- Page 1 SOLEIL SRT 1.5-6k 1ph String PV Grid-tied Inverter User Manual KEEP FOR FUTURE REFERENCE for the entire life of the appliance User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 1 of 56 +FR...
- Page 2 User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 2 of 56 +FR...
- Page 3 User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03...
- Page 4 The manual is suitable for following models: l SOLEIL SRT 1.5K, SOLEIL SRT 2K, SOLEIL SRT 3K l SOLEIL SRT 3.6K, SOLEIL SRT 4K, SOLEIL SRT 4.6K, SOLEIL SRT 5K, SOLEIL SRT 6K User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03...
- Page 5 Provides a tip that may help you solve a problem or save time. Provides additional information to emphasize or supplement important points in the main text. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 5 of 56 +FR...
-
Page 6: Table Of Contents
3.2.1 Tools ..............................20 3.2.2 Installation Environment ........................21 3.2.3 Installation Space ..........................22 3.2.4 Installation Way ............................ 23 3.3 Transportation and unpacking ........................23 User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 6 of 56 +FR... - Page 7 6 Maintenance and Troubleshooting ..................47 6.1 Maintenance ..............................47 6.2 Troubleshooting .............................. 47 7 Package, Transportation and Storage ..................50 7.1 Package ................................50 7.2 Transportation ..............................50 User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 7 of 56 +FR...
- Page 8 7.3 Storage ................................50 8 Technical Specifications ......................51 9 Reference Standards ........................54 User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 8 of 56 +FR...
-
Page 9: Safety Description
1.1.1 Safety Instructions It is prohibited touching any terminal or conductor that connected with grid circuit, or, it may cause deadly danger. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 9 of 56 +FR... - Page 10 The surface temperature of the inverter may reach to 75 . During running, please don't touch the surface to avoid scald. No liquid or other objects are allowed to enter the inverter. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 10 of 56 +FR...
-
Page 11: Protection For Pv Array
The device must be connected with protection earthing permanently. Before operating, please check the electric connection and ensure the device has been connected to earth reliably. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 11 of 56 +FR... -
Page 12: Moisture-Proof Protection
The grid-connected generation must be allowed by local power supply department and operate by professionals. All the electrical connection must accord with the electrical installation standard of local nation and district. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 12 of 56 +FR... -
Page 13: Measure With Voltage Present
Avoid the inverter suffering directly sunshine, rain or snow to prolong the service life (detail please see 3.2.2 ). If the installation environment does not meet the requirement, the guarantee time may be influenced. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 13 of 56 +FR... - Page 14 The place where has vibration or easy impacted. l The place where has dust, corrosive material, salty or flammable gas. l The place where without good ventilation or closed. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 14 of 56 +FR...
-
Page 15: Overview
Figure2-2 Model meaning illustration As shown in Errore. L'origine riferimento non è stata trovata., "UHK" means that the product is S iel Soleil SRT series PV gird-tied invert. 2.1.2 Product Features l Efficiently power generation: adopt efficient HERIC inverter topology and advanced completely digitized control technology. -
Page 16: Appearance And Structure
Short press: move the cursor downward or decrease the setting value. ENT button Long press: enter sub menu or confirm the current command. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 16 of 56 +FR... -
Page 17: External Terminal Illustration
It needs to provide by customer. Grounding port External grounding port When the DC SWITCH and COM. is not selected, the corresponding port is filled with a waterproof plug. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 17 of 56 +FR... -
Page 18: Work Principle
DC and AC side, as shown inFigure2-6, Figure2-7. Boost Inverter optional circuit circuit GRID Figure2-6 Work principle diagram of SOLEIL SRT 1.5K, SOLEIL SRT 2K User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 18 of 56 +FR... - Page 19 GRID Boost circuit 2 Figure2-7 Work principle diagram of SOLEIL SRT 3K, SOLEIL SRT 3.6K, SOLEIL SRT 4K, SOLEIL SRT 4.6K, SOLEIL SRT 5K, SOLEIL SRT 6K User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 19 of 56 +FR...
