We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• During use the appliance and
its accessible parts become
very hot. Keep children well
away from the appliance.
• Protect hands with heat resistant
gloves during use.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
91477A921/A
21
21
24
25
25
25
25
26
26
26
27
27
27
28
28
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
eight at a safe distance unless
they are constantly supervised.
• Keep children under the age of
8 away from the appliance
when it is in use.
• Cleaning and maintenance
must not be carried out by
unsupervised children.
• Be aware of how rapidly the
cooking zones heat up. Do not
place empty pans on the heat.
Danger of overheating.
• Activate the controls lock when
28
29
30
32
32
33
33
33
34
34
34
35
36
36
37
37
PRECAUTIONS - 21
Advertisement
Table of Contents
Related Manuals for Smeg Universale Aesthetic SI4742D
Summary of Contents for Smeg Universale Aesthetic SI4742D
-
Page 1: Table Of Contents
Basic functions Instructions for the installer We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions that they are supervised or... - Page 2 you have children or pets which such as dishes or cutlery, on the could reach the hob. surface of the hob during • Do not touch or clean the hob cooking as they may overheat. surface during operation or • Do not cook foods in closed when the residual heat tins or containers or plastic indicator lights are still on.
- Page 3 surfaces. removers and metallic • Before performing any work on sponges) on glass parts. the appliance, switch off the • Use wooden or plastic utensils. power supply. • Do not sit on the appliance. • Do not try to repair the •...
-
Page 4: Installation
substances such as lemon juice installed on a dishwasher. or vinegar on the hob. • Position the appliance into the • Do not spill sugar or sweet cabinet cut-out with the help of mixtures on the hob during a second person. cooking. -
Page 5: Appliance Purpose
• The power cable must only be metres above sea level. installed or replaced by a Appliance purpose qualified technician. This appliance is intended for • If the power cable becomes cooking food in the home damaged, contact technical environment. Every other use is support immediately to arrange considered inappropriate. -
Page 6: Disposal
Disposal the pressure cooker and the cooking zone. • If possible, always cover pans with a This appliance conforms to the WEEE suitable lid. European directive (2012/19/EU) and • Choose a pan suitable for the quantity of must be disposed of separately from food to be cooked. -
Page 7: Description
DESCRIPTION General description Power draw in booster Zone Dimensions H x L (mm) Power draw at lev. 9 (W)* function (W) * 1 - 3 160 x 160 1400 2100 2 - 4 200 x 200 2300 3000 *Power levels are approximate and may vary according to the pan used or the settings made. Advantages of induction cooking Control panel The appliance is equipped with an... -
Page 8: Use
the hot plates. The module tries to maintain the maximum deliverable power levels. Levels set by Priority is given to the last zone set. the automatic control will appear on the display. The power control module does not affect the total power consumption of the appliance. -
Page 9: Using The Hob
the pressure cooker and the cooking zone. 2. The display corresponding to the zone on which the container has been placed turns • If possible, always cover the pans with a suitable lid. on automatically and displays • Choose a pan suitable for the quantity of food to be cooked. -
Page 10: Additional Functions
Quick selection 3. The pause function has now been deactivated and the previously set functions The appliance is fitted with an automatic are restored. pan sensing system. The cooking time limitation, the residual After switching on the appliance and having heat indicators and the control lock selected a cooking zone: function remain enabled during the... - Page 11 After selecting a cooking zone: 3. Pressing again will cause the digit on the left to flash. It is now possible to set the minutes • Press and hold a power level (from 1 to 8) for at least 3 seconds. using the scroll bar (e.g.
-
Page 12: Safety Features
Recall Function Setting the power level of the appliance This is used to restore some functions • This function allows you to set the that have already been started after the maximum power limit for your appliance has been switched off appliance. -
Page 13: Cleaning And Maintenance
Support. CLEANING AND MAINTENANCE Cleaning the glass ceramic hob bases of pans, especially aluminium ones, rubbing on the surface, and due to the use of unsuitable detergents. They are difficult to See General safety instructions. remove using conventional cleaning products. It may be necessary to repeat the cleaning Cleaning the surfaces process several times. -
Page 14: Installation
disconnect the power supply and contact Technical Support. INSTALLATION Electrical connection Fixed connection Fit the power line with an all-pole circuit breaker with a contact separation distance sufficient to See General safety instructions. provide complete disconnection in category III overvoltage conditions, pursuant to installation General information regulations. -
Page 15: Mounting
Appliance overall dimensions (mm) edge of the hob before assembly. MODELS (cm) Do not use silicone to secure the hob. This would make it impossible to remove the hob without damaging it. Standard and flush mounting (mm) In the case of flush mounting, after placing the adhesive seal (A) on the glass surface and after positioning and securing the hob, fill the edges with insulating silicone (B) and wipe off any... -
Page 16: Ventilation
the top of the appliance installed below. opens on rear: Failure to install the double-layer wooden base exposes the user to possible accidental contact with sharp or hot parts. If installed on top of an oven, the latter must be equipped with a cooling fan. Ventilation On top of empty kitchen unit or drawers The illustrations below show two examples of... -
Page 17: Fixing To The Built-In Cabinet
2. Then turn them upwards to fix them in place. Fixing to the built-in cabinet In order to ensure fixing to the built-in cabinet and optimum centring, the supplied fixing brackets must be screwed into the holes in the bottom casing. Screw the fixing brackets into the dedicated holes to properly fasten the hob to the built-in structure.
