Controls and functions

Projector
1
2
3
4
5
6
4
7
8
1. Focus ring
Adjusts the focus of the projected image.
See "Fine-tuning the image size and clarity"
on page 26 for details.
2. Zoom ring
Adjusts the size of the image. See
tuning the image size and clarity" on page
26 for details.
3. LAMP indicator light
Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem. See
details.
4. Keystone/Arrow keys (
Down)
Manually corrects distorted images
resulting from an angled projection. See
"Correcting keystone" on page 26
details.
5. Left/Blank
Used to hide the screen picture. See
the image" on page 39
10 Introduction
"Fine-
"Indicators" on page 61
/ Up,
for
for details.
6. Mode/Enter
Selects an available picture setup mode.
See "Selecting a picture mode" on page 34
for details.
9
Activates the selected On-Screen Display
(OSD) menu item. See
on page 27
10
7. Source
Displays the source selection bar. See
"Switching input signal" on page 31
11
details.
8. I Power/POWER indicator light
I
Toggles the projector between standby
mode and on.See
projector" on page 24
the projector" on page 42
Lights up or flashes when the projector is
under operation. See
61 for detail.
9. TEMPerature indicator light
Lights up red if the projector's
temperature becomes too high. See
"Indicators" on page 61
10. Right/Auto
for
When the On-Screen Display (OSD)
menu is activated, the #4, #5, and #10 keys
/
are used as directional arrows to select the
desired menu items and to make
adjustments. See
page 27
Automatically determines the best picture
timings for the displayed image. See
"Auto-adjusting the image" on page 25
"Hiding details.
11. Menu/Exit
Turns on the On-Screen Display (OSD)
menu. Goes back to previous OSD menu,
exits and saves menu settings.
"Using the menus"
for details.
"Starting up the
and "Shutting down
for details.
"Indicators" on page
for details.
"Using the menus" on
for details.
for
for
