  • Page 2 DA 62 AFM Ice Protection System Supplement S02 Intentionally left blank. Page 9-S02-2 31-Jan-2019 Doc. # 11.01.05-E Revision 0...
  • Page 3 DA 62 AFM Ice Protection System Supplement S02 0.1 RECORD OF REVISIONS Rev. Chap- Date of Approval Date of Date Reason Page(s) Signature Revision Note Approval Inserted Doc. # 11.01.05-E 31-Jan-2019 Page 9-S02-3 Revision 0...
  • Page 4 DA 62 AFM Ice Protection System Supplement S02 0.2 LIST OF EFFECTIVE PAGES Chapter Page Date 9-S02-1 31-Jan-2019 9-S02-2 31-Jan-2019 9-S02-3 31-Jan-2019 9-S02-4 31-Jan-2019 9-S02-5 31-Jan-2019 9-S02-6 31-Jan-2019 9-S02-7 31-Jan-2019 9-S02-8 31-Jan-2019 9-S02-9 31-Jan-2019 DOT approved 9-S02-10 31-Jan-2019 DOT approved 9-S02-11...
  • Page 5 DA 62 AFM Ice Protection System Supplement S02 Chapter Page Date 9-S02-23 31-Jan-2019 9-S02-24 31-Jan-2019 9-S02-25 31-Jan-2019 9-S02-26 31-Jan-2019 9-S02-27 31-Jan-2019 9-S02-28 31-Jan-2019 9-S02-29 31-Jan-2019 9-S02-30 31-Jan-2019 9-S02-31 31-Jan-2019 9-S02-32 31-Jan-2019 9-S02-33 31-Jan-2019 9-S02-34 31-Jan-2019 9-S02-35 31-Jan-2019 9-S02-36 31-Jan-2019 9-S02-37...

  • Page 6: Table Of Contents

    DA 62 AFM Ice Protection System Supplement S02 0.3 TABLE OF CONTENTS Page GENERAL ........... . . 9-S02-7 OPERATING LIMITATIONS .

  • Page 7: General

    This supplement to the AFM contains all necessary information to operate the ice protection system of the DA 62. The DA 62 can be equipped with an optional ice protection system in accordance with the Optional Design Change Advisory OÄM 62-002. It distributes a thin film of de-icing fluid on the wings, vertical stabilizer, horizontal stabilizer, propellers, and windscreen.
  • Page 8 DA 62 AFM Ice Protection System Supplement S02 WARNING Some icing conditions have the potential of producing hazardous ice accumulations, which (1) exceed the capabilities of the airplane's ice protection equipment, and/or (2) create unacceptable airplane performance. Inadvertent operation in these conditions may be detected by heavy ice accumulation on the windshield, or when ice forms on the side areas of the canopy.
  • Page 9 DA 62 AFM Ice Protection System Supplement S02 or airborne. Ice Crystals: Any one of a number of macroscopic, crystalline forms in which ice appears. Examples are hail and snow. Icing conditions: An icing condition is defined as visually detected ice, or the presence of visible moisture in any form at or below an indicated outside air temperature (OAT) of +5 °C (41 °F).

  • Page 10: Operating Limitations

    DA 62 AFM Ice Protection System Supplement S02 OPERATING LIMITATIONS NOTE There is no change in existing operating limitations of the airplane. The following information is exclusively to reflect the new indications and information related to the ice protection system.
  • Page 11 DA 62 AFM Ice Protection System Supplement S02 2.6 WARNING, CAUTION, AND ADVISORY ALERTS 2.6.1 WARNING, CAUTION, AND ADVISORY ALERTS ON THE G1000 NOTE The alerts described in the following are displayed on the Garmin G1000. Section 7.10 includes a detailed description of the alerts.
  • Page 12 DA 62 AFM Ice Protection System Supplement S02 NOTE The airplane must be completely cleared of ice, snow and similar accumulations. For approved de-icing fluids, refer to AFM Section 8.7 - GROUND DE-ICING. 2.15 LIMITATION PLACARDS Next to the filler cap:...
  • Page 13 DA 62 AFM Ice Protection System Supplement S02 CAUTION The use of other fluids will provide a correspondingly lower standard of ice protection or may cause damage to the ice protection system. NOTE The maximum usable tank capacity is 36 liters (9.5 US gal). The maximum tank capacity is 37 liters (9.8 US gal).

