  • Page 1 Fax: +61 (0) 2 4372 8603 Belkin Tech Support 310.898.1100 ext. 2263 800.223.5546 ext. 2263 Europe: 00 800 223 55 460 Australia: 1800 666 040 P74242 © 2003 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed.
  • Page 2 2-Port KVM Switch with Built-In Cabling Control two computers using one video monitor, and a PS/2 keyboard and mouse User Manual F1DK102P...

  • Page 3: Table Of Contents

    Introduction Package Contents ........1 Overview Feature Overview .

  • Page 4: Introduction

    Engineered to give you control over multiple computers and/or servers from one console, Belkin KVM switches come in a variety of capacities suitable for all configurations, large or small. This Switch is backed by a Belkin Three-Year Warranty and free technical support.

  • Page 5: Overview

    OVERVIEW The Belkin 2-Port KVM Switch with Built-In Cabling allows you to control multiple computers with one keyboard, monitor, and mouse. The Switch supports PS/2 input devices (keyboard and mouse), VGA, SVGA, XGA, and PS/2 computers. Feature Overview Complete Compact Solution Built-in cables and color-coded connectors make operation and organization easy.

  • Page 6: Operating Systems

    OVERVIEW Operating Systems Your Switch is for use on CPUs using: Platforms • Windows® 95, 98, 2000, Me, NT®, XP • DOS • Linux® • Novell® NetWare® 4.x/5.x Keyboards • Supports 101-, 102-, and 104-key keyboards Mice • Microsoft® system-compatible PS/2 mice with 2, 3, 4, or 5 buttons Monitors •...

  • Page 7: Unit Display Diagram

    Unit Display Diagram The 2-Port KVM Switch with Built-In Cabling: Port Status Indicator LEDs Console Mouse Port Console VGA Monitor Ports Console Keyboard Port OVERVIEW Built-In Cables...

  • Page 8: Specifications

    OVERVIEW Specifications Part No.: F1DK102P PCs Supported: 2 Keyboard Emulation: PS/2 Mouse Emulation: PS/2 Monitors Supported: VGA, SVGA, MultiSync, and LCD (with use of adapter cable) Max. Resolution: 2048x1536@65Hz Keyboard Input: 6-pin miniDIN (PS/2) Mouse Input: 6-pin miniDIN (PS/2) VGA Port: 15-pin HDDB type LED Indicators: 2 Enclosure: Plastic Dimensions: (H) 27.5 x (W) 82 x (D) 81.25mm...

  • Page 9: Installation

    Note: If your computer needs to be more than eight feet from the KVM Switch, you can use the Belkin CAT5 Extender (part number F1D084) to extend your PS/2 keyboard, PS/2 mouse, and monitor up to 500 feet (152.4m) away using a standard CAT5 UTP cable.

  • Page 10: Step-By-Step Installation Guide

    Plugging and unplugging cables while computers are powered on can cause irreversible damage to your computers, data, and/or to the Switch. Belkin Corporation will not be responsible for damage caused in this way. Connecting the Console 1.
  • Page 11 Connecting the Computer 1. Using the attached cables, take the VGA cable and connect it to the VGA port on the first computer. 2. Connect the PS/2 keyboard KVM cable to the keyboard port on the computer. 3. Connect the PS/2 mouse KVM cable to the mouse port on the computer.

  • Page 12: Using Your Switch

    Powering Up the Systems Once all cables have been connected, power up your CPUs that are attached to the Switch. All computers can be powered on simultaneously. The Switch emulates a mouse and keyboard on each port and will allow your computer to boot normally.

  • Page 13: Autoscan Mode

    USING YOUR SWITCH You can switch directly to any port by entering the Switch port number you wish to use. For example, if you press “SCROLL LOCK”, “SCROLL LOCK”, “2”, the computer on port 2 will be selected. Switch to Port 2—(2) AutoScan Mode In AutoScan mode, the Switch remains on one port for eight seconds before switching to the next.

  • Page 14: Faqs

    Q: Does the Switch function with the Microsoft IntelliMouse? A: Yes, the Switch will function with Microsoft, Logitech, Kensington, as well as with all Belkin mice. The Switch will support only two mouse buttons. Please contact Belkin Technical Support for any compatibility questions you may have.
  • Page 15 USB option. Q: What are the benefits of the Belkin 2-Port KVM Switch with Built-In Cabling over a similar competitor product? A: The Belkin 2-Port KVM Switch with Built-In Cabling is an affordable solution, packed with features usually found in higher-priced units.
  • Page 16 Q: Do I have to install any software to use the Switch? A: No, the Switch does not require any drivers or software to be installed on your computers. Simply connect all your computers to the PC ports on the Switch, then attach one monitor, mouse, and keyboard to the corresponding console ports and your Switch is ready for use.

  • Page 17: Troubleshooting

    Video I am getting ghosting, shadowing, or fuzzy images on my monitor. • Check that all video cables are inserted properly. • Check that the monitor you are using supports the resolution and refresh-rate setting on your computer. • Check that the graphics card you are using supports the resolution and refresh-rate setting on your computer.
  • Page 18 • If you are using the keyboard software that was included with your keyboard, uninstall it and install the standard Microsoft keyboard driver. Mouse Mouse is lost when I switch to a different channel. • Check that the mouse you are using is connected properly to the console port of the Switch.
  • Page 19 • Make sure the mouse works when directly plugged into the computer. Rebooting may be necessary when trying this. • Try a different mouse. When I switch from one port to another, mouse movement is completely erratic. • Make sure you do not have more than one mouse driver installed. Make sure that the driver is either for a standard PS/2 mouse or a Microsoft compatible PS/2 mouse.

  • Page 20: Ce Declaration Of Conformity

    FCC Statement DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC COMPATIBILITY We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under our sole responsibility that the product: to which this declaration relates: Complies with Part 15 of the FCC Rules. Operation is subject to the following...
  • Page 21 Belkin Corporation warrants this product against defects in materials and workmanship for its warranty period. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product.
