- Page 1 eArc™ PV System Installation Manual...
-
Page 2: Table Of Contents
Contents Purpose of this guide Features & Benefits Notices General safety Handling safety Installation safety Fire safety Production Identification Mechanical Installation Grounding Electrical installation Disclaimer of liability Products Data... -
Page 3: Purpose Of This Guide
• SUNMAN’s eArc are tested and certified for installations worldwide. Different regions may have different regulations for solar PV installations. © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com... -
Page 4: Features & Benefits
• Maximization installation quantity of eArc at any kinds roof. • Quick installation • Ultra-thin and light to save inatallation labor by a large margin. © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A... -
Page 5: Notices
For additional technical support documentation, please visit the Support page of the SUNMAN web site at www.sunman-energy.com © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A... -
Page 6: General Safety
• Do not attempt to disassemble eArc, and do not remove any attached nameplates or components from eArc. © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A... -
Page 7: Installation Safety
Accordingly, the values of Isc and Voc marked on this eArc should be multiplied by a factor of 1.25 when determining component voltage © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com... -
Page 8: Fire Safety
• eArc should not be shaded at any time. If an eArc is shaded or even partially shaded, it will fail to © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. - Page 9 Quick bonding can be direct to the roof or on Aluminium 6065-T5 raining, such as the product from Unistrut. © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com...
- Page 10 • Clean off excess dirt and debris off the roof sheet with rags and water. Leave to dry. If it is extremely dirty, pressure cleaning with water is recommended. © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com...
- Page 11 SMDxxxM-4X09DW SMDxxxM-6X10UW SMDxxxM-4X09UW 665mm 995mm • Please see below for proper bead application © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A page 9 / 18...
- Page 12 • Layout (For SMD Series: SMDxxxM-6X12DW, SMDxxxM-6X12UW, SMDxxxM-6X10DW, SMDxxxM- 6X10UW) • Layout (For SMD Series: SMDxxxM-4X12DW, SMDxxxM-4X12UW, SMDxxxM-4X09DW, SMDxxxM- 4X09UW) © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A page 10 / 18...
- Page 13 • Horizontal installation of SMA series components. © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A page 11 / 18...
- Page 14 • Layout(For SMA Series: SMAxxxM-6X12DW, SMAxxxM-6X10DW, SMAxxxM-4X12DW, SMAxxxM- 4X09DW, SMAxxxM-6X12UW, SMAxxxM-6X10UW, SMAxxxM-4X12UW, SMAxxxM-4X09UW ) © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A...
-
Page 15: Grounding
This branch of earth cable can then be connect to the main return earth cable going back to a common ground. © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com... -
Page 16: Electrical Installation
• Any hardware used must be compatible with the mounting structure material to avoid galvanic corrosion. • It is not recommended to use eArc with different configurations in the same system. © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A... -
Page 17: Disclaimer Of Liability
© 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com... -
Page 18: Products Data
5.6mm 1690mm X 1019mm X SMDxxxM-6X10UW SMD295M-6X10UW 32.8 9.00 40.1 9.52 5.6kg 5.6mm © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A page 16 / 18... - Page 19 1666mm X 995mm X 35mm 7.7kg SMA270M-6X10UW 31.8 8.50 39.1 9.07 1666mm X 995mm X 35mm 7.7kg © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A page 17 / 18...
- Page 20 1507mm X 665mm X 35mm 5.1kg SMA160M-4X09UW 18.6 8.61 23.2 9.17 1507mm X 665mm X 35mm 5.1kg © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A page 18 / 18...
