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 237 MOUNTING PLATE Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 239 NOTE: 115VAC www.consilium.se Copyright Consilium Marine AB...
Page 241 Copyright Consilium Marine AB...
Page 243 Copyright Consilium Marine AB...
Page 245 Copyright Consilium Marine AB...
Page 247 Copyright Consilium Marine AB...
Page 249 Copyright Consilium Marine AB...
Page 251 Note to workshop Central is to be delivered whithout batteries. FIRE FAULT DISC. Menu Home Disc. Power Test Alarm Transfer Alarm Device Alarm Delay Zone/Unit PQRS WXYZ SALWICO CS4000 System Fault Warning Pre-Alarm Mute Next Reset www.consilium.se Copyright Consilium Marine AB...
Page 253 NOTE: 115VAC www.consilium.se Copyright Consilium Marine AB...
Page 255 Copyright Consilium Marine AB...
Page 267 Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 269 03 LEVEL LOOP 1 PRIMARY 03 LEVEL 03 LEVEL 02 LEVEL 02 LEVEL LOOP 1 SECONDARY 02 LEVEL 02 LEVEL 01 LEVEL 01 LEVEL LOOP 2 PRIMARY LOOP 2 SECONDARY 01 LEVEL 01 LEVEL Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 271 MAIN DECK MAIN DECK LOOP 3 PRIMARY LOOP 3 SECONDARY MAIN DECK MAIN DECK 2ND DECK 2ND DECK LOOP 4 PRIMARY LOOP 4 SECONDARY 2ND DECK 2ND DECK Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 273 MAIN DECK MAIN DECK MAIN DECK MAIN DECK 2ND DECK 2ND DECK LOOP 5 PRIMARY 2ND DECK 2ND DECK TANK TOP TANK TOP LOOP 5 SECONDARY TANK TOP TANK TOP Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 275 2ND DECK 2ND DECK LOOP 6 PRIMARY LOOP 6 SECONDARY 2ND DECK 2ND DECK TANK TOP TANK TOP TANK TOP TANK TOP Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...
Page 277 MAX. 20 IS-UNITS PER ISOLATOR Göteborg, Sweden www.consilium.se Copyright Consilium Marine AB...

Consilium SALWICO CS4000 Installation Manual

Section 1

Chapter 3: Installation

Section 2

Chapter 1: CS4000 Block Diagram

Chapter 2: Testing

Chapter 4: Replacing/Adding/Deleting Fire Detectors

Chapter 5: Replacing Battery

Chapter 6: Software

Chapter 7: Service Menu in CS4000 (Access Level 4)

Appendix A: Fault Codes & Fuses

Appendix B: Connections for Loop Units

Appendix C: System Modules

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for Consilium SALWICO CS4000

Summary of Contents for Consilium SALWICO CS4000

Table of Contents
