- Page 1 " " The price of greatness is responsibility. — Winston Churchill TRUSTED PARTNER OF ONE-X KIT Spring return actuator with integrated communication module. Unit 23, Second Avenue, Cookstown Ind. Est., Tallaght, Dublin 24, D24 FP95. Ph: +353 1 463 4300 www.airmovementsupplies.ie...
- Page 2 ONE-X Features Spring return actuator with integrated field module. Spring return fire damper actuator ▶ Fusible link 72°C ▶ 24V or 230V versions ▶ 3 cables: bus in, bus out and power ▶ 3 LEDs: damper status, bus status, errors ▶...
- Page 3 " I dentify your problems but give your " p ower and energy to solution. — Tony Robinson TRUSTED PARTNER OF ONE-X KIT Spring return actuator with integrated communication module. CO N T E N T S Product presentation ONE-X .
- Page 4 ONE-X K148-A Product presentation ONE-X Actuator 06/2020 rOduct PresentatiOn The ONE-X is a spring return actuator with integrated communication module designed to simply operate Rf-t fire dampers of all sizes, automatically or remotely. When powered, the actuator moves the damper blade into its stand-by position. When the power is interrupted or when the temperature in the duct exceeds 72°C, the internal armed spring brings the damper blade back into its safety position.
-
Page 5: Operating Mechanism
ONE-X K148-A 06/2020 Actuator Operating mechanism One-X PeratinG mechanism Unlocking AUTO ZENIX 72°C • Manual unlocking: shortly press the unlocking button (1) once. • Remote unlocking: by interrupting the power supply. • Automatic unlocking: the fusible link reacts as soon as the temperature in the duct reaches 72°C. •... -
Page 6: Installation
ONE-X K148-A Installation Actuator 06/2020 Caution: It is sufficient to briefly insert the battery (touch the contacts) in the ONE-X to rearm it when the ONE-X is powered, unless the ZENiX controller commands the damper to be open or it is the first time the ONE-X is activated. The power supply of this actuator cannot be individually replaced. - Page 7 ONE-X K148-A 06/2020 Actuator Type BFL(T)/BLF(T) on Type MFUS(P) on Type CFTH on CR60/CR120/CU-LT(1s): CR60/CR120/CU-LT(1s): CR2/CU2/CU4/CU2-15: 1. Unlock the motor by 1. Unlock the existing 3. Replace the old 1. Unlock the existing interrupting the power mechanism by pressing membrane by the new mechanism.
- Page 8 ONE-X K148-A Actuator 06/2020 OuntinG the new mechanism On CR60/CR120/CU-LT(1s) 1. Put the new membrane 4. Connect the motor in place. according to the wiring 2. Make sur the damper diagram. blade is closed. 5. Test the functioning of 3. Fasten the ONE on the motor.
- Page 9 AMS are the originators of SAFE4 in 2005 which we now promote as SureFire – a range of fire and smoke rated ductwork and insulation to compliment Rf-t complete range of dampers. We are fully FPC approved CE manufacturer of harmonized ductwork products to current EN regulations and BS 476.
- Page 10 AMS Air Movement Supplies, Unit 23, Second Avenue, Cookstown Ind. Est., Tallaght, Dublin 24, D24 FP95, Ireland. Ph: +353 1 463 4300 Email: info@airmovementsupplies.ie www.airmovementsupplies.ie " He that succeeds makes an TRUSTED PARTNER OF important thing of the " immediate task.
