STATUS SCIENTIFIC CONTROLS FGD10B Series Installation, Commissioning And Operation Manual
Pellistor
Hide thumbs
Also See for FGD10B Series:
Related Manuals for STATUS SCIENTIFIC CONTROLS FGD10B Series
Summary of Contents for STATUS SCIENTIFIC CONTROLS FGD10B Series
- Page 1 STATUS SCIENTIFIC CONTROLS Issue: Date: 7/1/20 Firmware: V1.0.4 Installation, Commissioning & Routine Gas Testing Manual Gas Detector Type FGD10B Pellistor...
- Page 3 Description of Equipment: The FGD10B Series of Fixed Gas Detectors for the detection of Flammable gases using pellistor technology. ATEX Flameproof Certified for use in Group IIC hazardous locations. Directive 2014/34/EU ATEX The following harmonised standards were used in support of this declaration: EN 60079-0:2018 Explosive atmospheres Part 0: Equipment –...
-
Page 5: Table Of Contents
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector CONTENTS PACKAGE CONTENTS ..............6 SCOPE OF THE MANUAL ..............6 DESCRIPTION ..................7 3.1.................. 8 AS TYPES INSTALLATION .................. 9 4.1................10 ABLE ENTRIES 4.2. - Page 6 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector 8.2..........31 NALOGUE UTPUT ALIBRATION 8.2.1. Analogue Output Zero ................ 32 8.2.2. Analogue Output Span ............... 32 ROUTINE GAS TESTING ..............33 SENSOR REPLACEMENT ..............34 10.1.
-
Page 7: Package Contents
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector ACKAGE ONTENTS The FGD10B is supplied in a box containing the following items:- Stock Description FGD10B Gas Detector Installation manual Calibration certificate Optional:- Weather guard SS749 Calibration / Configuration Keypad... -
Page 8: Description
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector Description The FGD10B is an explosion protected ATEX and IECEx certified fixed gas detector for use in potentially explosive atmospheres. The unit may be optionally fitted with a protective weather guard as shown in the following photograph. -
Page 9: Gas Types
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector IMPORTANT – When used in hostile environments (e.g. oil platforms where the instrument is exposed to salt spray or diesel) it is recommended that the FGD10B is always fitted with its protective weather guard. -
Page 10: Installation
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector NSTALLATION It is important that the correct cable and gland types are used when installing the FGD10B in a hazardous location. The cable entry devices and blanking elements of unused apertures shall be of a certified flameproof type, suitable for the conditions of use and correctly installed. -
Page 11: Cable Entries
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector Cable entries The cable entry threads are 20mm, ½” or ¾” NPT female. The FGD10B enclosure is manufactured from die cast aluminium. Therefore, the use of glands, conduit fittings and blanks made from brass should be avoided because if moisture is present, bi-metallic corrosion may occur due to the chemical reaction between the two materials. -
Page 12: Fgd10B Connections
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector FGD10B connections ATEX certified Ex d armoured Armoured cable Armoured cable cable glands Keypad Span Zero Important Sensor Mount Connect enclosure vertically as earth-point shown to a high integrity earth Figure 2 –... -
Page 13: Wiring Details
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector 3.2. Wiring details The infrared gas detector is a 4 to 20 mA loop powered device that operates from a supply of 8 – 24 volt dc supply and as such only requires two wires. -
Page 14: Commissioning
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector OMMISSIONING Following completion of the installation:- Ensure that the front cover has not been contaminated with dirt - paying particular attention to the thread. Replace the cover by rotating it several times clockwise until it reaches its limit then secure using the locking screw, turning in an anti-clockwise direction –... -
Page 15: Initial Gas Testing
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector Initial Gas Testing FGD10B units are factory calibrated as detailed on the calibration certificate supplied with the instrument. However, it is always advisable after installation to confirm that the instrument reads zero with no gas present and responds accurately when presented with an appropriate concentration of the target gas. - Page 16 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector Figure 7 – Arrangement for Application of a Certified Test Gas With weatherguard Calibration Metal sampling adaptor, Stock No. SS336 Adaptor 6mm O.D. Sampling Tube Remote Sampling...
-
Page 17: Test Gas
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector Test gas Figure 7 shows a typical arrangement for the application of a certified test gas. The purpose of the test gas response check is to confirm that that the reading on the instrument corresponds with the test gas concentration. -
Page 18: Sampling Time
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector 4.2.2. Sampling time Apply the test gas and allow a sufficient time for the sample to reach the gas detector. The response time will vary according to the length of the sampling tube. -
Page 19: Calibration
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector Calibration Calibration of the sensor can be carried out by using the buttons on the circuit board as seen in Fig1 and Fig 2. These buttons only work when the FGD10B has been powered for a minimum of 10 minutes. -
Page 20: Sensor Span
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector 4.4. Sensor Span Always zero the sensor prior to performing a span operation. Span Fig 2 Apply a known concentration of gas (applicable to sensor type) at a flow rate of between 500 and 1000 cc/min. -
Page 21: Calibration / Configuration Keypad
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector 4.5. Calibration / Configuration Keypad The FGD10B sensor can be calibrated via a purpose designed keypad. The keypad allows the user to carry out the following: Calibrate the sensor. - Page 22 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector The menu system featured within the keypad calibration unit allows all calibration and configuration activities to be performed. MENU The keypad has the following functionality: Button Function...
