FlySky FS-i6X User Manual page 23

VA 73x39mm, LCD with white backlight
Model type: Multi-rotor
2.4GHz system: AFHDS 2A
DSC port: PPM/i-BUS/S.BUS
FS-A8S
Transfer method: FHSS
Receiver
Data output: 1.5mm*3 Pin PPM/i-BUS/S.BUS
Display method: LED
No ground interference ( Transmitting and receiving 1
m from the ground): >300m
Working current: 40mA
Each channel data: depend on the transmitter
Channel delay: <15mS
Size: 20*14*5.3mm
Weight: 392g
Power: 6V DC 1.5AA*4
Display: STNTransflective Display, LCD 128x64 Lattice,
Size: 174x89x190mm
On-line Update: Yes
Color: Black
Certificate: CE0678, FCC ID: N4ZFLYSKYI6X
Brand Name:Flysky
Item Name:FS-A8S Receiver
Channels: PPM 8CH, i-BUS 18CH
Frequency range: 2.408-2.475GHz
Band width: 500KHz
Band number: 135
RX Sensitivity: -92 dBm
Modulation type: GFSK
Antenna length: 26mm (Not including brass contacts)
Input power supply: 4.0-8.4V
Weight: 1.2g
