TRANSLATION OF THE ORIGINAL INSTRUCTIONS
These instructions apply only for the destination countries listed on the appliance's data
plate.
This is a class 3 built-in hob.
We advise you to read this manual carefully, which contains all the instructions for
maintaining the appliance's aesthetic and functional qualities.
For further information on the product: www.smeg.com
Contents
42
42
46
46
47
48
48
49
51
51
52
52
60
63
64
66
69
70
70
70
70
70
71
72
72
73
73
73
73
75
41
Advertisement
Table of Contents
Related Manuals for Smeg SI1M4744D
Summary of Contents for Smeg SI1M4744D
-
Page 1: Table Of Contents
These instructions apply only for the destination countries listed on the appliance's data plate. This is a class 3 built-in hob. We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com... -
Page 2: Instructions
Instructions 1 Instructions • Cleaning and maintenance must not be carried out by 1.1 General safety instructions unsupervised children. • Be aware of how rapidly the Risk of personal injury cooking zones heat up. Do not let • During use the appliance and its pans heat up when dry, as there is accessible parts become very hot. - Page 3 Instructions • Do not use or store flammable Risk of damaging the appliance materials near the appliance or • Do not use abrasive or corrosive directly underneath the hob. detergents (e.g. scouring • DO NOT USE AEROSOLS IN powders, stain removers and THE VICINITY OF THIS metallic sponges) on glass parts.
- Page 4 Instructions • All pans must have smooth, flat Installation bottoms. • THIS APPLIANCE MUST NOT BE • If any liquid does boil over or spill, INSTALLED IN BOATS OR remove the excess from the hob. CARAVANS. • Take care not to spill acid •...
- Page 5 Instructions For this appliance • Supervise children carefully as they cannot readily see the • If cracks or fissures form, or if the residual heat indication. After use glass ceramic cooking surface the cooking zones remain hot for breaks, turn off the appliance a certain period of time even if immediately.
-
Page 6: Appliance Purpose
Instructions • This appliance complies with the 1.4 Identification plate current standards and directives The identification plate bears the regarding safety and technical data, serial number and electromagnetic compatibility. It is brand name of the appliance. Do not however recommended for remove the identification plate for pacemaker wearers to maintain a any reason. -
Page 7: How To Read The User Manual
Instructions • Deliver the appliance to the 1.7 How to read the user manual appropriate recycling centre for This user manual uses the following reading electrical and electronic conventions: equipment waste, or return it to Instructions the retailer when purchasing an General information on this user equivalent product, on a one for manual, on safety and final... -
Page 8: Description
Description 2 Description 2.1 General description 60 cm (3 cooking zones) 60 cm (4 cooking zones) 75 cm Maximum absorbed power table (Watt) Dimensions Level 9 Booster Double Booster H x L (mm) Zone 1/ 2: Single 180 x 218 2100 2500 3000... -
Page 9: Control Panel
Description 2.2 Control panel 1 On/Off button 2 Settings icons 3 Cooking zone display 4 Timer display 5 Settings menu button 6 Auto-Vent 2.0 function button 7 Grill function button 8 Scroll bar... - Page 10 Description Advantages of induction cooking Power control The hob is fitted with a power control The appliance is equipped with an module that optimises/limits consumption. If induction generator for each the overall set power level exceeds the cooking zone. Each generator maximum limit permitted, the electronic located under the glass ceramic circuit board will automatically manage the...
-
Page 11: Use
3 Use High temperature Danger of fire or explosion 3.1 Instructions High temperature • Do not use or leave flammable materials near the appliance or directly Danger of burns underneath the hob. • Do not cook in closed tins or containers, •... -
Page 12: Preliminary Operations
3.2 Preliminary operations List of icons In order to remove any moisture that could Warming function icon. have accumulated during the manufacturing process and for the electronic circuits and Timer icon. control keypad to work properly: 1. Remove the protective films from the Pause function icon. - Page 13 Cooking zones display Bear in mind the following: • Do not exceed the limits of the zones printed on the hob. • Do not cover the control panel. • Do not place the pans next to the edges of the glass. The buttons for selecting the cooking zones •...
- Page 14 Unsuitable cookware: Protection from overheating • Copper, stainless steel, aluminium, If the hob is used on full power for a long fireproof glass, wood, ceramic and period, the electronics will have trouble terracotta cookware. cooling down if the room temperature is To see whether the pan is suitable, bring a high.
- Page 15 • If possible, always cover saucepans with Switching the hob on and off a suitable lid. Keep the On/Off button pressed in • Choose a pan suitable for the quantity of for at least 1 second to activate the hob. food to be cooked.
- Page 16 • The button corresponding to the zone on Adjusting the cooking zone which the pan has been placed turns on After having selected/activated a cooking zone: automatically and displays . The 1. Place a finger on the left-hand side of the other zones cannot be activated.
- Page 17 The display of the zone being used Booster Function indicates Improper use Danger of burns Hold the On/Off button • Do not use the Booster and Double down for at least 2 seconds to Booster functions to heat fats or oils as switch off all cooking zones at the they could catch fire.