  • Page 14: Emergency Procedures

    DA 62 AFM Ice Protection System Supplement S02 EMERGENCY PROCEDURES 3.5 G1000 FAILURES 3.5.7 ERRONEOUS OR LOSS OF DE-ICING FLUID DISPLAY If the de-icing fluid quantity is known, the remaining system operating time can be estimated based on the durations given in Section 2.17 - DE-ICING FLUIDS FOR SYSTEM OPERATION.
  • Page 15 DA 62 AFM Ice Protection System Supplement S02 CAUTION Do not delay activation of the ice protection system if icing conditions are encountered. CAUTION The stall warning in icing conditions may not be reliable and must not be relied upon in icing conditions.
  • Page 16 DA 62 AFM Ice Protection System Supplement S02 If the system does not work properly Continue with Section 3.15.1 - FAILURE OF THE ICE PROTECTION SYSTEM. If the system works properly, proceed as follows 7. Leave the icing area (by changing altitude, turning back, even continuing on the same course if clear air is known to be immediately ahead).
  • Page 17 DA 62 AFM Ice Protection System Supplement S02 CAUTION If ice fails to shed, proceed with Section 3.15.1 - FAILURE OF THE ICE PROTECTION SYSTEM. 3. ICE LIGHT ......ON, as required 4.
  • Page 18 DA 62 AFM Ice Protection System Supplement S02 3.15 ICE PROTECTION SYSTEM EMERGENCIES 3.15.1 FAILURE OF THE ICE PROTECTION SYSTEM A “failure” of the ice protection system is any condition in which the system fails to remove ice from protected surfaces, including the propellers.

  • Page 19: Normal Operating Procedures

    DA 62 AFM Ice Protection System Supplement S02 4A. NORMAL OPERATING PROCEDURES 4A.6 CHECKLISTS FOR NORMAL OPERATING PROCEDURES 4A.6.1 PRE-FLIGHT INSPECTION I. Cabin Check Ice protection system a) ELEC MASTER ..... . . ON b) DEICE FLUID .
  • Page 20 DA 62 AFM Ice Protection System Supplement S02 g) DEIC PRES HI ......verify NOT ILLUMINATED h) DEICE LVL LO ......check (must be annunciated if de-icing fluid quantity is below 11 liters (2.9...
  • Page 21 DA 62 AFM Ice Protection System Supplement S02 b) Filler cap ......check secure c) Inspection door .
  • Page 22 DA 62 AFM Ice Protection System Supplement S02 4A.6.17 PARKING NOTE When the ice protection system has been enabled in flight, special care must be taken when touching the airframe structure or windscreen, as they may be partially contaminated with de-icing fluid.

  • Page 23: Abnormal Operating Procedures

    DA 62 AFM Ice Protection System Supplement S02 4B. ABNORMAL OPERATING PROCEDURES NOTE The abnormal operating procedures of this supplement describe the operation of the ice protection system during the occurrence of cautions on the G1000. Nevertheless, flight in icing conditions is not approved.
  • Page 24 DA 62 AFM Ice Protection System Supplement S02 CAUTION If at ambient temperature above 10 °C (50 °F) and below 20 °C (68 °F) DEIC PRES LO warning appears in HIGH mode, switch to max mode to cancel the warning. Above 20 °C (68 °F) ambient temperature, warning cancellation may not be possible.
  • Page 25 DA 62 AFM Ice Protection System Supplement S02 4B.3.18 FAILURE OF THE INDICATION LIGHTS The indication lights (MAX, NORM, HIGH) on the de-ice panel are only used to indicate the selected operating mode. Failure to illuminate does not indicate a malfunction of the system.

  • Page 26: Performance

    DA 62 AFM Ice Protection System Supplement S02 PERFORMANCE 5.1 INTRODUCTION Airplane performance and stall speeds in clear air are unchanged with the installation of the ice protection system. CAUTION Significant climb and cruise performance degradation, range reduction, buffet, and stalling speed increase must be expected if ice accumulates on the airframe.

