Spectrum Industries Honors Lectern 55178 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
Honors Lectern
55178
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported
within 5 days of receipt. To report information regarding
missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
925 First Avenue, Chippewa Falls, WI 54729 USA
800 235 1262
715 723 6750
www.spectrumfurniture.com
™
Honors with surround
(shown extended)
Honors with overbridge
(shown retracted)
0119327R1 Page 1 of 18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Honors Lectern 55178 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Spectrum Industries Honors Lectern 55178

Summary of Contents for Spectrum Industries Honors Lectern 55178

  • Page 1 Thank you for purchasing Spectrum products! Spectrum Industries, Inc 925 First Avenue, Chippewa Falls, WI 54729 USA 800 235 1262 715 723 6750 www.spectrumfurniture.com...
  • Page 2 If servicing is necessary, adults or with adult supervision. please contact Spectrum Industries for assistance. Warning - Relocating audio and/or video equipment to furniture not specifi cally designed to support audio and/or video equipment may result in death or serious injury due to the furnishing collapsing or over turning onto a child.

  • Page 3: Assembly & Set-Up

    Assembly / Setup 1. Install 3-piece skirt Phillips screwdriver Note: The skirt is designed to be installed with the lectern in the upright position. Do not tip or flip the lectern in any way. Door 1. Align the two audience-side skirt keyhole slots with the two pre-installed screws.

  • Page 4: Normal Operation

    2. Lift mechanism initial setup, operation, and reset procedure Preparation: Control buttons • Read all instructions before operation • Make sure lectern power cord is plugged-in • Locate the “Up” and “Down” control buttons on the instructor-side under the worksurface front edge •...

  • Page 5: Quick-Release Door

    Keyboard Tray / Drawer The tray can be used as a keyboard tray, or flipped and used as a drawer. 1. To remove, pull out the tray and locate the plastic lever on each slide. Figure 3A. 2. Release the levers (left-up, right-down) while pulling the tray out of the slides. 3.
  • Page 6 Removable Rack Cube Phillips screwdriver The removable rack cube (12RU) simplifies installation and provides the ability to integrate equipment remotely. The cube can be installed into the lectern at a later date. The cube also provides mounting capabilities for multiple 4mm Hex cooling fans if necessary.
  • Page 7 Rack Cube Note: Check the dimensions of all equipment before installation. (Overall depth) (Maximum component depth available) Rack rail Rack rail Cooling fan mounting location Fans should be mounted inside cube to provide clearance. This will take approximately 3RU’s of rack space. Figure 5D 0119327R1 Page 7 of 18...
  • Page 8 Flip-up shelf operation - optional Operation The shelf will automatically lock into place when lifted into the horizontal position with the levers released. Figure 6B. To lower or flip-up the CAUTION shelf, press and hold the shelf bracket levers while slowly lowering or raising the shelf.
  • Page 9 Overbridge insert panel - optional 4mm Hex Drill Wrench 1. To remove the overbridge insert panel, remove the (2) 1/4-20 x 35mm JC bolts with a 4mm hex wrench and lift out the panel. Figure 9A. Measuring Drill bit 2. To make cutouts in the insert panel [optional]: device A.
  • Page 10 Honors Lectern overbridge insert panel blank (flat view) 2” Grommet 2” Grommet Max cutout area Figure 9B Overbridge Section View C-C ™ Note: The Overbridge Control Console been designed for many of the currently avail- able controllers on the market, however, modi- fied cutouts should be reviewed by Spectrum to ensure clearance of brackets, keyboard slides, or other objects under the worksurface.

  • Page 11: Wiring Diagram

    Wiring Diagram Control buttons Control box Actuator Actuator Note: Provide enough slack in the power cord to accommodate full lectern extension. A separate power strip is recommended (not included) to plug the control box and other power plugs into. The power strip can be located in the upper or lower section of the lectern.
  • Page 12 Bottom view Power access Base skirt panels Note: Power cords can be accessed directly under the lectern using the base panel grommet holes. Figure 11. 2” Grommets for floor power Figure 11 access Caster operation 1. Lock the brake levers to lock movement of the casters. (Two instructor-side casters only).
  • Page 13 Accessories (Available separately after initial configured purchased) Customized Upper Logo Panel - 55148 • Attaches to audience-side of lectern • 24”W [60.96 cm] x 4.13”H [10.5 cm] • To get panel customized-contact Spectrum for details • New logos require a first time logo charge •...
  • Page 14 ™ Cove Power Module - 99044 • Two power receptacles • Requires worksurface cutout • Two USB charge ports • ETL listed (not data-compatible) • Available in Black or Silver • Thumbscrew clamps • Customer-installed Cutout required: 5.25”W [13.3 cm] x 2”D [5.1 cm] (mounts to surface thicknesses up to 1.5”) Power cord: 9’...

  • Page 15: Safety Information

    Electric leg information Warning! Only for EU markets • This appliance can be used by children aged from 8 years and above and persons Failure to comply with these instructions may result in accidents involving serious personal injury. with reduced physical, sensory or mental capabilities or lack of experience and Failing to follow these instructions can result in the product being damaged or being destroyed.
  • Page 16 Misc. on the DESKLINE® DL5/DL6 system Electrical connection of the DL5/DL6 system This system is a DESKLINE system developed for desks and for indoor use in offi ces. Do not The DESKLINE® DL5/DL6 system is to be connected as shown on fi gure 4. Each DL5/ use it in industrial kitchens or in other enviroments that have to be cleaned with aggressive DL6 is to be connected to the sockets on the control box by means of the motor cables, detergents.
  • Page 17 Honors Lectern Troubleshooting Guide Symptom Problem Solution Loss of power Be sure control box is plugged into a live circuit. Make sure all electrical connections are securely plugged into the control box. Loose electrical connections See wiring diagram on p.11 for reference. 1.

  • Page 18: Warranty

    • 10 Years • Cart Chassis • Lectern Chassis DESIGNED AND MANUFACTURED IN CHIPPEWA FALLS WISCONSIN.USA 925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM © 2015 Spectrum Industries Inc., All rights reserved. 0119327R1 Page 18 of 18...
