Spectrum Industries Media Manager V2 55253 Owner's Manual

With overbridge control console, with lh/rh drawer, heavy-duty casters and surround
Hide thumbs

Advertisement

Table of Contents

Owner's Manual
Media Manager
LH Drawer
RH Drawer
55253
55254
55256
55257
Standard Media Manager V2
with LH drawer, Heavy-Duty casters and surround
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported
within 15 days of receipt. To report information regard-
ing missing parts or damage, to purchase parts or
accessories, or if you have any questions, please
contact us.
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
925 First Avenue, Chippewa Falls, WI 54729 USA
800 235 1262
715 723 6750
www.spectrumfurniture.com
V2 Lectern
™
Standard Media Manager V2
with Overbridge Control Console
55253HDS
Media Manager V2 with Overbridge Control Console,
LH drawer and Heavy-Duty casters
55256HD
shown with optional insert panel (shaded)
0116157 Page 1 of 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Media Manager V2 55253 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Spectrum Industries Media Manager V2 55253

Summary of Contents for Spectrum Industries Media Manager V2 55253

  • Page 1 Thank you for purchasing Spectrum products! Spectrum Industries, Inc 925 First Avenue, Chippewa Falls, WI 54729 USA 800 235 1262 715 723 6750 www.spectrumfurniture.com...

  • Page 2: Assembly & Set-Up

    If servicing is necessary, please contact Spectrum Industries for assistance. Warning - Relocating audio and/or video equipment to furniture not specifi cally designed to support audio and/or video equipment may result in death or serious injury due to the furnishing collapsing or over turning onto a child.
  • Page 3 Changing rack rail position - optional Phillips Screwdriver 1. To move the rack rails from the left or right mounting positions, remove the 1/4-20 x 5/8” PHM screws attaching the rack rail brackets as shown in Figure 2A. 2. Move the rack rails and brackets into the new position and re-attach with the screws. rack rails and brackets in left position...
  • Page 4 Quick-release door hinge operation To remove door: Open door wide enough to be able to access the quick-release hinge. Support door with one hand. With other hand, push-down on the quick-release hinge lever until the upper hinge pin clears the upper hinge pin hole. Figure 3A. Hold the quick-release hinge lever down while tipping the top of the door away from the lectern.

  • Page 5: Cord Management

    Cord management 4mm hex wrench The audience-side logo panel can be removed to provide access to internal wiring. 1. Remove the (6) 1/4-20 x 15mm JC bolts and remove the panel. Figure 4A. 2. Cords can be accessed through the two openings behind the panel. 3.
  • Page 6 Overbridge insert panel (overbridge models only) Note: The insert panel shown (shaded) is not included with the lectern or over- bridge. This option needs to be ordered separately to complete the overbridge. drill drill bit jigsaw or router 1. To remove the overbridge insert panel, remove the (2) 1/4-20 x 35mm JC bolts with a 4mm hex wrench and lift out the panel.
  • Page 7 Media Manager V2 overbridge panel blank (flat view) 2” grommet 2” grommet max cutout area Figure 7B ™ Note: The Overbridge Control Console been designed for many of the currently avail- able controllers on the market, however, modified cutouts should be reviewed to ensure clearance of brackets, keyboard slides, or other objects under the worksurface.
  • Page 8 Floor anchoring (Toe kick versions only) 4mm hex Drill wrench 1. If your Media Manager is equipped with a toe kick, and you wish to attach it to the floor, the toe-kick will need to be detached from the lectern. To detach, remove the (4) 1/4-20 x 35mm JC bolts (one on each corner) from inside the lectern.
  • Page 9 Caster operation brake lever 1. To lock the caster rotation, press the brake lever. Figure 8. 2. To resume operation, lift up on brake lever. Figure 8 Moving and parking the lectern • Before moving, unplug and secure all power cords. •...
  • Page 10 Options Custom-cut logo panel Media Manager V2 Overbridge Insert Panel (audience-side) Rear Rack Rail Kit for overbridge version only-contact Spectrum to ⁄ ”W x 9”H 11RU specify cutout size(s) and position(s)- 55241 55238 overbridge not available separately (includes two 2” grommets with covers) 96507 - blank panel 96507mod - panel with cutout(s) Power/Communication Module...

  • Page 11: Rack-Mount Accessories

    Rack-mount accessories Pull-Out Shelf (3RU) Cantilever Shelf (2RU) Cantilever Shelf (3RU) Pull-Out Shelf (2RU) ⁄ ”W x 21 ⁄ ”D ⁄ ”W x 18”D x 3 ⁄ ”H ⁄ ”W x 18”D x 5 ⁄ ”H ⁄ ”W x 17 ⁄...

  • Page 12: Warranty

    Warranty WE WILL MAKE IT RIGHT FOR YOU! Spectrum is committed to provide complete customer satisfaction. Each of our products is manufactured from the best materials available and each product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet Customer Expectations). We expressly warrant that Spectrum products will be of good quality and workmanship and free from defect for the period set out in the warranty table below from the date of delivery.