  • Page 27: Mass And Balance

    DA 62 AFM Ice Protection System Supplement S02 MASS AND BALANCE 6.4 FLIGHT MASS AND CENTER OF GRAVITY 6.4.1 MOMENT ARMS Lever Arm Item [in] De-icing fluid tank 0.90 35.4 The mass (weight) of the de-icing fluid is obtained as follows: * Multiply the fluid quantity in liters by 1.1 to obtain kilograms (kg), or...

  • Page 28: Description Of The Airplane And Its Systems

    DA 62 AFM Ice Protection System Supplement S02 7.9 DESCRIPTION OF THE AIRPLANE AND ITS SYSTEMS 7.9 POWER PLANT 7.9.4 ENGINE INSTRUMENTS On the Garmin G1000 MFD, the de-icing fluid level indication is displayed on the system page. Indication markings indicate (from left to right) 1/4, 2/4, 3/4, and 4/4 of the usable fluid quantity (36 liters or 9.5 US gal).
  • Page 29 DA 62 AFM Ice Protection System Supplement S02 7.10 ELECTRICAL SYSTEM 7.10.3 WARNING, CAUTION, AND ADVISORY MESSAGES Caution Alerts on the G1000 Caution Alerts Meaning/Cause (Amber) System pressure upstream of the porous panels on the horizontal DEIC PRES LO or vertical tail is too low.
  • Page 30 DA 62 AFM Ice Protection System Supplement S02 7.16 DE-ICING SYSTEM Description The ice protection system is electrically operated. It is supplied with power via the XFR PUMP/DE-ICE circuit breaker. The airframe and propellers are grouped and operate together. Windshield de-icing is a separate system and operates independently. All systems draw fluid from a common tank.
  • Page 31 DA 62 AFM Ice Protection System Supplement S02 Ice Light Control Box Metering Pumps Windshield Pump Solenoid Valve HP Switch Tail Bracket Assy TKS Fluid Tank (Low Pressure Switches) Fluid Level Gauge Low Fluid Level Switch Ice Light Electrical Overview The system consists of the following main components: * De-icing fluid tank with an integrated filler neck, which has an inlet strainer.
  • Page 32 DA 62 AFM Ice Protection System Supplement S02 * A low level sensor in the tank provides indication of the minimum quantity for dispatch (55 minutes). * A fluid level gauge provides data for the de-icing fluid level indication on the G1000 system.
  • Page 33 DA 62 AFM Ice Protection System Supplement S02 Porous titanium panels are fitted to the leading edge of the outer wings, the vertical tail, and the horizontal tail. The porous panels weep the fluid at a low rate through fine holes.
  • Page 34 DA 62 AFM Ice Protection System Supplement S02 Replenishing Refer to Section 2.17 of this supplement for approved de-icing fluids. NOTE The de-icing fluid must be considered for the mass and balance calculations. Refer to Chapter 6 of this supplement.
  • Page 35 DA 62 AFM Ice Protection System Supplement S02 OFF/NORM/HIGH switch The OFF/NORM/HIGH switch operates the selected main pump and thus activates the system. It has 3 positions: Down position: Center position: NORM (normal). The main pumps produce a cycled fluid flow: the main pumps provide fluid to the system for 30 seconds, followed by a 90 second break.
  • Page 36 DA 62 AFM Ice Protection System Supplement S02 Up position: PUMP 2. Main pump no. 2 is selected as the active pump in HIGH mode. Pump no. 1 is standby. WINDSHIELD push button The WINDSHIELD push button activates the selected windshield de-icing pump for a duration of 5 seconds.

  • Page 37: Airplane Handling, Care, And Maintenance

    DA 62 AFM Ice Protection System Supplement S02 AIRPLANE HANDLING, CARE, AND MAINTENANCE The porous panels can be cleaned with soap and water using a clean, lint-free cloth. Isopropyl alcohol, ethyl alcohol, or methylated spirit may be used to remove oil or grease. Furthermore, approved de-icing fluids, AVGAS, and jet fuel are permitted for use on the panels.
  • Page 38 DA 62 AFM Ice Protection System Supplement S02 8.4.6 PROLONGED OUT OF SERVICE OR DE-ICING SYSTEM RUN DRY To avoid the need to reprime the system, and to provide a quick response when returned to service, maintain at least 2 liters (0.5 US gal) in the tank. To ensure that all system components are filled with fluid, operate the system at least once a month.
