Solo 461 Instructions

Specifications

Suitable detector types : Rate of Rise and Fixed Temperature up to 194
Maximum detector size : Any – provided sensing element can be sealed within cup
Number of tests : Unlimited, if using one Baton whilst charging another
Maximum height : Up to 10ft using Solo 461
Up to 30ft using Solo extension poles
Safety Features : Battery over-current cut-out
: Element safety cut out after 120 seconds
: Auto power off after 5 mins
Operating features : Color coded LED user feedback
: Automatic starting of test via infrared sensing of detector
: Multi position user head for alignment of detector
: Recharge time of Battery Baton of 1 hour using fast charge
: Charger operates from car (12V DC) or 115 AC
: Battery life : in excess of 500 cycles
Environment : Operating temperature: 40
: Storage Temperature: 15
: Humidity: 0-85% RH non-condensing

Safety Notes:


The heat duct inside the Cordless Heat Detector Tester should not be touched
during operation.

Before using this product with SOLO telescopic or extension poles, ensure all
sections are fully locked into position.

Other Products Available from your Supplier


Telescopic pole, extendable, non conductive for accessing detectors at
SOLO 100
height to 20ft. Compatible with all other SOLO tools

SOLO 101 Extension pole, non-conductive rigid pole section. For use on its own or to
extend SOLO 100. Max of 3 recommended to reach up to 30ft

Universal detector removal / replacement tool
SOLO 200

Smoke detector tester (aerosol dispenser)
SOLO 300



SOLO 600 Protective Carrying and Storage Bag

Replacement Battery Batons
SOLO 721

AERO 100 Aerosols for use with SOLO 300

Important Note:

The Cordless Heat Detector Tester is a functional tester - not a calibration device. When
testing spot type combination rate of rise and fixed temperature heat detectors ensure
that the Cordless Heat Detector Tester is removed as soon as the detector is initiated.
Continued application of heat could cause permanent damage to the fixed temperature
element.
Do not attempt to test non-restorable / fusible link type detectors with this tool.
SDI, 1345 Campus Parkway, Neptune, New Jersey, 07753-6815, USA
Tel: (732) 751 9266 Fax: (732) 751 9241
Website: www.sdifire.com
o
F
o o
F to 115 F
o o
F to 120 F
Email: info@sdifire.com
Cordless CAT™ 461 Heat Detector Tester
Even though the device is quiet and small, and uses only battery power, a significant
amount of heat is deployed. Detectors should not be subjected to testing for longer
than necessary to set them into alarm.
After long periods of testing on a detector without an alarm signal, there is a danger
that damage may occur to the detector, so the tool will automatically cease any one
test after 120 seconds.

General Principles


Performs functional tests on most types of heat detector without the need for cables.

Operated by rechargeable NiCd (Nickel Cadmium) Battery Batons mounted within
TM
SOLO 100 or 101 (Telescopic or extension) pole.

Infra-red beam senses heat detector presence, switching the product from standby
to operational mode during a test, conserving energy.

Timed cut-out to help prevent damage.

Interchanging fully charged Battery Batons allows virtually unlimited testing
Brief Description
The product is designed to test
spot-type, fixed and rate of rise heat
detectors.
Virtually all known detectors fit into
the opening of the clear cup and
membrane, and can be easily
tested.
Hot air is blown from the side duct
into the detector under test, and it
will only take a short amount of time
for the detector to alarm.
