SECURECOM V-4030PT-1 Installation Manual

V-4030PT-1 INDOOR PAN/TILT
VIDEO CAMERA
Installation Guide
Figure 1: V-4030PT-1 Video Camera

DESCRIPTION

The V-4030PT-1 is an indoor video
camera that allows for viewing live
and recorded video clips using
the Virtual Keypad™ App and
VirtualKeypad.com. The camera
can be connected using Wi-Fi or a
wired connection.
The camera can be set up to
automatically record when armed,
when motion is detected, or when
the system is in alarm, giving
immediate notification to the user.
Compatibility
• Any DMP system with an active
Virtual Keypad account
• V-IP1006RR SecureCom Wireless
Access Point (WAP)

What is Included?

• V-4030PT-1 Camera
• Camera Mounting Base
• Hardware Pack and Mounting
Template
• 5 V Power Supply
1

MOUNT THE CAMERA

1. Use the included template to mark the screw holes for the
camera mounting base.
2. Secure the camera mounting base onto the surface using
the supplied screws.
3. Route any power and network cables through the mounting
base and connected them as necessary.
4. Secure the camera to the mounting base. See Figure 2.
Tilt
Figure 2: Mounting the Camera
2

POWER AND CONNECT THE CAMERA

Using a SecureCom Wireless Access Point

Wireless Connection
1. Plug the 5 V power supply into the port on the back of the
camera, then connect it to a power outlet.
2. Press and hold the WPS button on the back of the WAP
for 2 seconds.
3. Press and hold the WPS button on the side of the
camera for three seconds. Once the camera and WAP are
connected, the LED on the WAP turns on steady.
Auto Pair
Verify the WAP is powered. Plug the 5 V power supply into the
port on the back of the camera, then connect it to a power outlet.
Auto-pairing begins immediately. Once the camera and WAP are
connected, the LED on the WAP turns on steady.
Pan
Lock Open
Mounting
Base
