Summary of Contents for SIRI Maxi Bella 75
- Page 1 Charter:: ella ella SIRI SRL Via R.Dalla Costa, 44/46 41122 MODENA (ITALY) Tel. 059/313191 - Fax 059/311362 E-mail: info@SIRI.mo.it - http//www.SIRI.mo.it A member of EXPO - MODENA Consortium 3/24 Release:: Page::...
- Page 2 - info@siri.mo.it 75 - 105 75 - 105 ella ella operating and maintenance manual...
-
Page 3: Table Of Contents
Charter:: ella ella CONTENTS 1 INTRODUCTION ......................page 4 General information ....................page 4 General information concerning machine use ............page 5 General precautions concerning machine use ............. page 5 Pictographs concerning the “Operator qualification level” ........page 6 Pictographs relating to safety ................page 7 2 PRESENTATION ...................... - Page 4 The purchase date is confirmed by the stamp and signature of an authorised agent. The guarantee card has been filled in and sent within 10 days from the date of purchase (freight bill date) to "SIRI S.r.l.". IMPROPER OR UNUATHORISED APPLICATIONS...
- Page 5 DECLARATION OF CE CONFORMITY We SI.RI s.r.l. Via R.Dalla Costa, 44/46 41122 MODENA (ITALY) Tel. 059/313191 - Fax 059/311362 www.siri.mo.it - info@siri.mo.it declare on our sole responsibility that the machine: SI.RI Type electric water cutter for building trade model...
-
Page 6: Introduction
This manual reflects the state-of-the-art the moment the machine was supplied and cannot be considered inadequate if there have been subsequent modifications according to further experience. SIRI reserves the right to update its products and manuals without being obliged to inform the users of machinery previously supplied of these modifications. The provision of information concerning updates of the machine and manual is to be considered as a form of courtesyzioni sugli aggiornamenti che SiRi ha apportato alle macchine. -
Page 7: General Information Concerning Machine Use
SSiSTanCe epaRTMenT iS aT youR DiSpoSal To pRoviDe all The infoRMaTion SiRi ConCeRning upgRaDeS ThaT haS applieD To iTS MaChineS SiRi Shall Be RelieveD fRoM any liaBiliTy in The following CaSeS iMpRopeR uSe of The MaChine By unTRaineD peRSonnel... - Page 8 Charter:: ella ella Pos. Q.ty Descrption MaxiBella 75 MaxiBella 105 CODICE CODICE tank 12-41 12-41 1058 1058 Foot/square holder fixing knob Plastic cap for foot 12-33 12-33 12-60C 12-60C Complete left hand square assembly Feet 7295 7295 Square for diagonal 107110 107110 Lateral extension OPTIONAL...
- Page 9 Charter:: ella ella 34/24 Page: Release::...
-
Page 10: Pictographs Concerning The "Operator Qualification Level
Charter:: ella ella - Make sure there are no foreign objects in the operating area. - When there is a risk of being hit by projected or falling parts, both solid or in other form, use goggles with side shields, as well as helmets and gloves if necessary. - When handling hot materials, it may be necessary to use gloves or other means of individual protection, to avoid scorching. -
Page 11: Presentation
Charter:: ella ella 2 PRESENTATION 2.1 GENERAL INFORMATION The M 75 and 105 cutters are designed and built for performing linear, ella diagonal and 45° (“jolly”) cuts on ceramic tiles, marble, granite, porcelain stoneware, clinker and cotto. The diamond-tipped disc supplied with the machine is suitable for cutting ceramic tiles only; for all other materials, use specific discs. - Page 12 Charter:: ella ella 33/24 Release:: Page::...
- Page 13 Charter:: ella ella D Maintenance electrician: qualified technician capable of running the machine in normal conditions, as well as running it with guards deactivated using a control with a sustained action; also required to carry out all electrical adjustments, maintenance and repair work. This person is capable of working on live switchboards and connector blocks.
-
Page 14: Characteristics
Viale Dalla Costa, 44- 411222 MODENA (ITALY) C.P. 468 - Tel. 059/313191 Fax. 059/311362 P.IVA e C.F. 00496310368 E mail: info@SIRI.mo.it http://www.SIRI.mo.it ART: ......... Matricola: ......Annodi costruzione: 20 .. -
Page 15: Operation
Charter:: ella ella 2.4 opeRaTionT lineaR CuT inear cuTs are performed as follows 1) p . 3). ush The sliding carriage To The side opposiTe To The operaTor unTil iT sTops 2) p . 3). uT The Tile on The sheeT meTal Table Fig. - Page 16 Charter:: ella ella 8.2.1 PERIODIC MAINTENANCE SCHEDULE INTERVENTION Daily Weekly Monthly Clean the machine — — At the end of the work shift Clean the tank — — At the end of the work shift — Every week — Lubricate the guide Clean the pump —...
- Page 17 Charter:: ella ella 8 ADJUSTMENT AND MAINTENANCE Carefully read these instructions, before performing any maintenan- ce and adjustment on the accessories; this will guarantee safer wor- king conditions for the personnel involved and a greater reliability of the interventions made. ADJUSTMENT Adjusting flow of water to disc Flow of water to disc can be adjusted by acting on the tap (A).
- Page 18 Charter:: ella ella 45° CUTS (“JOLLY” CUTS) 45° (Jolly) cuts are performed as follows (Fig. 7): 1) Loosen fixing knobs (A) of sliding bar. 2) Turn motor unit counter-clockwise until it stops. 3) Firmly screw fixing knobs (A) at the ends of the machine. 4) Proceed as for linear cuts.