-
Page 20: Installation Guide
This chapter introduces the installation of the inverter, including installation process, installation preparation, transportation and unpacking, installation procedure, electrical connection and checking, etc. 3.1 Installation Process Figure3-1 Installation process 3.2 Installation Preparation 3.2.1 Tools Tools User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 20 of 56 +FR... -
Page 21: Installation Environment
Ensure that there has sufficient fresh-air supply around the inverter. l The inverter must be installed on the wall or supporter with enough bearing capacity. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 21 of 56 +FR... -
Page 22: Installation Space
350mm from the top of the inverter to ceiling and keep at least 600mm from bottom of the inverter to ground, which is good for heat dissipation or maintenance, as shown in Figure3-3. Figure3-3 Installation space (unit: mm) User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 22 of 56 +FR... -
Page 23: Installation Way
Check if the types of the accessories are complete and correct. If there is any discrepancy, take notes and contact the distributor immediately. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 23 of 56 +FR... -
Page 24: Installation
Figure3-5 Packing list 1. For SOLEIL SRT 1.5K and SOLEIL SRT 2K, we provide 1 pair of DC terminals, for other models, we provide 2 pairs of DC terminals. 2. WIFI/GRPS and smart meter are optional, they are provided according to the contract. - Page 25 8.5mm on the wall according to marked position, as shown in Figure3-8 Figure3-7 Optimized installation size (unit: mm) When installation, please keep the installation holder horizontal. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 25 of 56 +FR...
- Page 26 Align the holes of installation holder with the expansion plugs and install the self-tapping screws and flat gasket into the expansion plugs (as shown in Figure3-10) and fasten them by screwdriver. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03...
- Page 27 Fasten the inverter to the installation holder by 2 stainless steel combination bolt M5*12 (as shown in Figure3-12), and then lock it. The lock position is as shown in Figure3-13. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03...
-
Page 28: Electrical Connection
4 mm ~ 6 mm AC output (GRID) 2.5 mm (L/N/PE) 4 mm ~ 6 mm (L/N/PE) Grounding wire 2.5mm 4 mm ~ 6 mm User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 28 of 56 +FR... -
Page 29: External Grounding Connection
Figure3-15 External grounding wire connection 3.5.3 DC Input (PV) Connection l When installation, it must use the equipped DC terminals to avoid inverter damage. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 29 of 56 +FR... - Page 30 Crimp the metal terminals firmly by crimping pliers, as shown in Figure3-17. Figure3-17 Crimp the metal terminal User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 30 of 56 +FR...
- Page 31 Figure3-20) and tighten them. If there has a click sound, it means that the connector have been inserted properly. Figure3-20 Connect the DC connector User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 31 of 56 +FR...
-
Page 32: Ac Output (Grid) Connection
Step 1 Strip the insulation layer of AC live wire (L), neutral wire (N) and grounding wire (PE) for about 7mm, as shown in Figure3-21. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 32 of 56 +FR... - Page 33 When crimping the wires, please ensure the live wire, neutral wire and PE wire are connected to the corresponding port of AC connector. Figure3-22 AC connector Figure3-23 Connect the wires of AC connector User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 33 of 56 +FR...
-
Page 34: Wifi/Gprs Connection
If the inverter is equipped with WIFI/GPRS, insert it to the WIFI/GPRS port (as shown in Figure3-25) to monitor on the internet. The monitor way is as shown in Figure3-26. Figure3-25 WIFI/GPRS communication connection User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 34 of 56 +FR... -
Page 35: Communication Port Connection (Optional)
PIN 6: Green - DRM 0 PIN 7: White brown - METER:A PIN 8: Brown - METER:B Figure3-27 Pin definition of inverter’s RJ45 plug User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 35 of 56 +FR... -
Page 36: Check The Installation
Check if the connection of DC input, AC output and communication wire are right. l Check if the inverter is installed firmly. l Check if all the screws of wiring are tightened. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 36 of 56 +FR... -
Page 37: Lcd Operation
Figure4-3 to Figure4-5. The corresponding button function is as shown in Table4-2 Figure4-2 Main page Figure4-3 Grid-connected main page (1) 17/01/01 12:00 E_total 000.0kWh Figure4-4 Grid-connected main page (2) User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 37 of 56 +FR... -
Page 38: Main Menu Page
Short press: move the cursor upward l Long press: back to main page l Short press: move the cursor downward l Long press: enter sub-menu User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 38 of 56 +FR... -
Page 39: Running Information
In main menu page, select Power Query, the LCD will show the power query page. In this page, it shows the daily power and total power, as shown in Figure4-14, corresponding button function is as shown inTable4-5. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 39 of 56 +FR... -
Page 40: Record Query
Figure4-16 Record query page (2) Figure4-17 Current fault page 17/01/01 001: 12:00:00 E001_1 Figure4-18 History fault page Detailed fault info and dispose method please see Table6-1. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 40 of 56 +FR... - Page 41 Table4-8 Button function on record query page Button Function l Short press: move the cursor upward, or add the checked record No. l Long press: back to previous menu page User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 41 of 56 +FR...
