INSTRUCTIONS
INSTALLATION AND OPERATION
MODEL V390APT WEATHERPROOF HEAVY-DUN PAN-AND-TILT DRIVE
The information in this instruction manual covers the
installation, operation, and maintenance of the
ual, the term V39OAPT and V39OAPT-PP refers to both
models unless stated otherwise.
This unit should be installed by a qualified technician
using approved materials and wiring practices in con-
formance with national, state and local electrical codes.
Model V39OAPT Pan-and-Tilt Drive is a weatherproof,
heavy-duty unit capable of operating with loads up to
80
pounds (36 kg). When mounted in an inverted posi-
tion, it will operate with loads up to 75 pounds (34 kg).
The heavy-duty motors are constructed with hardened-
steel gears that never require lubrication. All-weather
protection is provided by "0" rings and gasket seals with
Teflon* wear surfaces. Solenoid operated brakes pro-
vide excellent operating stability with minimum coast.
Counterbalanced tilt arms provide smooth, reliable tilt
operation.
CONTROL
CONTROL
Figure 1
Operating Distances With
and Without Relay Box
Product specifications subject to change without notice.
FOR
1. INTRODUCTION
PAN/TILT
PAN/TILT
TOLL FREE: l-800-645-9116 (OUTSIDE OF NEW YORK)
This 120 VAC unit may be operated directly by a control
or by a combination of a control and a relay box when
greater operating distances are required. Refer to Figure
1 and Table 1 for maximum operating distances. If a
preset position option is required, use Model V129-8PP
Preset Position Control or the VPS324TM or VPS1200
systems.
The V39OAPT is UL listed under Standard 1409.
CAUTION: Mounting the unit outdoors in an
A
inverted position voids the product warranty.
TABLE 1
MAXIMUM OPERATING DISTANCES
Control
Relay Box
Model
kademark of DuPont DeNemours,
Cable Slze
Maxlmum
(AWG)
Distance
Annealed
Covver
20
18
1 6
14
22
20
18
part number 8006-8433-02-00