- Page 18 The display of the cooking zone used will Multizone function show . Select any other power level to This function can be used to operate two deactivate the Booster function. cooking zones (front and The Booster function can be activated rear) when using pans like fish quickly.
- Page 19 The same power level will be set for both cooking zones. It is only possible to activate the Multizone function between zones 1 and 2. Example of incorrect pan position • This function automatically divides the power equally between both of the hot plates in use.
-
Page 20: Additional Functions
Cooking guidelines Residual heat indication The table below shows the power values Improper use which can be set, together with the Danger of burns corresponding type of food. Settings may vary depending on the amount of food and • Supervise children carefully as they consumer taste. - Page 21 After selecting a cooking zone: Independent timer • Press and hold a power level (from 1 to • This function is used to set a 8) for at least 3 seconds. countdown timer that will emit a sound at the end of the pre-set •...
- Page 22 7. When the time elapses, a series of beeps Modifying and deactivating the independent timer will be emitted and the timer display will start to flash. Press the timer display to If you modify a timer that has deactivate the buzzer. already been started, it has to be reset from the beginning.
-
Page 23: Special Functions
Recall Function symbol appears on the front zone This is used to restore some display and the symbol appears on the functions that have already been started after the appliance has rear zone display. The scroll bar will be set been switched off unintentionally. -
Page 24: Settings Menu
This function has an automatic and a 3.6 Settings menu manual mode: The settings menu allows you to modify • Automatic mode (default), adjusts the some of the operating characteristics of the hood extractor fan speed according to appliance and allows you to the total power of the appliance (see With the appliance switched on, press the “User menu”... - Page 25 To deactivate the Pause function: At least one cooking zone must be active in order for the Clean function to be used: 1. Access the settings menu. 1. Access the settings menu. 2. Press the segment of the scroll bar below 2.
-
Page 26: User Menu
3.7 User menu Button sound volume The user menu allows you to modify the Allows you to adjust the volume of operating characteristics of the appliance. the sounds associated with The user menu contains 9 options that can pressing the buttons. be modified. - Page 27 4. The following appear on the cooking Press the timer display to enable changes to the power settings. Then press the left half of zone displays: the scroll bar to decrease the power or the 3 cooking zones models: right half to increase it. Keep the button pressed to reach the required setting more quickly.
- Page 28 • After selecting an option, press the front Option U4 modifies the brightness of the display. 10 levels can be selected. left display to modify it. • 0: maximum brightness. According to the adjustment range • 9: minimum brightness. of each option, the scroll bar will Option U5 allows you to modify the type of show only those segments that animation of the seconds countdown of the...
-
Page 29: Error Codes
Option U8 allows you to activate the Auto- Exiting the user menu Vent 2.0 function in automatic mode. 8 There are two ways to exit from the user levels can be selected. The following table menu: summarises the possible settings: 1. -
Page 30: Cleaning And Maintenance
Cleaning and maintenance 4 Cleaning and maintenance 4.3 Ordinary weekly cleaning Clean and maintain the hob once a week 4.1 Instructions using an ordinary glass cleaning product. Always follow the manufacturer’s Improper use instructions. The silicon in these products Risk of damage to surfaces creates a protective, water-repellent membrane which also resists dirt. -
Page 31: What To Do If
Cleaning and maintenance Changes in colour do not affect the The cooking results are unsatisfactory: operation and stability of the glass. These • Make sure that the cooking temperature are not alterations to the material of the hob is not too high or too low. but just residues which have not been The hob smokes: removed and have then carbonised. -
Page 32: Installation
Installation 5 Installation • 220-240 V / 380-415 V 2N~ 5.1 Electrical connection Power voltage Danger of electrocution 6 x 1.5 mm² six-core cable. • Have the electrical connection performed by authorised technical personnel. • Use personal protective equipment. • The appliance must be connected to earth in compliance with electrical system safety standards. -
Page 33: Instructions For The Installer
Installation Testing 5.4 Power limitation The appliance is factory set to use the At the end of installation, carry out a brief maximum available power: 7.4 kW. inspection test. If the hob fails to operate, after checking that you have carried out the The maximum power of the instructions correctly, unplug the appliance appliance can be regulated via... - Page 34 Installation Flush mounting dimensions (mm) Overall dimensions (mm) For this type of mounting, you have to make an additional cut at the edges of the recess if you wish to install the hob flush with the countertop. 555 ÷ 560 478 ÷...
-
Page 35: Mounting
Installation After laying the adhesive seal (A) on the glass surface and after positioning and securing the hob, fill the edges with insulating silicone (B) and wipe away any excess. In the event the hob needs to be removed, cut the silicone using a cutter before attempting to remove it (C). - Page 36 Installation opens on rear Failure to install the double-layer wooden base exposes the user to possible accidental contact with Spring clips sharp or hot parts. To ensure the hob is fixed and centred as accurately as possible, the clips provided Ventilation must be positioned as described below: The illustrations below show two examples...
