- Page 1 STATUS SCIENTIFIC CONTROLS Issue: Date: 7/1/20 Firmware: V2.4.yy Installation, Commissioning & Routine Gas Testing Manual Gas Detector Type FGD10A Oxygen - Toxic Gases (Relay version)
- Page 3 Authorised Signatory to this declaration, on behalf of the manufacturer: Name: David Stuttard Title: Managing Director Address: Status Scientific Controls Ltd, Hermitage Lane Industrial Estate, Kings Mill Way Mansfield, Nottinghamshire, NG18 5ER, United Kingdom Signature Date: 14/10/19 Extract from TD18/100...
-
Page 5: Table Of Contents
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector CONTENTS FIRMWARE REVISION ............... 6 PACKAGE CONTENTS ..............7 SCOPE OF THE MANUAL ..............7 DESCRIPTION ..................8 4.1..................10 ELAYS 4.2............10 LTERNATIVE GAS TYPES INSTALLATION ................ - Page 6 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector CALIBRATION .................. 33 9.1..............33 ENSOR ALIBRATION 9.1.1. Sensor Zero ..................33 9.1.2. Sensor Span ..................34 9.2..........35 NALOGUE UTPUT ALIBRATION 9.2.1.
-
Page 7: Firmware Revision
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector IRMWARE EVISION TD18/002 Issue: Change Note: 1904 Page 6... -
Page 8: Package Contents
Installation manual Calibration certificate Optional:- Weather guard COPE OF THE MANUAL This manual relates specifically to the version of the FGD10A gas detector with the following features:- • An Oxygen or Toxic sensor for the detection of various gases. •... -
Page 9: Description
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Description FGD10A GAS DETECTOR FGD10A GAS DETECTOR FITTED WITH PROTECTIVE WEATHERGUARD TD18/002 Issue: Change Note: 1904 Page 8... - Page 10 Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector The FGD10A is an explosion protected ATEX and IECEx certified fixed gas detector for use in potentially explosive atmospheres. The unit may be optionally fitted with a protective weather guard as shown in the photograph.
-
Page 11: Relays
Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector 3.1. Relays The FGD10A relay version has 3 factory-fitted relays. Each provides a set of voltage free changeover contacts to perform the following control functions:- • Alarm Level 1 •... -
Page 12: Installation
In order to prevent dangerous overloading of the FGD10A gas detector, it is important that the installer observes the relay contact rating and ensures that external circuits connected to the relay contacts are suitably protected from exceeding that rating and associated cabling is adequately rated and suitably installed. -
Page 13: Cable Entries
The FGD10A should be mounted and secured using the mounting holes on the main unit. Figures 2 and 3 shows details of the FGD10A terminal connections – these can be accessed as follows:-. Switch OFF the supply to the FGD10A. - Page 14 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Figure 1 – Unplugging the display board for connection purposes TD18/002 Issue: Change Note: 1904 Page 13...
-
Page 15: Fgd10A Connections
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector FGD10A connections ATEX certified Ex d armoured Armoured cable cable glands Armoured cable RS232 Aout Important Relay 3 Relay 2 Relay 1 Fault Alarm 2... -
Page 16: Analogue Output
Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector The FGD10A is powered from an 8 – 24 volt dc, 5 W maximum output supply. This may be either:- An independent supply powering one or more units. -
Page 17: Commissioning
Once the installation is complete and the covers are secure then power can be applied. The power source should be between 8 and 24 volts dc. When power is first applied to the FGD10A, an initialisation procedure is performed as follows: All segments on the LCD are shown 8.8:8.8... -
Page 18: Initial Gas Testing
FGD10A Oxygen / Toxic Gas Detector Initial Gas Testing FGD10A units are factory calibrated as detailed on the calibration certificate supplied with the instrument. However, it is always advisable after installation to confirm that the instrument reads zero with no gas present and responds accurately when presented with an appropriate concentration of the target gas. - Page 19 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Figure 6 – Arrangement for Application of a Certified Test Gas Without weatherguard With weatherguard Calibration Metal sampling adaptor, Stock No. SS336 Adaptor 6mm O.D.
