Syntron Material Handling PowerPulse 225490-A Installation Operation & Maintenance

Syntron® PowerPulse

■■■■■■■■■■■■■■■■■■■■■ INSTALLATION ■ OPERATION ■ MAINTENANCE

Thank you for buying your equipment from SYNTRON. This manual will help you to understand

how your equipment operates and what is required to maintain peak performance. Please read

it thoroughly and keep it on file for reference.

Your satisfaction is important to us, so please direct any comments to our Marketing

Communications department.

Date Purchased: ______________________

Part No.: _____________________________

Serial No.: ____________________________

Factory Order No.: _____________________

INTRODUCTION

The PowerPulse 115/230V WT control regulates the vibration amplitude of feeders and vibrators through phase

control provided by a Silicon Controlled Rectifier (SCR). The printed circuit board (PCB) includes an OFF-ON

line switch, a terminal block, and an SCR assembly for converting alternating current to pulsating direct current.

It also includes a potentiometer for controlling the voltage to the equipment. An intermittent switch (C1/C2)

provides the OFF/ON switching capability typically required when the PowerPulse control is used with a flow

switch or a parts detector.

Product safety labels must remain highly visible on the equipment. Establish a

regular schedule to check visibility. If safety labels should require replacement,

contact SYNTRON Material Handling, for an additional supply free of charge.

WARNING: These instructions and safety precautions must be followed. There is

a hazard of electrical shock to the operator. NOTE: Local safety codes and

regulations must be considered when installing and/or operating this control.

(115/230V) WT Control

SM0098 090214

Table of Contents

Do you have a question about the PowerPulse 225490-A and is the answer not in the manual?

Page 1 Product safety labels must remain highly visible on the equipment. Establish a regular schedule to check visibility. If safety labels should require replacement, contact SYNTRON Material Handling, for an additional supply free of charge. WARNING: These instructions and safety precautions must be followed. There is a hazard of electrical shock to the operator.
Page 2 INSTALLATION Install the control, being careful to maintain its UL TYPE 4X and NEMA 4 rating integrity. Power supply voltage and frequency requirements are designated on the control nameplate. If remote mounting is necessary, the control should be installed close to the equipment where it is easily accessible and within sight of the operator. Installation on a wall in a clean, dry, vibration-free location is recommended.
Page 3 TROUBLESHOOTING PROBLEM CAUSE CORRECTION *Replace the Open fuse(s) fuse(s) Loose connection Repair No power from the control. Defective PCB *Replace PCB Ensure C1 & C2 Jumper wire closed/connected No control of power from the control. Equipment runs at full Defective PCB *Replace PCB capacity or with a weak hum.
Page 4 Handling for an additional supply free of charge. Syntron Material Handling, LLC reserves the right to alter at any time, without notice and without liability or other obligations on its part, materials, equipment specifications and models. Syntron Material Handling, LLC also reserves the right to discontinue the manufacture of models, parts, and components thereof.
