Terminals and sockets 3.2.4 LED‘s FPM-2 Technical data 4.2 Terminal assignment and configuration 4.2.1 Bus connection X11 ... X12 4.2.2 Jumpers 4.2.3 Terminals and terminal strips Connection of an EAZ-256/64.FPM-2 FPE 5.1 Technical data 5.2 Terminal assignment and configuration Technical data 6.2 Terminal assignment and configuration Manual FPM-1, FPM-2, FPE, FPA...
About this manual About this manual This manual contains all information on the FPM-2, FPM-1, FPE and FPA car operating panel modules. Abbreviations, characters and symbols used Symbol / Meaning abbreviation Car operating panel adapter; replaces the 50-pin round cable for the car operating panel wiring Car operating panel extension;...
If, after referring to this manual, you still require assistance, our service line is there for you: Phone +49 89 – 898 66 – 110 E-mail service@newlift.de Mon. - Thurs.: 8:00 a.m. – 12:00 p.m. and 1:00 p.m. – 5:00 p.m. 8:00 a.m. – 3:00 p.m. Manual FPM-1, FPM-2, FPE, FPA...
› Before opening the original packaging, a static discharge must be performed. To do this, touch a grounded piece of metal. › During work on electronic assemblies, periodically perform this discharge procedure. › All bus inputs and outputs not in use must be equipped with a terminal resistor (terminator). Manual FPM-1, FPM-2, FPE, FPA...
The FPM-1 car operating panel module forms the interface between the car operating panel and the FST control system. An FPM-1 supports up to 16 car calls. The FPM-1 is connected to the FST via the LON bus. The FPM-1 is either assembled in the car top box or in the car operating panel.
In „single door mode“, the car call of the car panel module are assigned using the jumpers on one door side (A, B or C). If jumper J2 is plugged in, the FPM-1 is in the so-called „dual door mode, “ i.e. an FPM-1 can process car calls for door sides A and B.
FPM-1 3.2.3 Terminals and sockets FPM-1 X3 An FPE can be connected to the FPM-1 via the X3 plug. FPM-1: X3 Car call extension + 24 V + 24 V + 5 V + 5 V Reset of SPI drivers...
Page 10
Car call 02 Car call 02 door side A I/O; L 250 mA / 24 V gn br bk + 24 V + 24 V * see FST2XT-XTs manual „5.5.5 Display 0 ... 2“ Manual FPM-1, FPM-2, FPE, FPA...
For emergency lighting: Four white LED‘s on the back of the FPM-2 module illuminate the text field as soon as the car lighting fails. Manual FPM-1, FPM-2, FPE, FPA...
Door A+B dual door mode plugged plugged Installation position of the EAZ-256.64 Installation position EAZ-256.64 Vertical installation position plugged Horizontal installation position open The jumpers J8 and J9 are not in use yet. Manual FPM-1, FPM-2, FPE, FPA...
I; L; 250 mA / 24 V Key switch fireman Key switch fireman FPM-2 X23.6 I; L; 250 mA / 24 V service service Pin 34 function Pin 34 function FPM-2 X23.8 I; L; 250 mA / 24 V FPM-2 X23.9 Manual FPM-1, FPM-2, FPE, FPA...
Page 15
I/O; L; 250 mA / 24 V X21.7 Car call 06 I/O; L; 250 mA / 24 V X21.8 Car call 07 I/O; L; 250 mA / 24 V X21.9 Car call release 01 O; L; 250 mA / 24 V X21.10 +24V Manual FPM-1, FPM-2, FPE, FPA...
Page 16
The acoustic acknowledgement is already integrated on the FPM-2 assembly and does not need to be led to the terminals. Emergency light function: As soon as the supply voltage of the car lighting fails, four white LEDs illuminate the text field. Manual FPM-1, FPM-2, FPE, FPA...
1,5m, use alternatively a LON EAZ. If the following pattern is displayed on the screen after the FPM-2 supply voltage has been switched on via bus connector X11 or X12, there is no bus connection. Display for checking the function Manual FPM-1, FPM-2, FPE, FPA...
The FPE is the extension of the FPM-1. The module is connected to the FPM-1 car operating panel module via FPE X3. This means the car calls for floors 16 to 63 are supported. Technical data Description Value Supply voltage 24 V DC ±10%...
Page 19
Car call 21 Car call 13 door side A I/O; L; 250 mA / 24 V wh gn bk Car call 18 Car call 10 door side A I/O; L; 250 mA / 24 V gn br bk +24 V +24 V Manual FPM-1, FPM-2, FPE, FPA...
FPM-1 X4 plug. It replaces the 50-pin round cable for the car operating panel wiring. The FPA is connected to the X4 plug of the FPM-1 car operating panel module via the 50-pin X4 plug. Switching from „single door mode“ to „dual door mode“ is done on the associated FPM-1 with the JK2 jumper.
FPA circuit board marking 222,5 93,5 FPM-1 dimensions in combination with FPA Terminal assignment and configuration FPA X4 corresponds exactly to FPM-1 X4 FPA X5 Car operating panel signals Technical data Car call 00 (00 Door side A for dual door mode) Car call 01 (01 Door side A for dual door mode)
Page 22
Car call release Call 12 Car call release Call 13 Car call release Call 14 Car call release Call 15 + 24 V + 24 V + 24 V + 24 V + 24 V + 24 V Manual FPM-1, FPM-2, FPE, FPA...
Page 23
"Ventilator ON/OFF" button Key switch fireman service Key switch car priority Direction UP Direction DOWN Overload display Display 0 * Display 1 * Display 2 * * see FST2XT-XTs manual „5.5.5 Display 0 ... 2“ Manual FPM-1, FPM-2, FPE, FPA...