-
Page 20: Test Gas
If the instrument reads correctly then no adjustment is required. If the analogue signal is connected to an associated control panel, confirm that the reading corresponds with that on the FGD10A or adjust as necessary in accordance with the control panel manufacturer’s instructions. -
Page 21: Sampling Time
Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Where a weather guard is not fitted, the use of a sampling adaptor (Stock No. SS336) is required in order to present the gas to the FGD10A sensor. 4.7.2. Sampling time Apply the test gas and allow a sufficient time for the sample to reach the gas detector. -
Page 22: Software Features
Note: It is important that that the FGD10A is correctly configured for the sensor in use, prior to performing any feature available in the menu system. TD18/002... -
Page 23: Menu Mode Selection
4.8. Menu Mode Selection The FGD10A uses a password system to restrict the end user from carrying out certain changes that may compromise the use of the equipment. Setting the password to zero will give the user access without compromise. -
Page 24: E : 1 - Sensor Zero
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector E : 47 – Set the Dac analogue output FSD 4.8.21. 4.8.21. E : 1 – Sensor Zero 4.8.1. Refer to section 5.1.1. for sensor calibration details. -
Page 25: E : 6 - Decimal Places
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector E : 6 – Decimal Places 4.8.6. The number of decimal places that are used to display the detected gas levels can be changed via this menu option. -
Page 26: E : 8 - Sensor Selection
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector E : 8 – Sensor Selection 4.8.8. This menu option allows the sensor type to be manually selected. The available sensor options are listed below:... -
Page 27: E : 9 - Engineer Diagnostics
E : 9 – Engineer diagnostics 4.8.9. This feature is a view-only feature. No configuration changes are possible from within this menu. The information is for use of Status Scientific Controls personnel. • From the menu system select menu option: E: 9 and press ENTER. -
Page 28: E : 14 - Relay 2
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector E : 14 – Relay 2 4.8.11. The unit is fitted with a relay that is operated in conjunction with the alarm level. The user can select if the relay is normally Energized, ‘E’ or normally de-energised, ‘d’... -
Page 29: E : 16 - Alarm Level 2
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector E : 16 – Alarm Level 2 4.8.13. The gas level that will cause Relay 2 to change state is set via this menu option. -
Page 30: E : 20 - Negative Zero Suppression
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector E : 20 – Negative Zero Suppression 4.8.15. This option is used to allow the user to suppress small amounts of negative sensor zero drift. The setting can be set between 0 and 10% of the sensor range as set by the FSD value. -
Page 31: E : 28 - Firmware Update
PC software. See PC software manual to carry out the actual programming of the FGD10A module. E : 29 – Relay 3 4.8.18. -
Page 32: E : 30 - Password
FGD10A Oxygen / Toxic Gas Detector E : 30 – Password 4.8.19. Use this menu option to enable / disable the password feature. Place the FGD10A in the password menu as follows: • Press the MENU to open the menu system. •... -
Page 33: E : 47 - Analogue Output Fsd
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector E : 47 – Analogue Output FSD 4.8.21. This menu option allows the full-scale gas level to be selected that relates to the 4 to 20 mA output. -
Page 34: Calibration
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector ALIBRATION MENU DOWN ENTER 5.1. Sensor Calibration This feature allows the sensor to be calibrated. Ensure that the correct sensor type is selected in the configuration prior to calibration. Refer to section 4.8. -
Page 35: Sensor Span
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector 5.1.2. Sensor Span Always zero the sensor prior to performing a span operation. • From the menu system select menu option: E: 2 and press ENTER. -
Page 36: Analogue Output Calibration
Meter range: – Control Analogue Output 0.04V – 0.20V Unit (4 – 20mA) 40mV – 200mV Advantage: No need to disturb wiring between FGD10A and control unit. Disadvantage: Measurement accuracy dependent upon resistor tolerance. TD18/002 Issue: Change Note: 1904 Page 35... -
Page 37: Analogue Output Zero
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector 5.2.1. Analogue Output Zero • Monitor the current sourced from the analogue output of the FGD10A using a suitable method. • From the menu system select menu option: E: 4 and press ENTER. -
Page 38: Error Codes
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector RROR ODES The FGD10 Oxygen / Toxic Gas Detector has only 1 error code ERROR_SENSOR_NEG_DRIFT = 2, the gas level is below -10% of the FSD. -
Page 39: Communications Protocol
FGD10A Oxygen / Toxic Gas Detector OMMUNICATIONS ROTOCOL The communications protocol used by the FGD10A is used for communications between devices connected via an RS232 connection at 19200 baud, 8 data bits 1 stop bit, no parity. This point-to-point, P2P, protocol is a frame-based protocol. -
