INSTALLATION
The voltage and frequency of the power supply must match the designation on the control nameplate. The control
assembly should be installed close to the equipment, where it is easily seen by and accessible to the operator.
Installation on a wall in a clean, dry, vibration-free location is recommended. Ambient temperature should not
exceed 100ºF (40ºC).
WARNING: The electrical power supply connection to the control must be made
through a customer-supplied safety disconnect switch, which must be mounted
next to the control. Incorporation of an emergency stop may also be required, per
local codes.
When making electrical connections, it is important to follow the wiring diagram supplied with the control.
CAUTION: Nonmetallic enclosure does not provide grounding between conduit connection. Use grounding
bushings and jumper wires.
WARNING: The control must be properly grounded and verified at installation.
Enclosure integrity should be maintained at all times. Ensure any enclosure connectors used will maintain the
designated UL or IEC rating of the supplied unit. Install enclosure lid gasket to maintain the NEMA 4X integrity
rating.
OPERATION
WARNING: The control must be kept closed and secured while in operation.
After the control has been installed and all strain relief connections have been properly completed, the control is
ready for operation. To energize the equipment, place the switch in the ON position. The potentiometer is used
to control the vibration of the equipment. Turning the knob clockwise will increase the amplitude of vibration,
and counterclockwise will decrease the amplitude of vibration.
MAINTENANCE
WARNING: Disconnect the power supply at the safety switch before performing
any maintenance.
The only maintenance required is that the controller be kept reasonably clean.
WARNING: Do not use a damp cloth or water for cleaning. Clean, dry,
compressed air is recommended for cleaning.