-
Page 42: System Setting
Long press: clear enter value, and back to user authority page l Short press: reduce number value l Long press: confirm the current entering, and the cursor move to right User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 42 of 56 +FR... - Page 43 PV mode setting, QV mode setting, etc. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 43 of 56 +FR...
-
Page 44: System Information
In main menu page, select System Info, the LCD will show the system information, as shown in Figure4-31 to Figure4-36, corresponding button function is as shown in Table4-12. > Model Serial No Figure4-31 System information (1) User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 44 of 56 +FR... - Page 45 Short press: move the cursor upward l Long press: back to previous menu l Short press: move the cursor downward l Long press: enter sub-menu User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 45 of 56 +FR...
-
Page 46: Startup And Shutdown
About 60s, the inverter will generate power normally. The grid connection indictor will be on and the LCD will show: "current status: grid-connected". 5.2 Shutdown Step 1 Switch off all switches. Step 2 Wait for all indicators off. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 46 of 56 +FR... -
Page 47: Maintenance And Troubleshooting
If some faults occur, the display screen will show the corresponding alarm information. Under the circumstances, the inverter may stop power generation. The troubleshooting is as shown in Table6-1. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03... - Page 48 Check the environment and see if the environment is too Leakage current E042 moist. protection l Check the grounding connection. l If they are all normal, please contact local distributor. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 48 of 56 +FR...
- Page 49 4. Problem description (that is the alarm information displayed on the display screen and the status of indicators and other information obtained from information menu (refer to 4.3.3 Record Query). 5. Your detail contact information. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 49 of 56 +FR...
-
Page 50: Package, Transportation And Storage
Under the storage conditions above, the storage period is six months. If the inverter is stored beyond six months, it should be rechecked. User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 50 of 56 +FR... - Page 51 26.0 current (A) Inrush Current (peak and 3.7A@11 9.2A@7. 9.0A@7. 8.8A@7. 9.0A@7. 13.0A@ 4.6A@1 7.9A@8, duration) .97ms 11ms 02ms 01ms 44ms 7.67ms 3.6ms .0ms User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 51 of 56 +FR...
- Page 52 Anti-island AC short-circuit protection Leakage current protection (RCD) DC switch Standard PV Fault Detect Input DC impedance monitor Surge protection Yes: Class D, Piezo-resistor User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 52 of 56 +FR...
- Page 53 Plug and play (max. 6mm²) DC terminal MC4 (max. 6mm Other function Whole machine Update online Specifications are subject to change without prior notice. · User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 53 of 56 +FR...
- Page 54 9 Reference Standards The SOLEIL SRT series satisfies the following general standards, where applicable: EN 61000-6-2:2005 EN 61000-6-3:2007 + A1:2011 Low Voltage directive 214/35/EU EN 62109-1:2010 EN 62109-2:2011 CEI0-21 ED. 2016-07 + Ed. 2019-04 (Italy) DIN VDE V 0126-1-1 (VDE V 0126-1-1:2013...
- Page 55 User Manual SOLEIL SRT 1.5-6k 1ph IV430E REV. 00 Issued: 2020/06/03 Pag. 55 of 56 +FR...
- Page 56 Siel Company operates a Quality Management System certified to ISO 9001/2015 (Certification No. CERT-005SGQ04 ITALCERT) covering all company functions from design and manufacture to after sales services. The environmental Management System implemented by Siel Company is in compliance with the standard UNI EN ISO 14001:2015 (ISO 14001:2015) (Certification N°...