Page 40: 7.3. Frame Structure
Variable ID. A variable ID may be any number of bytes long. The available Variables and their corresponding Variable IDs depend on the type of device, but here are a few examples for the FGD10A:- General Configuration 0x00... -
Page 41: 7.5. Reading A Variable
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector 7.5. Reading a Variable Send a read frame with the Variable ID to be read: var- Csum Csum Byte stuffing Device response on success, where requested variable data < 255 bytes:... -
Page 42: Read Example - Read Live Data
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector 7.5.1. Read example - read live data The following example is based on V4.x.xE where the data is either byte or integer types only. Send the following bytes: DLE, RD, Variable ID, DLE, EOF, Checksum High byte, Checksum low byte i.e. -
Page 43: 7.6. Writing A Variable
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector 7.6. Writing a Variable Send a write frame with the Variable ID to be written: Csum Csum var-id Byte stuffing Device response on success: Where data to write is < 255 bytes, send a DAT frame:... -
Page 44: Routine Gas Testing
Refer to Figure 6 in section 0showing the arrangement for applying the test gas to the FGD10A. Before application of the test gas, check that the FGD10A reads zero with no known gas present in the atmosphere. If necessary, carry out adjustment of the zero setting as described in section 5.1.1. -
Page 45: Sensor Replacement
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector sensor replacement 8.1. Oxygen / Toxic sensor Step1 Turn cover securing stud anti-clockwise to allow cover to open. Step 2 Remove cover by rotating anti-clockwise... - Page 46 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Step 3 Remove display board which can be left to dangle on its retaining wire. Remove PCBs from the support pillars and the datamate cable from the...
- Page 47 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Step 5 Remove sensor insert from FGD10A enclosure using extraction tool. TD18/002 Issue: Change Note: 1904 Page 46...
- Page 48 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Step 6 Separate the two sensor insert components. Once separated remove old sensor and replace with a new sensor and mate the two component parts...
- Page 49 Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Step 7 Apply Loctite 243 or a compound equal strength to the threads Insert the sensor housing into the FGD10A enclosure using the insertion tool. loctite TD18/002 Issue:...
- Page 50 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Step 8 Terminate the wires dependIing on which type of gas sensor is fitted. TD18/002 Issue: Change Note: 1904 Page 49...
- Page 51 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Step 9 Fix datamate cable, the boards removed from the support pillars and finally the display board back into position. TD18/002 Issue: Change Note: 1904...
- Page 52 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Step 10 Replace cover and fully tighten. Step 11 Turn the cover securing stud clockwise until secure. TD18/002 Issue: Change Note: 1904 Page 51...
-
Page 53: Fuses
USES A 1Amp anti-surge fuse, housed within a surface mounted holder, is located within the FGD10A to prevent overloading of the electronic circuitry in the event of an internal fault. In the event of the internal fuse blowing, access can be gained using the following procedure: Switch OFF the supply to the FGD10A. -
Page 54: Specification
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Specification Instrument Body – Aluminium Pressure Die Casting Sensor Insert – Stainless Steel Grade 316 Materials Magnetic Pen – Stainless Steel Grade 316 Weather guard – Stainless Steel Grade 304 & Nylon 66... -
Page 55: Dimensions
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Dimensions 126 Centres 2 x 7mm dia. mounting holes Optional Weatherguard Maximum Depth = 127mm TD18/002 Issue: Change Note: 1904 Page 54... -
Page 56: Certification
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector ERTIFICATION The FGD10 Series of Gas Detectors are ATEX and IECEx certified for use in potentially explosive atmospheres and is marked as follows:- WARNING – DO NOT OPEN WHEN AN EXPLOSIVE GAS... - Page 57 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector Compliance with the Essential Health and Safety Requirements has been assured by compliance with: EN 60079-0: 2018 EN 60079-1 : 2014 Electrical data Power supply - 8Vdc to 24Vdc, 5W Relay contact rating –...
- Page 58 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector USTOMER NOTES TD18/002 Issue: Change Note: 1904 Page 57...
- Page 59 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector USTOMER NOTES TD18/002 Issue: Change Note: 1904 Page 58...
- Page 60 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10A Oxygen / Toxic Gas Detector USTOMER NOTES TD18/002 Issue: Change Note: 1904 Page 59...
