- Page 1 PV System Installation Manual...
-
Page 2: Table Of Contents
Contents Purpose of this guide Features & Benefits Notices General safety Handling safety Installation safety Fire safety Production Identification Mechanical Installation Grounding Electrical installation Maintenance and care Disclaimer of liability Products Data... -
Page 3: Purpose Of This Guide
• SUNMAN’s eArc are tested and certified for installations worldwide. Different regions may have different regulations for solar PV installations. © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com... -
Page 4: Features & Benefits
• Maximization installation coverage of panels over any kind of roof. • Quick installation • Ultra-thin and light design to save installation labour © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A... -
Page 5: Notices
For additional technical support documentation, please visit the Support page of the SUNMAN web site at www.sunman-energy.com © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A... -
Page 6: General Safety
General safety • eArc that fall under this application class may be used in system operation at more than 50V DC or 240W, where general contact access is anticipated. eArc are qualified for safety under IEC 61730-2 and within this application class are considered to meet the requirements for Safety Class II. -
Page 7: Handling Safety
“on a soft flat surface” to prevent water from collecting inside the panel and causing damage to exposed connectors. © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com... -
Page 8: Installation Safety
• Contact with electrically charged parts of the panels, such as terminals, can result in burns, sparks and lethal shock whether or not the panel is connected. • Do not touch eArc unnecessarily during installation. The front surface and the ribs may be hot; there is a risk of burns and electric shock. -
Page 9: Fire Safety
• Do not use panels near equipment or in places where flammable gases may be generated. • eArc have been rated Fire Class C, and are suitable for mounting on to a Class A roof. © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. -
Page 10: Production Identification
XXXX160417XXXXXXXX means the module was made in the 17th week of 2016. Each module has only one bar code. It is permanently attached to the interior of eArc and is visible from the top front of eArc. This bar code is inserted prior to lamination. -
Page 11: Mechanical Installation
• eArc should not be shaded at any time. If an eArc is shaded or even partially shaded, it will fail to perform at ideal conditions and result in lower power output. - Page 12 • Please clearly identify the roof material before installation as the type of the roof material directly affects the strength of the adhesion. © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com...
- Page 13 8mm long. This will ensure proper wet-out onto the substrate and a uniform adhesive thickness is achieved. Fix the nozzle onto the silicone gun. © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com...
- Page 14 See note from Sika installation manual below on how to check for the presence of a “skin” over the silicone: © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com...
- Page 15 Layout of SMD Series • Layout (For SMD Series: SMDxxxM-6X12DW, SMDxxxM-6X12UW, SMDxxxM-6X10DW, SMDxxxM- 6X10UW) © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 13 / 29...
- Page 16 • Layout (For SMD Series: SMDxxxM-4X12DW, SMDxxxM-4X12UW, SMDxxxM-4X09DW, SMDxxxM- 4X09UW) • Layout for landscape installation with generic roof profile © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 14 / 29...
- Page 17 • Layout for portrait installation with generic roof profile © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 15 / 29...
- Page 18 Framed Installation ▶For SMB Series SMBxxxM-6X10DW, SMBxxxM-4X12DW, SMBxxxM-4X09DW, SMBxxxM-6X12UW, SMBxxxM-6X10UW, SMBxxxM-4X12UW, SMBxxxM-4X09UW, SMBxxxF-6X24DW, © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 16 / 29...
- Page 19 4X09DW, SMBxxxM-6X12UW, SMBxxxM-6X10UW, SMBxxxM-4X12UW, SMBxxxM-4X09UW, SMBxxxF- 6X24DW; SMBxxxF-6X20DW; SMBxxxF-4X24DW; SMBxxxF-4X18DW; SMBxxxF-6X24DB; SMBxxxF- 6X20DB; SMBxxxF-4X24DB; SMBxxxF-4X18DB ) © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 17 / 29...
- Page 20 SMBxxxF-6X24DB SMBxxxM-6X10DW; SMBxxxM-6X10UW; SMBxxxF-6X20DW; SMBxxxF-6X20DB SMBxxxM-4X12DW; SMBxxxM-4X12UW; SMBxxxF-4X24DW; SMBxxxF-4X24DB SMBxxxM-4X09DW; SMBxxxM-4X09UW; SMBxxxF-4X18DW; SMBxxxF-4X18DB © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 18 / 29...
-
Page 21: Grounding
This branch of earth cable can then be connect to the main return earth cable going back to a common ground. © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com... - Page 22 Third party grounding solutions are acceptable. These solutions must comply with local standards and all associated manufacturer instructions. © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A...
-
Page 23: Electrical Installation
• The maximum number of series connected eArc depends on system design, the type of inverter used and environmental conditions. • Please make sure no more than two strings in parallel if eArc without any fuse or blocking diode to be connected according to the maximum series fuse rating of eArc and local electrical installation code. -
Page 24: Maintenance And Care
Contact the installer Contact the local distributor of the Sunman panel © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 22 / 29... -
Page 25: Disclaimer Of Liability
SUNMAN reserves the right to change the manual, eArc, the specifications, or product information sheets without prior notice. © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com... -
Page 26: Products Data
10.72 1615mm X 705mm X 35mm 6.6kg SMBxxxF-4X18DB (200-215) 20.8 10.10 24.7 10.58 © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 24 / 29... - Page 27 9.85 SMDxxxM-4X12UW 2031mm X 700mm X 5.6m 5.0kg (158.75) 26.5 9.25 31.9 9.77 © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 25 / 29...
- Page 28 9.85 SMFxxxM-4X12UW 2002mm X 671mm X 2mm 4.0kg (158.75) 26.5 9.25 31.9 9.77 © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 26 / 29...
- Page 29 1531mm X 689mm X 5.6mm 3.8kg (156.75) 18.9 8.74 23.5 9.28 18.6 8.61 23.2 9.17 © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 27 / 29...
- Page 30 (156.75) 38.3 8.75 47.3 9.31 38.0 8.69 47.1 9.22 37.7 8.63 46.9 9.13 © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 28 / 29...
- Page 31 1502mm X 660mm X 2mm 2.9kg (156.75) 18.9 8.74 23.5 9.28 18.6 8.61 23.2 9.17 © 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2021A page 29 / 29...
