Specifications - AutoAqua Smart ASOV Manual

b. RO/DI System with Auto Shut Off
Connect the solenoid valve at the RO/DI output
to the directional waterflow arrow on the solenoid valve).
1/4 inch Tubing from
RO/DI outlet
Specifications
1. Power Input : 100-240 VAC 50-60 Hz
2. RO Solenoid Valve :
• 6 W @ 12 VDC
• 1/4 inch RO Tubing Connection
3. Max. Mounting Thickness :
• Sensor : 1/2 inch (12.7 mm)
• RO Tubing Holder : 1.2 inches (30.5 mm)
Notice
1. Please read the manual before the installation. Keep the power
adapter dry and avoid any contact with water to prevent any
malfunction.
2. Please avoid setting up the sensor in an area with micro bubbles
or direct lighting.
2
3
Solenoid Valve
(*pay close attention
*
3
English
1
Water Reservoir
