- Page 1 FAGOR AUTOMATION S.COOP RS232/RS422/RS485 serial line connections ∼ series ∼ MCS and MCP Ref.0610 -...
- Page 2 34-943-771118 (Technical Service Department) The information described in this manual may be subject to changes due to technical modifications. FAGOR AUTOMATION, S. Coop. reserves the right to change the contents of this manual without prior notice. The contents of this manual have been verified and matched with the product described here.
- Page 3 8 years after such product has disappeared from the product catalog. It is entirely up to FAGOR to determine whether a repair is to be considered under warranty. EXCLUDING CLAUSES: The repair will take place at our facilities. Therefore, all shipping expenses as well as travelling expenses incurred by technical personnel are NOT under warranty even when the unit is under warranty.
- Page 4 Electromagnetic Compatibility for Servo Drive systems). In Mondragón, 01.04.06 INTRODUCTION Fagor offers a diverse range of servo drive systems (Brushless AC motor and digital drive) This manual offers a description of the RS232/RS422/RS485 serial line communication between the different units that make up the servo drive system and their connection diagrams.
-
Page 5: Table Of Contents
GENERAL INDEX ESA VIDEO TERMINAL ........7 Description..........7 Communications..........7 RS232/RS422/RS485 SERIAL LINE CONNECTIONS ....8 Serial port of the units. Associated connector....8 RS422/RS232/RS485 serial port of the MCS or MCP drive ....8 MSP RS422/RS232/RS485 serial port of the VT from ESA ....8 Connections.......... - Page 6 BLANK PAGE MCS/MCP-6/20 RS232/RS422/RS485 CONNECTIONS-Ref.0610...
-
Page 7: Esa Video Terminal
ESA VIDEO TERMINAL Description An ESA video terminal VT is a device that may be used to control or monitor a process or system. It has a set of keys or touch-buttons that the user may configure to send commands to the system itself. It also permits sending data to determine the procedure and display the data coming originated by it. -
Page 8: Rs232/Rs422/Rs485 Serial Line Connections
RS232/RS422/RS485 SERIAL LINE CONNECTIONS Serial port of the units. Associated connector RS422/RS232/RS485 serial port of the MCS or MCP drive TABLE 2. RS422/RS232/RS485 serial connector of an MCS or MCP module. Signal Function Sub -D, M9 - front view - N.C. -
Page 9: Connections
Connections The following sections describe the connection possibilities between: A PC (Personal Computer) and an ESA Video terminal. An MCS or MCP drive and an ESA Video terminal. Several MCS or MCP drives and an ESA Video terminal. in order to establish serial line communication between all of them. RS422/RS232 BE ADAPTER Some connections (not all) will mention the adapter (RS422/RS232 BE), thus being necessary to describe it and its pinout at both ends. -
Page 10: Rs232 Serial Line
RS232 or RS422 serial line with a VT panel from ESA. The user is free to use this Fagor adapter or not. But, it should be used unless indicated otherwise because it makes the connection a lot easier. -
Page 11: Without Adapter
RS232 Cable. PC and ESA VT connection This Video Terminal - PC connection is essential for transferring the communication driver and the project. The connection cable to use will depend on whether the adapter RS422/RS232 BE is used or not. Without adapter RS232 cable 9-pin Sub-D,... -
Page 12: With Adapter
With adapter to the VT panel 9-pin Sub-D, 9-pin Sub-D, (ESA) type female type female connector connector RS422/RS232 BE RS232 cable Adapter FIGURE 7. RS232 Cable.Connection between a PC and an ESA Video terminal with adapter. The connection cable when using the adapter will have the following connectors at its ends: RS232 cable B port of the adapter... - Page 13 RS232 Cable. VT - drive connection Once the project has been transferred from the PC to the VT (ESA), an ESA video terminal may be connected to a single drive, thus establishing communication via the MSP serial port of the VT and the drive's RS232 serial port. In this type of communication, the following parameters must be set to certain values.
-
Page 14: Rs422 Serial Line
Note that the RS422/RS232 BE adapter may be used to connect the RS422 serial line with an ESA VT panel. The user is free to use this Fagor adapter or not. But, it should be used unless indicated otherwise because it makes the connection a lot easier. -
Page 15: Without Adapter
Without adapter RS422 cable to the VT panel (ESA) FIGURE 13. RS422 Cable.Connection between an ESA VT and several MCS or MCP drives without adapter. Follow the diagram of the next figure to make this type of connection (without adapter): +5V (16) 470 Ω... -
Page 16: With Adapter
With adapter RS422/RS232 BE Adapter RS422 cable to the VT panel (ESA) FIGURE 15. RS422 Cable.Connection between an ESA VT and several MCS or MCP drives with adapter. Follow the diagram of the next figure to make this type of connection (with adapter). TxRS422 +OUT 330 Ω... -
Page 17: Rs485 Serial Line
RS485 SERIAL LINE Fagor does NOT supply the RS485 serial line cable.Nevertheless, these are the connection diagrams. Note that the RS422/RS232 BE adapter may be used to connect the RS485 serial line with an ESA VT panel. RS485 cable. Connecting a VT and several MCS or MCP drives Once the project has been transferred from the PC to the ESA VT, a VT may be connected with several drives. -
Page 18: With Adapter
Follow the diagram of the next figure to make this type of connection: +5V (16) 470 Ω 0.25 W TxRx 485 +IN/OUT 330 Ω 0.25 W TxRx 485 -IN/OUT 470 Ω 0.25 W GND (7) to the VT panel CHASSIS (ESA) MCS2 or MCP2 MCS1 or MCP1... - Page 19 Follow the diagram of the next figure to make this type of connection (with adapter). Tx/Rx +RS485 Tx/Rx -RS485 to B port of the adapter Sub-D, F9 MCS1 or MCP1 MCS2 or MCP2 MCSn or MCPn Sub-D, F9 Sub-D, F9 Sub-D, F9 FIGURE 20.
- Page 20 Fax: 351 22 996 07 19 E-mail: fagor_nj@fagorautomation.com.cn E-mail: fagorautomation@fagorautomation.pt Headquarters: Guangzhou: FAGOR AUTOMATION S. COOP. Beijin FAGOR AUTOMATION Equipment Ltd. Bº San Andrés 19, Apdo. 144 Guangzhou Office Chicago: E-20500 ARRASATE-MONDRAGON Room 915 Lihao Plaza FAGOR AUTOMATION CORP. www.fagorautomation.com No.
