Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
IMPORTANT: YOU MUST CHARGE COMPLETELY BEFORE FIRST USE,
AFTER EVERY JUMP START, AND EVERY 30 DAYS OR VOIDS WARRANTY.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2020 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
20g
Advertisement
Related Manuals for Viking 57085
Summary of Contents for Viking 57085
- Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
-
Page 2: Table Of Contents
Wear ANSI-approved splash-resistant safety goggles. Alternating Current Read the manual before Amperes set-up and/or use. Cold Cranking Amps WARNING marking concerning Risk of Fire. Reserve Capacity Follow connection procedure. Ampere-hours Page 2 For technical questions, please call 1-888-866-5797. Item 57085... -
Page 3: Safety
Electromagnetic fields in 3. NEVER smoke or allow a spark or flame close proximity to heart pacemaker could cause in vicinity of battery or engine. pacemaker interference or pacemaker failure. Item 57085 For technical questions, please call 1-888-866-5797. Page 3... -
Page 4: Specifications
Cold Cranking Amps 500A Battery 12V, 22Ah, Sealed Lead-Acid Battery Cables 55" L, 2AWG Functions: 12VDC Jump Starter, 12VDC Power Supply, 250 PSI Air Compressor, 5VDC 2.4A USB Port, LED Work Light Page 4 For technical questions, please call 1-888-866-5797. Item 57085... -
Page 5: Setup
Indicator Light/USB Button Negative Battery Positive Battery Clamp / C able Clamp / C able Compressor Pressure Switch Gauge Air Hose 120 V AC Compartment Charging Input Plug Item 57085 For technical questions, please call 1-888-866-5797. Page 5... - Page 6 Small Power Tool (7 amps x 12 volts = 84 Watts) to run the item. Bilge Pump This figure is within the capacity of the unit. Electric Cooler Air Compressor Page 6 For technical questions, please call 1-888-866-5797. Item 57085...
-
Page 7: Operation
Negative Battery Cable to a non- moving metal part of the vehicle. 8. Recharge the Jump Starter. WARNING! TO PREVENT SERIOUS INJURY: DO NOT CONNECT TO THE NEGATIVE TERMINAL OF THE BATTERY. Item 57085 For technical questions, please call 1-888-866-5797. Page 7... - Page 8 USB Indicator will illuminate. Charging the Jump Starter on page 6. 4. When finished, press LIGHT/USB Button again. 2. Plug the device into the USB Port. Remove the device from the USB Port. Page 8 For technical questions, please call 1-888-866-5797. Item 57085...
-
Page 9: Maintenance
Contact your local city government office for the nearest hazardous waste disposal area in your community. Item 57085 For technical questions, please call 1-888-866-5797. Page 9... -
Page 10: Parts List And Diagram
Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Page 10 For technical questions, please call 1-888-866-5797. Item 57085... - Page 11 Assembly Diagram Item 57085 For technical questions, please call 1-888-866-5797. Page 11...
-
Page 12: Warranty
Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
