Summary of Contents for Fluance Ai41
- Page 1 Ai41 - Powered Bookshelf Speakers Manual v1.0 Serious Performance Fluance.com ™...
-
Page 2: Table Of Contents
Table Of Contents Introduction ............. 3 Break-in Period ............3 Online Resources........... 3 What’s Included .............4 Front & Back Panel Layout ....... 5 Remote Control Layout ........6 Product Setup ............7 Turning On/Off Unit ..........8 Source Selection ............ 8 RCA Input .............. -
Page 3: Table Of Contents Introduction
Fluance Ai41 User Manual Introduction Thank you for your purchase of your Fluance product. We hope you enjoy your experience. If you have any questions please visit us at: Fluance.com/support Fluance believes everyone should experience audio in its truest form, recreating the per- formance the way the artist intended. -
Page 4: What's Included
Fluance Ai41 User Manual What’s Included VOL + VOL - TREBLE BASS Ai41 Passive Ai41 Active Remote 2 ‘AAA’ Power Speaker Speaker Control Batteries Cable (Left Channel) (Right Channel) LIFETIME Customer Support Speaker Quick Start Lifetime 2 Year Wire Guide... -
Page 5: Front & Back Panel Layout
Fluance Ai41 User Manual Front & Back Panel Layout Active Speaker - Front Control Knob • Volume • Input Selection • Power ON/OFF 2. Source LED • Blue (Solid) - Bluetooth Paired ® • Blue (Flashing) - Bluetooth Pairing ®... -
Page 6: Remote Control Layout
Fluance Ai41 User Manual Passive Speaker - Back 11. Speaker Input Remote Control Layout 1. Power ON/OFF 2. Volume UP/DOWN 3. Source VOL + 4. Treble UP/DOWN 5. Mute VOL - 6. Play/Pause & Bluetooth Pairing Reset* *To enable Bluetooth Pairing Reset, press + hold for 3 seconds. -
Page 7: Product Setup
Fluance Ai41 User Manual Product Setup 1. Position the speakers with the Active Speaker on the right and the Passive Speaker on the left. Passive Speaker Active Speaker NOTE: If placing the speakers in a cabinet or on a shelf, position the front of the speakers as close as possible to the front edge of the shelf for optimum audio performance. -
Page 8: Turning On/Off Unit
Fluance Ai41 User Manual Turning On/Off Unit Press the Control Knob to turn on Press on the Remote to turn the unit. Hold to turn off the unit. the unit on/off. VOL + VOL - TREBLE BASS Source Selection Press the Control Knob to cycle through... -
Page 9: Rca Input
4. Adjust volume on Ai41 as the RCA input (Green LED). well as source device. NOTE: When connecting a turntable to the Ai41, a phono preamplifier (preamp) must be used. Some turntables include a built-in preamp but others, without one, would require an external preamp. -
Page 10: Bluetooth ® Pairing
Fluance Ai41 User Manual Bluetooth Pairing ® 1. Press the Control Knob to select 2. Pair to “Fluance Ai41” on your the Bluetooth input (Blue LED). source device. Settings Bluetooth MY DEVICES Fluance Ai41 NOTE: Unit will attempt to auto-pair to the last paired device. -
Page 11: Optical Input
Optical Audio Signal Compatibility The Ai41 does not support Dolby Digital Audio or DTS Audio. Locate the audio output settings on your source device and ensure Dolby Digital is turned off. The correct audio output setting is commonly referred to as PCM or Stereo. -
Page 12: Subwoofer Output
Fluance Ai41 User Manual Subwoofer Output IMPORTANT: When a subwoofer cable is connected, the Ai41 will automatically cut frequencies below 80Hz to optimize performance. The subwoofer cable must be removed to resume full frequency playback. 1. Connect the Subwoofer cable to your powered subwoofer. -
Page 13: Volume Adjustment
Fluance Ai41 User Manual Volume Adjustment Turn the Control Knob or use the Remote to increase or decrease volume. EQ Adjustment Use the Bass/Treble buttons on the Remote to adjust each from -5 to +5. LED Behavior: Red (Flash 2x) – Bass/Treble Set to -5 or +5 Bluetooth: Blue (Flash 2x) –... -
Page 14: Frequently Asked Questions
The different signal types used by each input means they are processed differently by the Ai41. The Optical Input uses a digital signal while the RCA Input uses an analog signal. These differences can result in slight variances in the output volume of the Ai41. -
Page 15: Troubleshooting
• Check all connections on power adapter and ensure fully inserted No Audio • Check volume on Ai41 and ensure it is above 0 • Check volume on source device and ensure it is above 0 • Confirm Ai41 is set to correct source •... -
Page 16: Specifications
Fluance Ai41 User Manual Specifications 2 Way – 2 Driver Bookshelf Speaker SPEAKER CONFIGURATION System with Integrated Amplifier BLUETOOTH Yes; BT 5.0 INPUTS RCA, Bluetooth, & Optical TWEETER 1 inch Silk Soft Dome Ferrofluid Cooled 5 inch Woven, Glass Fiber Composite... -
Page 17: Certification Information
Fluance Ai41 User Manual Certification Information FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 18: Warranty Information
Warranty Information Fluance gives the following warranty to the original customer of each new Fluance product purchased from a dealer authorized by Fluance. Fluance warrants that each new product, under normal use, is free from defects, subject to the terms and conditions set forth. If a... - Page 19 Should your Fluance product require warranty service, please contact your Fluance Authorized Dealer and send your product fully insured and freight prepaid to the nearest Fluance authorized service center. Before sending to Fluance, you will be required to get a Return Authorization Number from your dealer.
- Page 20 Thank you for your purchase of this Fluance product. ® We hope you enjoy your experience. Questions? Give us a chance to help, we’re just a click away. Fluance.com/resources Fluance.com/support Fluance.com/videos Fluance.com/contact Don’t forget to register your product with us!
