- Page 1 Quick Start Guide for the BroadNAS (No Disks Pre-Installed) 01/06/04 16215 Alton Parkway • P.O. Box 57013 • Irvine, CA 92619-7013 • Phone: 949-450-8700 • Fax: 949-450-8710...
- Page 2 All rights reserved Printed in the U.S.A. ® Broadcom and the pulse logo are registered trademarks of Broadcom Corporation and/or its subsidiaries in the United States and certain other countries. All other trademarks mentioned are the property of their respective owners.
-
Page 3: Table Of Contents
Overview ......................1 Installation .......................1 Install the Disk ..................2 Connect the Cables ..................6 Turning on the BroadNAS ..............7 Configure the BroadNAS ...............8 B r o a d c o m C o r p o ra t i o n Document... - Page 4 BCMXXXX B ro ad co m C o r p o r a t i o n Page iv Document 94780-QS100-R...
-
Page 5: Overview
Within this guide, there are sections that provide specific instructions for each. Installation BroadNAS does not come with any pre-installed disks, so at least one disk must be installed before connecting BroadNAS. Either one or two disk drives can be installed in BroadNAS. -
Page 6: Install The Disk
Install the Disk BCM94780 Install the Disk The following procedure describes how to remove the drive sled and insert the drive by connecting the IDE and power cables. Lift the drive handle and slowly pull out the drive sled. If the drive bay is locked, use the provided key to unlock it before attempting to remove a drive sled. - Page 7 BCM94780 Installation Release Tab Open the case by pressing the release tab on the front of the drive sled, and slide the cover in the direction of the arrow. Components of the drive sled assembly are the top cover, drive sled, installation manual, screws, and a set of keys.
- Page 8 Install the Disk BCM94780 Connect the IDE and power cables. IDE Cable Power Cable Gently insert the drive into the drive sled. Care must be taken not to damage the IDE cable during this operation. Screw locations When the drive has been inserted, secure the drive with four screws (two on each side).
- Page 9 Replace the drive sled into its housing in the BroadNAS. Gently slide the sled into the slot until it meets firm resistance, and push the handle down.
-
Page 10: Connect The Cables
This may be a network hub or the network connector of a PC if the PC is the only other device in the home network. If there is anything more than the BroadNAS and one PC on the network, a router, gateway, or hub is needed for the network. -
Page 11: Turning On The Broadnas
BCM94780 Installation Turning on the BroadNAS Turn the BroadNAS on by pressing I on the main AC power switch (located on the back of the BroadNAS). For the location of the main AC power switch, see the figure on page... -
Page 12: Configure The Broadnas
Double-click config, and a Configuration icon displays. Open an Explorer window and in the address bar type: \\BroadNAS. All the shares on BroadNAS then appear. This step can take up to 1 minute. If there is an error, re-try. If the shares do not appear, reboot the computer and go back to step •... - Page 13 In this case, press the Authentication button again. This timing makes it difficult for intruders to take over the BroadNAS over the network, because they are not able to press the button and connect unless...
- Page 14 Corporation reserves the right to make changes without further notice to any products or data herein to improve reliability, function, or design. Information furnished by Broadcom Corporation is believed to be accurate and reliable. However, Broadcom Corporation does not assume any liability arising out of the application or use of this information, nor the application or use of any product or circuit described herein, neither does it convey any license under its patent rights nor the rights of others.
