ITEM #0672832/0672826 LED WORK LIGHT MODEL #KWL 224-03 Français p. 9 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday.
PACKAGE CONTENTS PART DESCRIPTION PART DESCRIPTION ON/OFF switch Light head Transparent cover Loop WARNING • Remove the tool from the package and examine it carefully. Do not discard the carton or any packaging material until all parts have been examined. •...
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble or operate this product. If you have any questions regarding the product, please call customer service at 1-888-3KOBALT, 8 a.m. - 8 p.m., EST, Monday - Friday. Know the Tool To operate this tool, carefully read this manual and all labels affixed to the tool before using it.
SAFETY INFORMATION CAUTION • Hot Surface. • Risk of Burns - Do Not Touch. • Risk of Fire - Keep Away From Combustible Materials. IMPORTANT SAFETY INSTRUCTIONS WARNING • When using electric appliances, basic precautions should always be followed, including the following: •...
OPERATING INSTRUCTIONS 1. Battery Pack To Attach Battery Pack a. Align the raised portion on the battery pack with the grooves on the bottom of the tool, and then slide the battery pack onto the tool as shown. b. Make sure that the latch on the battery pack snaps into place and the battery pack is secured to the tool before beginning operation.
OPERATING INSTRUCTIONS 3. Adjusting the LED Work Light Head The light head (C) pivots from fully upright to fully folded, and can remain at any point within the 135° range. 4. Loop The LED work light is equipped with a loop (D). The light can be carried or hung to an object with the loop.
TROUBLESHOOTING WARNING • Turn the switch to the “OFF” position and remove the battery pack from the tool before performing troubleshooting procedures. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION The LED work light does not work Battery is depleted Charge the battery WARRANTY For 5 years from the date of purchase, the LED work light is warranted and for 3 years from date of purchase the battery &...
Page 9
ARTICLE #0672832/0672826 LAMPE DE TRAVAIL À DEL MODÈLE #KWL 224-03 JOIGNEZ VOTRE REÇU ICI Numéro de série Date d’achat Des questions, des problèmes, des pièces manquantes? Avant de retourner l’article au détaillant, appelez notre service à la clientèle au 1 888 3KOBALT (1 888 356-2258),...
TABLE DES MATIÈRES Caractéristiques du produit ....................10 Contenu de l’emballage ....................11 Consignes de sécurité ....................12 Préparation ........................13 Mode d’emploi .......................14 Entretien ........................15 Dépannage ........................16 Garantie .........................16 CARACTÉRISTIQUES DU PRODUIT COMPOSANT CARACTÉRISTIQUES Tension nominale 24 V c.c. Pivot de tête 135° Source lumineuse 200 Lumen...
CONTENU DE L’EMBALLAGE PIÈCE DESCRIPTION PIÈCE DESCRIPTION Interrupteur Tête de lampe Couvercle transparent Boucle AVERTISSEMENT • Retirez l’outil de l’emballage et examinez-le soigneusement. Ne jetez ni la boîte ni le matériel d’emballage avant d’avoir examiné toutes les pièces. • Si une pièce de l’outil est manquante ou endommagée, évitez de fixer le bloc-piles ou d’utiliser l’outil tant que la pièce n’a pas été...
CONSIGNES DE SÉCURITÉ Assurez-vous de lire et de comprendre l’intégralité de ce manuel avant de tenter d’assembler ou d’utiliser le produit. Si vous avez des questions, veuillez communiquer avec notre service à la clientèle au 1 888 3KOBALT, entre 8 h et 20 h (HNE), du lundi au vendredi. Sachez bien comment utiliser l’outil Veuillez lire attentivement ce manuel et toutes les étiquettes apposées sur l’outil avant de l’utiliser.
CONSIGNES DE SÉCURITÉ • En cas d’usage abusif, du liquide peut s’échapper des piles; évitez tout contact avec celui-ci. En cas de contact accidentel, rincez à grande eau. En cas de contact avec les yeux, consultez un médecin. Le liquide provenant des piles peut causer de l’irritation ou des brûlures.
MODE D’EMPLOI 1. Bloc-piles Pour insérer le bloc-piles a. Alignez les nervures du bloc-piles aux rainures situées sous l’outil, puis faites glisser le bloc-piles de manière à ce qu’il s’insère sur l’outil de la manière indiquée. b. Assurez-vous que le verrou du bloc-piles s’enclenche et que le bloc-piles est bien fixé...
MODE D’EMPLOI 3. Réglage de la tête de lampe de travail à DEL La tête de lampe (C) peut être réglée en position complètement verticale ou complètement pliée, et placée à tout angle dans cet intervalle de 135°. 4. Boucle La lampe de travail à...
DÉPANNAGE AVERTISSEMENT • Mettez l’interrupteur à la position OFF (arrêt) et retirez le bloc-piles de l’outil avant d’effectuer toute tâche de dépannage. PROBLÈME CAUSE POSSIBLE MESURE CORRECTIVE La lampe de travail à DEL ne fonctionne pas. La pile est à plat. Chargez la pile.