-
Page 23: Menu Mode Selection
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector 4.6. Menu Mode Selection The external Calibration / Configuration Keypad is used in its simplest form to calibrate the sensor for zero or gas drift. It may also be used to configure the FGD10b. -
Page 24: E : 1 - Sensor Zero
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector E : 1 – Sensor Zero 4.6.1. Refer to section 5.1.1. for sensor calibration details. E : 2 – Sensor Span 4.6.2. Refer to section 5.1.2. for sensor calibration details. -
Page 25: E : 8 - Sensor Type
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector E : 8 – Sensor Type 4.6.6. There is only one type of sensor that can be fitted, that is a pellistor type device. • Press MENU to open the menu system. -
Page 26: E : 9 - Engineer Diagnostics
E : 9 – Engineer diagnostics 4.6.7. This feature is a view-only feature. No configuration changes are possible from within this menu. The information is for use of Status Scientific Controls personnel. • From the menu system select menu option: E: 9 and press •... -
Page 27: E : 12 - Sensor Cross Reference
Pressing MENU instead of ENTER aborts any changes (the existing factor is displayed on exit). • Press MENU to close the menu system. Ask Status Scientific Controls for advice on settings. Some typical settings when methane is used for the calibration gas Target gas Xref... -
Page 28: E : 19 - Positive Zero Suppression
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector E : 19 – Positive Zero Suppression 4.6.9. This option is used to allow the user to suppress small amounts of positive sensor zero drift. The setting can be set between 0 and 10% of the sensor range as set by the FSD value. -
Page 29: E : 25 - Positive Zero Temperature Compensation
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector E : 25 – Positive Zero Temperature Compensation 4.6.11. This option has no effect on the sensor version 1.0.3 E : 34 – Positive Span Temperature Compensation 4.6.12. -
Page 30: Calibration
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector ALIBRATION 5.1. Sensor Calibration This feature allows the sensor to be calibrated. Ensure that the correct sensor type is selected in the configuration prior to calibration. Refer to section 4.6. -
Page 31: Sensor Span
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector 5.1.2. Sensor Span Always zero the sensor prior to performing a span operation. • From the menu system select menu option: E: 2 and press • Apply a known concentration of gas (applicable to sensor type) at a flow rate of between 500 and 1000cc/min. -
Page 32: Analogue Output Calibration
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector 5.2. Analogue Output Calibration The analogue output is that of a current source. In order to calibrate the output it is necessary to monitor the output signal. This can be performed in... -
Page 33: Analogue Output Zero
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector 5.2.1. Analogue Output Zero • Monitor the current sourced from the analogue output of the FGD10B using a suitable method. • From the menu system select menu option: E: 4 and press •... -
Page 34: Routine Gas Testing
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector OUTINE ESTING Refer to Figure 7, which shows the arrangement for applying the test gas to the FGD10B. Before application of the test gas, check that the associated control panel reads zero with no known gas present in the atmosphere. -
Page 35: Sensor Replacement
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector ENSOR REPLACEMENT 7.1. Pellistor sensor Step1 Turn cover securing stud clockwise to allow cover to open. Step 2 Remove cover by rotating anti-clockwise TD18/008 Issue: Change Note:... - Page 36 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector Step 3 Remove the main PCB and unplug the pellistor sensor board. Step 4 Remove sensor insert using extraction tool TD18/008 Issue: Change Note: 1904 Page 35...
- Page 37 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector Step 5 Undo the circlip that retains the sensor in its housing. And replace the sensor. Step 6 Apply Loctite 243 or a compound equal strength to the threads Insert the sensor housing into the FGD10B enclosure using the insertion tool.
- Page 38 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector Step 7 Place the pellistor sensor board onto the pellistor sensor pins and fix the pellistor main board into position. Step 8 Replace cover and fully tighten.
- Page 39 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector Step 9 Turn the cover securing stud anti clockwise until the stud is in tight contact with the cover. TD18/008 Issue: Change Note: 1904 Page 38...
-
Page 40: Fuses
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector USES A 340 mA polyfuse is located within the FGD10B. It will automatically reset when normal conditions return. PECIFICATION Instrument Body – Aluminium Pressure Die Casting Materials Sensor Insert –... -
Page 41: Dimensions
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector IMENSIONS 108 Centres 2 x 7mm dia. mounting holes Optional Weatherguard Maximum Depth = 127mm TD18/008 Issue: Change Note: 1904 Page 40... -
Page 42: Certification
STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector ERTIFICATION The FGD10 Series of Gas Detectors are ATEX and IECEx certified for use in potentially explosive atmospheres and is marked as follows:- WARNING – DO NOT OPEN WHEN AN EXPLOSIVE GAS... - Page 43 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector Compliance with the Essential Health and Safety Requirements has been assured by compliance with: EN 60079-0: 2018 EN 60079-1 : 2014 Electrical data Power supply - 8Vdc to 24Vdc, 5W...
- Page 44 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector USTOMER NOTES TD18/008 Issue: Change Note: 1904 Page 43...
- Page 45 STATUS SCIENTIFIC CONTROLS Installation, Commissioning & Routine Gas Testing FGD10B Pellistor Gas Detector TD18/008 Issue: Change Note: 1904 Page 44...