-
Page 19: Technical Data
Fig. 8 5) Repeat cut for three remaining sides of rectangle. 2.5 TECHNICAL DATA The machine has these basic features: Technical data Maxi Bella 75 Maxi Bella 105 Power supply 230 V - 50 Hz 230 V - 50 Hz Power draw 7.5 A... - Page 20 Charter:: ella ella 7 STARTING AND STOPPING 7.1 FIRST START After installing the machine, a few preliminary checks must be made before use. Before starting, read this manual with care. Should the Purchaser wish to carry out these operations autonomously, this manual must be read beforehand with great care in order to become conversant with the purpose and effect of the commands given 7.1.1 Supply activation...
- Page 21 Charter:: ella ella 5.4 WATER PUMP SUPPLY Make sure that the plug (T) is positioned correctly and fill the tank with water, making sure that the pump is completely submerged (Fig. 17). Fig. 17 Check that the water level is never low to protect the diamond-tipped disc and prevent a large quantity of cutting dust from forming.
-
Page 22: Diamond-Tipped Discs
Charter:: ella ella 2.5.1 Diamond-tipped discs The following discs can be fitted to the machine (Fig. 9): A) Smooth crown for ceramics / discs for porcelain stoneware; B) Turbo for “cotto” tiles - ceramics - marble; C) Sector type for stone – concrete - granite – hard stone - marble Fig. - Page 23 Charter:: ella ella 16/24 Page: Release::...
- Page 24 Charter:: ella ella 5) Flick switch (I) to “1” to start disc and pull motor carriage slowly towards material to cut (Fig. 5). 6) Remove cut pieces and any remaining fragments from work table. Fig. 5 Diagonal CuT iagonal CuTS aRe peRfoRMeD aS followS 1) l (a f .
- Page 25 Charter:: ella ella No brick laying is requested for installation. Unless otherwise specified, the floor must fulfil the following requirements: - the floor must be industrial grade, smooth and perfectly flat. The operator’s control station (P) is as illustrated in figure 12. During the work phase, the machine requires only one operator.
-
Page 26: Accident-Prevention Systems
Charter:: ella ella 3.1.1 Accident-prevention systems The machine features the following safety devices (fig. 10): A) Power switch B) Disc guard This type of guard consists of two parts connected together by 4 screws to enable the disc to be easily replaced; this guard covers most of the disc and is integral with the motor. C) Splash guard Fig. -
Page 27: Lifting, Transport And Storage
Charter:: ella ella 4 LIFTING, TRANSPORT AND STORAGE 4.1 LIFTING AND TRANSPORT The machine must be lifted and transported with care to prevent it falling or overturning. The machine is packed and placed on a wooden pallet to make it easier to transport and store.For handling on the worksite, use the knob to immobilise the carriage holding the motor;... -
Page 28: At The User's Care
Charter:: ella ella 5 INSTALLING THE MACHINE 5.1 AT THE USER’S CARE The user must provide the following: - installation areas complying with the local standards in force concerning health and safety at work; - an electricity supply line complying with the standards in force in the place of installation; - an efficient grounding system;... - Page 29 Charter:: ella ella 3 DANGERS AND GUARDS 3.1 PROHIBITED USES The line must be used only for the purposes envisaged by the maker (see chapter 2). In particular, the system cannot be used: - without its guards and/or with its safety devices deactivated, out-of-order or missing; - unless it has been correctly installed;...
- Page 30 Charter:: ella ella 20/24 Page: Release::...
-
Page 31: Electrical Connections
Charter:: ella ella 3) Release the motor support with special threaded bar and screw (F Fig. 15). Fig. 15 5.3 ELECTRICAL CONNECTIONS All connections to the mains must be made with this disconnected and by qualified and explicitly authorised personnel in accordance to the standards in force. -
Page 32: Control Components
Charter:: ella ella 6 CONTROL COMPONENTS The cutter has thermal overload protection and is protected against power fluctuation. In “0” position, the switch (I) is off and is on in “1” position (Fig. 18). Fig. 18 In event of a power failure, the switch automatically flicks to “0”. When power is restored, the machine does not start up without warning but only after flicking the switch to “1”. - Page 33 Charter:: ella ella 26/24 Page: Release::...
-
Page 34: Checking The Efficiency Of The Safety Devices
Charter:: ella ella 7.2.1 Checking the efficiency of the safety devices At the beginning of each work shift, make sure the safety devices are secured in place and in working order. The machine’s safety devices are described in chapter 3. 7.2.2 Stopping the machine To stop the machine, flick the switch to “0”. -
Page 35: Maintenance
Charter:: ella ella - Sharpening disc: In certain cases, a disc may partially lose its keenness although it is not completely blunt; in such cases the disc must be dressed. To dress with a S.I.R.I. whetstone whilst the machine is running, bring the whetstone into contact with the diamond-tipped crown of the disc, switch off the machine and wait for the disc to finish running. -
Page 36: Extra-Duty Maintenance
Charter:: ella ella Twice-yearly maintenance - Check the continuity of the machine’s PE circuit, as envisaged by the EN 60204-1 standard. This check must be made after every operation involving the machine’s PE circuit. - Check the state of the contacts of electrical contactors; if these are considerably oxidised or are functioning improperly, replace the contactors.
