Assembly Instructions
TABLE
Item# L-DN899SAL-A
Our clear, easy-to-follow, step by step instructions will guide you through the project from start to finish. The final
product will be a quality piece that will assemble easily and give years of enjoyment.
IMPORTANT:
Please read instructions thoroughly before assembly. Familiarize yourself with the inventory of parts and the
accompanying illustrations to assure safe and proper assembly.
Repeated assembly can weaken the locking ability of the washers. Periodically check all bolted connections on
your product to make sure they are tight and secure. Please keep the instructions for future reference.
WARNING:
Begin assembly not less than 6 feet from any obstruction such as a fence, garage, house, overhanging branches,
Some parts may contain sharp edges.
Keep children away from assembly are
Check all nuts and bolts for tightness before and during usage.
