Parameter; Include - M5Stack FIRE Quick Start Manual

ESP32 Chip GPIO15
M5Stack Docs
Hardwares SIG Pin

PARAMETER

Resources
ESP32
Flash Memory
Power Input
Port
IPS Screen
Speaker
MEMS
Battery
Operating Temperature
Size
Case Material
Notice1 M5PORT EXPLAIN
PortA(21/22) mainly used for I2C, black is PortB(26/36) which can be used for DA/AD, Singel-bus
communication, Blue is PortC(16/17) can be used for Uart. Correspondingly, most of the M5 Units have
the Port with matched color for specify which port it should go in on the M5Core. Those port
identification is a convenience for UIFlow (Blockly) Users. For advanced using ,you can do you own
customization, since most of the PIN on ESP32 are remapping-able. Unfortunatly, PortA(red) can not be
used as analog read in. It refers to GPIO 21 & 22 from ESP32, which doesn't have AD channel alternatives:
ADC1(8 channels atteched to GPIOs 32-39)
ADC2(10 channels atteched to GPIOs 0，2，4，12-15，25-27)
To use AD read function : 1, Use Dupont cable refers to the pins on the side which can be used as an AD
channel. 2, Get a M5GO bottom, which comes with a PortB. 3, Get a PbHUB and connect it with PortA,
then you can have 6 PortBs. For more information about Pin assignment and Pin Remapping, Please refer
to EPS32 Datasheet

Include

1x FIRE
1x M5GO CHG Base
2x LEGO block
5x LEGO connector
1x M3 hex wrench
1x Type-C USB(100cm)
1x User Manual
MIC Pin Speaker Pin
Parameter
240MHz dual core, 600 DMIPS, 520KB SRAM, Wi-Fi, dual mode Bluetooth
16MB
5V @ 500mA
TypeC x 1, GROVE(I2C+I/0+UART) x 1
2 inch, 320x240 Colorful TFT LCD, ILI9342C
1W-0928
BMM150 + MPU6886
500 mAh @ 3.7V
32°F to 104°F ( 0°C to 40°C )
54 x 54 x 21 mm
Plastic ( PC )
You can identify the port name and function by its color, red is
5/7
