DA 40 NG AMM
This temporary revision is approved in conjunction with the Mandatory Design Change Advisory MÄM 40-
1038 and is valid in conjunction with the Airplane Maintenance Manual (AMM) until this temporary revision
has been incorporated into the AMM.
The limitations and information contained herein either supplement, or in the case of conflict, override those
in the AMM.
The technical information contained in this document has been approved.
Doc. No.
6.02.15
Doc # 6.02.15
AMM-TR-MÄM 40-1038
AIRCRAFT MAINTENANCE MANUAL
TEMPORARY REVISION
AMM-TR-MÄM 40-1038
Section
05-28-50
05-50-00
32-20-00
COVER
NLG Inspection & Maintenance
AIRCRAFT
Affected Pages
Temporary Revision
3 to 10
11 to 18
19 to 22
Page 1
13 Jul 2020
