Sony CDX-C8050X Product Guide Specifications

2000 MOBILE ES PRODUCT GUIDE
• X-tal Lock SSIR-EXA Tuner, Station Memo
• 18FM & 12AM Memory Presets
• 8X Oversampling, 1-Bit D/A, Active Servo Control
• Adj. Hi/Lo Pass Filters, Sub Pre-Out w/LPF level
• Multi-Color Dot Matrix LCD w/EL Backlight
General
Output Lead
DSP EQ
Power Requirements
Dimensions (w/h/d)
Mounting Dimension (w/h/d)
Weight
Supplied Accessories
Optional Accessories
Tuner Section
FM
Tuning Range
Antenna Terminal
Intermediate Frequency
Usable Sensitivity
Selectivity
Signal-to-Noise Ratio
Harmonic Distortion @ 1 kHz
Separation
Frequency Response
CD Player Section
Mechanism Type
System
Frequency Response
Signal-to-Noise Ratio
Wow and Flutter
Preamplifier Section
Line Outputs
Line Output Impedance
Bus Input Impedance
Max Line Output Level
Power Amplifier Section
Speaker Outputs
Speaker Impedance
Maximum Power Output
RMS Power Output
Distortion
10
CDX-C8050X
CD Receiver
Line Outputs (2), Power Antenna, Relay Control Lead, Power Amplifier Control Lead,
Telephone ATT Control Lead
±12dB at 62Hz, 157Hz, 396Hz, 1kHz, 2.5kHz, 6.3kHz, 16kHz
12VDC Car Battery (negative ground)
Approx.188 x 58 x 182 mm (7
Approx. 182 x 53 x 162 mm (7
Approx. 1.3 kg (2 lb. 14 oz.)
Parts for Installation and Connections (1 set); Front Panel Case (1), Wireless Remote (RM-X91)
Wired Remote (RM-X4S)
87.5-107.9 MHz
External Antenna Connector
10.7 MHz
8 dBf
75 dB at 400 kHz
66 dB (stereo); 72 dB (mono)
0.6% (stereo); 0.3% (mono)
35 dB (@ 1 kHz)
30-15,000 Hz
MG-383V-121//Q
Compact Disc Digital Audio System
10-20,000 Hz
90 dB
Below measurable limit
Front/Rear/Sub (RCA)
200 ohms
50k ohms
4.0 Volts, < 1.0% THD
Front/Rear Outputs
4-8 ohms
50W x 4 (@ 4 Ω)
19W x 4 (20-20kHz, 4 Ω)
1% THD
Design and specifications subject to change without notice.
• CD/MD/TV Control, Custom File, HX DSP
• 4 Volt F/R/S Preout, <200Ω source imped.
• 50 W x 4 High Power Output
• Fold Down Detachable Face
• Supplied Wireless Remote
1 / x 2 3 / x 7 1 / in.) (including trim)
8
2 8
3 / x 2 x 6 1 / in.)
16 2
AM
Tuning Range
Antenna Terminal
Intermediate Frequency
Sensitivity
Harness Plug Configuration
Plug shown with wires facing viewer
Pin Number Wire Color
1 White
2 Green
3 Violet
4 Grey
5 Blue/White
6 Blue
7 Red
8 Black
9 White/Black
10 Green/Black
11 Violet/Black
12 Grey/Black
13 Sky Blue
14 Orange
15 N/C
16 Yellow
530-1,710 kHz
External Antenna Connector
450 kHz
30 µV
Description
Left Front Positive
Left Rear Positive
Right Rear Positive
Right Front Positive
Amp Remote
Antenna Remote
Accessory +12 VDC
Ground
Left Front Negative
Left Rear Negative
Right Rear Negative
Right Front Negative
Telephone Attenuate
Illumination
Constant +12 VDC
